TBM150 GB 02 2014

09/2021

Please refer to the numbered drawings

which correspond to the paragraph numbers of the instruction manual.

Contents

Introduction 1

Installation 1

Use, safety 3

Cleaning, hygiene and storage 4

Fault ﬁnding 4

Maintenance 5

Conformity with regulations 6

Introduction

1. DESCRIPTION1

• This turbo liquidiser is used to mix, liquidise, reduce and

emulsify vegetable and ﬁsh soups, fruit and vegetable purées,

liquid pastries and sauces, etc. directly in cooking containers.

It is mainly used in large catering and central kitchens and the

food preparation industries. Please ask for details on other ap-

plications.

A Trolley

B Handle

C Motor housing with

handles

D Body

E Hinge sleeve

F Body locking pin

G Rotating body locking knob

H Immersion tube

I Height adjustment handle

J Liquidising head

K Protection ring

L Stand

M Castors

Installation

2. DIMENSIONS - WEIGHT (for information only)1

- Gross weight when packaged : 220 kg

- Net weight equipped : 170 kg

- Dimensions of packaging L x l x H : 1780 x 840 x 1400 mm

- Machine dimensions: 1852 x 663 x 1475 mm

Handling – Transport

- The Turbo-Liquidizer is delivered on a wooden pallet.

- Use a forklift truck to remove it from the pallet, slipping the

forks beneath the trolley.

1.1

2.1

Introduction

The User Manual contains useful information for the user on

how to work correctly and in complete safety, and is designed

to make it easier to use the machine (called «machine» or

«appliance» below).

What follows is in no case intended to be a long list of warnings

and constraints, but rather a series of instructions meant to

improve the service provided by the machine in every respect,

and particularly to avoid a series of injuries or damage to equi-

pment that might result from inappropriate procedures for use

and management.

It is essential that all the people responsible for transporting,

installing, commissioning, using, maintaining, repairing or dismant-

ling the machine should consult this manual and read it carefully

before proceeding with the various operations, in order to avoid

any incorrect or inappropriate handling that might be result in

damage to the machine or put people’s safety at risk.

It is just as important that the Manual should always be available

to the operator and it should be kept carefully where the machine

is used ready for easy and immediate consultation in case of any

doubt, or in any case, whenever the need arises.

If after reading the Manual, there are still any doubts concerning

how to use the machine, please do not hesitate to contact the

Manufacturer or approved After Sales Service provider, who

is constantly available to ensure quick and careful service for

improved machine operation and optimum efﬁciency.

Note that the safety, hygiene and environmental protection stan-

dards currently applicable in the country where the machine is

installed must always be applied during all phases of machine

operation. Consequently it is the user’s responsibility to ensure

that the machine is operated and used solely under the optimum

safety conditions laid down for people, animals and property.

ATTENTION!!

Machine storage: -25°C to +50°C

Ambient temperature during operation: +4°C to +40°C

This machine is for professional use and must be used by staff trained to use, clean and maintain it, in terms or reliability and

safety.

Use the machine in adequately lit premises (See applicable technical standard for the country of use. In Europe, refer to standard

EN 12464-1)

When handling the machine, always check that the parts taken hold of are not mobile elements: risk of dropping and injury to the

lower limbs.

The machine is not designed for use in explosive atmospheres.

If unloaded manually, take all necessary precautions to ensure

the appliance does not tip at all

The reference language for these instructions is French.

•

Check that the voltage of the electrical system is the same

as that marked on the rating plate and the label on the power

cable.

•

The machine must be protected by a differential circuit breaker

and a fuse per phase of the rating shown in column of the H

characteristics.

•

: Electrical characteristics

B Number of phases (3 three phase)

C Nominal voltage in Volts (value, range or commutation)

D Frequency (Hertz)

E Motor speed (rpm)

F Nominal power (Watts)

G Nominal current (Amperes) depending on the voltage

H Rating of fuse protecting electrical line (Amperes)

I Approximate electrical consumption (Kwh)

•

Types of motor:

a) 230/400 V three phase motor - single speed:

- Provide a single phase wall socket with 3 phases + earth,

rating 20A and a matching watertight plug ﬁtted on the power

supply cable.

2.2a

•

Check the direction of rotation of the rotor: by means of the

arrow marked on the top of the liquidising head (anticlockwise

direction )

- If the direction of rotation is reversed, change over the two

phase wires on the plug.

2. ELECTRICAL CONNECTION2

ATTENTION!!

Connection to the electrical power supply must be done according to proper professional practice by a qualiﬁed and authorised

person (see current standards and legislation in the country of installation).

If an adapter is used on the socket, a check must be made that the electrical characteristics of this adapter are not lower than

those of the machine.

Do not use multiple plugs

The AC power supply to the machine must comply with the following conditions;

- Maximum voltage variation: ±5%

- Maximum frequency variation: ±1% on a continuous basis, ± 2% over short periods

ATTENTION: the electrical installation must comply (for design, creation and maintenance) with the legal and standard

requirements in the country where used.

- Check that the electric mains voltage, the value shown on the speciﬁcation plate.

- The machine’s electrical power supply must be protected against voltage surges (short-circuits and excess voltages) by using

fuses or thermal relays of the appropriate gauge relative to the place of installation and machine speciﬁcations – see the spe-

ciﬁcations shown in column H of ﬁgure 2.2a

ATTENTION: Concerning protection against indirect contact (depending on the type of power supply provided and

connection of the exposed conductive parts to the equipotential protection circuit), refer to point 6.3.3 of EN 60204-1 (IEC

60204-1) with the use of protection devices for automatic shut-off of power in the event of an insulation fault with a TN or

TT, system, or for the IT system, with the use of a permanent insulation or differentials controller for automatic shut-off.

The requirements of IEC 60364-4-41, 413.1 must apply for this protection.

For example: in a TT system, a differential circuit breaker must be installed upline of the power supply, with a suitable

power cut-off (e.g.: 30 mA) on the earthing installation for the place where it is planned to install the machine.

ATTENTION: Failure to comply with these instructions means the customer runs the risk of machine failure and/or acci-

dents due to direct or indirect contacts.

The machine must be earthed with a green / yellow wire.

b) Three phase motor - single voltage - 400 V or 230 V - 2 speed:.

- Cannot be switched over.

The machine must be earthed with a green / yellow wire.

To PAT test the Electrolux Range of Food Preparation Equipment,

the PCB board needs to be disconnected before any test is done.

This is due to the fact that the boards are ﬁtted with a grounding

diode that can give incorrect result during such a test. Also on a

standard appliance a ﬂash test of 25 amps and up to 3000v is

used but, as you would expect, to use this on equipment, which

has a printed circuit, board would be quite destructive to that

board. We would recommend the use of a PAT tester approved

for computer systems which use a lower rate of amps.

The appliance is perfectly safe and is CE certiﬁcated. There are

two ways to get overcome this problem.

· Disconnect the board as instructed and test using test for

PC’s,

· Or install the mixer on a fused spur (no plug) as this takes it

away from being a portable appliance and the PAT test is then

not needed.

TBM150 GB 09 2021
