Side 1/5

Se reporter aux dessins numérotés correspondant aux numéros des

paragraphes de la notice d’instructions

Presentation 1

Installation 1

Use and safety 2

Cleaning and hygiene 3

Operating incidents 4

Maintenance 4

Conformity with regulations 5

Sommaire

Presentation

Never place the peeling machine in a sink (risk of water leaking

into the motor).

T8E GB 09 2016

2.2

2.1

1.1

1.1 DESCRIPTION

This 8kg peeling machine is used essentially for vegetables

to be peeled or for spin-drying vegetables, depending on the

equipment being used.

There is a T8E «mussels» version :

- Motor 1000 rpm – «Special mussel» bowl and plate

E Waste water evacuation

F Partition

G Stainless steel ferrule

H Electric controls

I Bottom

Installation

A Water inlet (clip-on

shower head)

B Removable cover

C Removable bowl

D Filter case (receiving

optional lter)

2. (for information 1 DIMENSIONS AND WEIGHT

only)

• Gross weight packed with abrasive plate: 26,5 kg

• Net weight: 23,5 kg

- Packed sizes : 450 x 480 x 695 mm

- Overall machine dimensions : 422 x 390 x 675 mm

2.2 LOCATION

• The peeling machine requires:

- Connection to the cold water system with a nearby shuto󰀨 tap

(see § 2.3)

- A large enough drain to the main drain (see § 2.4)

- An electric power supply (see § 2.5)

• It can be mounted:

- On a totally stable and horizontal non-resonating support (table,

cabinet, sink top) with a height included between 500 and 900

mm.

Note: In this case, the peeling machine can be removed easily

after disconnecting the power outlet and the exible water supply

pipe or unclipping the water inlet (shower head) from the cover.

2.3 CONNECTION TO THE WATER SYSTEM

• The peeling machine operates at network pressure and at

low water ow rate.

• In conformity with the sanitary regulations, the machine water

inlet is above the overow level at a standardized distance (spill-

over device).

• The machine is supplied with a 1 m long exible hose having

a 1/2 female connection mating with the shuto󰀨 tap.

• The clip-on water inlet of the cover means that the machine

can be removed without needing to touch the connecting pipe.

Note: If the peeling machine has to be moved regularly, provide

a connecting pipe equipped with quick couplings.

2.4 WASTE WATER DRAIN AND WASTE

SEPARATION

• Waste separation is necessary, depending on the size of such

waste (pieces of peel, skin, starch, foam, soil) depending on the

equipment used (see § 3.2)

• Some installations have starch decanting tanks to which connec-

tion can be made directly. For other installations, we advise a

lter mounted on the peeling machine to prevent clogging and

bad smells.

• The machine is provided with a drain exible hose 0.7 m long,

not assembled.

- Screw on the exible hose, LH thread, counter-clockwise

into coupling E.

Recommendations:

To drain o󰀨 the waste water correctly, avoid:

- Vertical falls opening onto a manhole (causing foam to form),

- Abrupt bends,

- Flattened, deformed or shrunken pipes,

- Counter-slopes or excessively shallow slopes

06/2024

The «mussels» version cannot be used to peel potatoes, even

with an abrasive plate.

2.2b

Introduction

The User Manual contains useful information for the user on how

to work correctly and in complete safety, and is designed to make

it easier to use the machine (called «machine» or «appliance»

below).

What follows is in no case intended to be a long list of warnings and

constraints, but rather a series of instructions meant to improve the

service provided by the machine in every respect, and particularly

to avoid a series of injuries or damage to equipment that might

result from inappropriate procedures for use and management.

It is essential that all the people responsible for transporting,

installing, commissioning, using, maintaining, repairing or dis-

mantling the machine should consult this manual and read it

carefully before proceeding with the various operations, in order

to avoid any incorrect or inappropriate handling that might be

result in damage to the machine or put people’s safety at risk.

It is just as important that the Manual should always be available

to the operator and it should be kept carefully where the machine

is used ready for easy and immediate consultation in case of any

doubt, or in any case, whenever the need arises.

If after reading the Manual, there are still any doubts concerning

how to use the machine, please do not hesitate to contact the

Manufacturer or approved After Sales Service provider, who is

constantly available to ensure quick and careful service for im-

proved machine operation and optimum e󰀩ciency.

Note that the safety, hygiene and environmental protection stan-

dards currently applicable in the country where the machine is

installed must always be applied during all phases of machine

operation. Consequently it is the user’s responsibility to ensure

that the machine is operated and used solely under the optimum

safety conditions laid down for people, animals and property.

The reference language for these instructions is French.

2.5 ELECTRICAL CONNECTIONS

ATTENTION!!

Connection to the electrical power supply must be done according to proper professional practice by a qualied and authorised

person (see current standards and legislation in the country of installation).

If an adapter is used on the socket, a check must be made that the electrical characteristics of this adapter are not lower than

those of the machine.

Do not use multiple plugs

The AC power supply to the machine must comply with the following conditions (EN60204-1);

- Maximum voltage variation: ±10%

- Maximum frequency variation: ±1% on a continuous basis, ± 2% over short periods

ATTENTION: the electrical installation must comply (for design, creation and maintenance) with the legal and standard

requirements in the country where used.

- Check that the electric mains voltage, the value shown on the specication plate.

- The machine’s electrical power supply must be protected against voltage surges (short-circuits and excess voltages) using

a circuit breaker compliant with IEC60947-2 properly sized, of the appropriate gauge relative to the place of installation and

machine specications .

ATTENTION: Concerning protection against indirect contact (depending on the type of power supply provided and

connection of the exposed conductive parts to the equipotential protection circuit), refer to point 6.3.3 of EN 60204-1

(IEC 60204-1) with the use of protection devices for automatic shut-o󰀨 of power in the event of an insulation fault with

a TN or TT, system, or for the IT system, with the use of a permanent insulation or di󰀨erentials controller for automatic

shut-o󰀨. The requirements of IEC 60364-4-41, 413.1 must apply for this protection.

For example: in a TN or TT system, a di󰀨erential circuit breaker must be installed upline of the power supply, with a

suitable power cut-o󰀨 (e.g.: 30 mA) on the earthing installation for the place where it is planned to install the machine.

ATTENTION: Failure to comply with these instructions means the customer runs the risk of machine failure and/or acci-

dents due to direct or indirect contacts.

Grounding is mandatory

The machine is supplied with single-phase power by a 2-pole +

ground molded plug. Provide an accessible standardized wall

outlet with 2 poles + ground, rated at 10/16A in accordance with

IEC60309, and a corresponding waterproof plug to be installed

on the power cord.

• Motor characteristics:

power Rated Frequency Current Electrical Speed

Supply(V) Power(W) (Hz) (A) Consu(kWh) rpm

230/240 370 50 2,8 0,54 1500

115 370 60 5,5 0,54 1500

230/240 250 50 2 0,47 1000

Special mussels

To PAT test the Electrolux Range of Food Preparation Equipment,

the PCB board needs to be disconnected before any test is done.

This is due to the fact that the boards are tted with a grounding

diode that can give incorrect result during such a test. Also on a

standard appliance a ash test of 25 amps and up to 3000v is

used but, as you would expect, to use this on equipment, which

has a printed circuit, board would be quite destructive to that

board. We would recommend the use of a PAT tester approved

for computer systems which use a lower rate of amps.

The appliance is perfectly safe and is CE certicated. There are

two ways to get overcome this problem.

· Disconnect the board as instructed and test using test for PC’s,

· Or install the mixer on a fused spur (no plug) as this takes it

away from being a portable appliance and the PAT test is then

not needed.

3.1

Use and Safety

3.1 OPERATION - SAFETY

• The safety of the user is ensured by:

- The need to press the ON pushbutton after a stoppage (“no

voltage” device)

- Compliance with the instructions of this manual for use, cleaning

and maintenance of the machine.

• Control box

I ON pushbutton

O OFF pushbutton

• An adjustable time-lag relay in the machine ensures the ope-

rating cycle (preset to 1minute 30’’).

Time lag relay adjustment:

- Turn the machine over.

- Remove the round rubber cover.

- Using a screwdriver, set the desired time (as a percentage)

E.g.:

3 = 3 min.

2,5 = 2 min. 30»

2 = 2 min.

1,5 = 1mn30’’ (standard adjustment)

a) Startup:

- Press the ON button to begin a 1-min30’’. cycle.

- Automatic stoppage at cycle end.

d) Stoppage

- The O button stops the machine in its operation.

- An impulse on I engages another 1-minute 30’’ cycle.

Any other use than that described in this manual will not be

considered normal by the manufacturer.

T8E GB 06 2024
