I N S T A L L A T I O N DE8310

Delayed Egress V1.6 Electromagnetic Locks

ISDE8310-V1-6

Installation Instructions

Pre-Installation Instructions

1. This product must be installed according to all applicable

building and life safety codes. All installations must be

approved by the Authority Having Jurisdiction (AHJ).

2. Due to the variety of mounting configurations available with

this product, a survey and assessment of the physical area

in which the product will be installed must be performed.

3. The door frame must be inspected and deemed structurally

sound prior to installation of the electromagnetic lock. The

structural integrity of the mounting surfaces must be strong

enough to meet or exceed the holding force of the product.

4. The product must be protected from potential damage due

to intruders or tampering.

5. The product should be installed in a location that will not

hinder or create a potential safety hazard to authorized

personnel accessing the protected area.

6. Because electromagnetic locks are used in a variety of

applications and different door frame configurations, an

experienced installer with knowledge of this product must

make a determination of the optimal mounting method for

this specific application.

7. The components, hardware, installation instructions and

mounting template included with this product are intended

for use on outswinging doors.

8. Do not install this product on the exterior of buildings.

9. Do not use as a doorstop. This will void warranty.

10. Separate accessories not included with this product must be

used in the following applications:

• Narrow head jamb situations or center-hung doors

• Wherever there is insufficient space on the door

frame header to mount the lock

• Hollow metal or wood frames where the door stop is

not thick enough to allow the product to be installed

• Wherever an obstruction in the door prevents

installation of the armature plate at a proper height

• Doors that do not permit the armature plate to be

mounted low enough to meet the magnet surface

Refer to the Product Accessories Guide section of

the Installation Instructions for further information.

Accessories may impact holding force.

11. Installation of this product should be done by an

experienced installer with knowledge of this product.

12. A mechanical latching device is required in conjunction

with the Delayed Egress 8310.

NOTE: It is highly recommended that thread locking compound

be applied to all screws during installation to reduce chance of

screws loosening over extended time.

PLEASE DELIVER ALL INSTALLATION INSTRUCTIONS TO

THE END-USER UPON COMPLETION OF THE INSTALLATION.

1. Mount the electromagnetic lock to the door frame as outlined

on the installation template included with the product.

Armature Plate Mounting Notes:

1) It is essential that this plate pivot slightly on the mounting bolt

to allow proper alignment with the magnet surface. If not aligned,

the lock may lose holding force or not lock at all.

2) The rubber washer on the head of the mounting bolt should

project slightly beyond the surface of the armature plate. It will

expand when power is removed and break the air vacuum between

the plate and magnet. If removed or trimmed, the lock will appear

to have some holding force even when power is removed.

For added safety, thread locking compound has been provided for

the armature plate bolt and the four captive electromagnetic lock

mounting screws.

WARNING: Improper installation, maintenance, inspection or

usage of the product or any related accessories or parts may cause

the electromagnetic lock, armature plate and associated hardware

to disengage and fall, causing serious bodily injury and property

damage. Rutherford Controls Int’l Inc. and/or Rutherford Controls

Int’l Corp. will not be liable to the installer, purchaser, end user

or anyone else for damage or injury to person or property due

to improper installation, care, storage, handling, maintenance,

inspection, abuse, misuse or act of God or nature involving this

product or any related accessories or parts.

2. Route the power supply connecting wire through the door

frame and into the wire access hole in the top of the magnet

housing. Connecting wire should be of sufficient gauge for

the lock being installed and the distance being run. See table

for current draw specifications and wiring gauge chart.

3. See system overview and switching options.

PCN16008

R03/17GR-2

DE8310 Delayed Egress V1.6 Electromagnetic Lock

Installation Instructions (Continued)

Delayed Egress System – Status Indicators

System Status Light Panel * Local Buzzer*** Local Alarm Relay Remote Alarm Relay

Door Open Red on OFF OFF OFF

Locked OFF OFF ONGreen on

Nuisance Delay

Period Red blinking (fast) Pulsing Sound ON ON

Release Delay Period Red blinking (slowly) Steady Sound ON OFF

Lock Release Red/Green blinking

alternately

Steady Sound

Until Reset ON OFF

Forced Open Red blinking (fast)** Pulsing Sound** ON OFF

Exit Switch to Open

(Authorized Exit) Red On OFF OFF OFF

* Light panel color may be inverted. See dip switch 8 settings.

** If forced open before the set release delay has lapsed, the buzzer/sounder can only be turned off, by

switching the system power off.

*** The DE8310S model has an internal buzzer. The base unit ships with an external sounder. See page 4 & 6.

Delayed Egress System – Overview

The Delayed Egress electromagnetic lock is a fail safe device.

In the normal condition with power, the door is locked, the local buzzer is off, the local SPDT relay is de-energized and the remote alarm

DPDT relay is energized.

The exit sequence is dip switch selectable for either pressure sensing on the door or a REX switch in the exit hardware (see Dip Switch 10-1). A

nuisance delay period can be set for 0, 1, 2 or 3 seconds as defined by the local building code. During this period the local buzzer will pulse and

the local alarm relay will be energized. If pressure on the door or hardware is released during this period the system returns to normal conditions.

This would be considered accidental triggering.

If the trigger is maintained for longer than the set nuisance delay, an irreversable release delay sequence begins. This release delay is for 15

seconds, but may be extended to 30 seconds with permission of the Authority Having Jurisdiction (AHJ). It includes the short nuisance delay.

Pressure is no longer required on the door. The remote relay de-energizes. The local buzzer changes from a pulse to steady.

The lock releases when the release delay time ends. The local buzzer remains on until reset and the local alarm relay will de-energize. The system

relock is defined by the local building code.

All installations must be approved by the local Authority Having Jurisdiction (AHJ).

The COM input/output is used to synchronize a pair of delayed egress maglocks, for use on double doors. Use the provided wire harness; yellow,

green and black. Configure DIP switch settings of both locks to the same to ensure proper operation.

Several building codes including the NFPA 101

Life Safety Code and the International Building

Code require the signage (shown left) to be

mounted on each door close to the releasing

device.

OPENED IN
