Disclaimer and Warning
Please read this entire document and all safe and lawful practices
DJITM provided carefully before use. Failure to read and follow
instructions and warnings may result in serious injury to yourself or
others, damage to your DJI product, or damage to other objects in
the vicinity. By using this product, you hereby signify that you have
read this disclaimer and warning carefully and that you understand
and agree to abide by the terms and conditions herein. You agree
that you are solely responsible for your own conduct while using this
product, and for any consequences thereof. DJI accepts no liability for
damage, injury or any legal responsibility incurred directly or indirectly
from the use of this product.
DJI is a trademark of SZ DJI TECHNOLOGY CO., LTD. (abbreviated
as “DJI”) and its affiliated companies. Names of products, brands,
etc., appearing in this document are trademarks or registered
trademarks of their respective owner companies. This product and
document are copyrighted by DJI with all rights reserved. No part of
this product or document shall be reproduced in any form without the
prior written consent or authorization of DJI.
This document and all other collateral documents are subject
to change at the sole discretion of DJI. For up to date product
information, visit http://www.dji.com and click on the product page for
this product.
This disclaimer is available in various languages. In the event of
divergence among dierent versions, the English version shall prevail.
Introduction
The DJI FPV Propeller Guard is used to reduce harm to people and
damage to objects if there is a collision with the spinning propellers of
the aircraft. It is recommended to use the propeller guard in windless
environments or during indoor or low-speed ight.
Installation
1. Release the locks on the propeller guards. Check the mark on the
lock and connect the two propeller guards marked LF (Left Front)
and LB (Left Back).
2. With the rear of the aircraft facing toward you, attach the propeller
guards from underneath the extended frame arms on the left side.
Make sure the propeller guards form a complete guard around the
frame arms.
3. Close the locks. There will be a clicking sound indicating the lock
is secure.
4. Repeat the steps above to install the propeller guards on the right
side. The locks are marked RF (Right Front) and RB (Right Back).
The propulsion performance of the aircraft will be affected
after the propeller guards are attached. Fly with caution.
Specications
Weight (single) 21.8 g
Radius 95 mm
Installation Circumference 387 × 332 × 136 mm
