Side 1/19

EFLH2200

DSM and DSM2 are trademarks or registered trademarks of Horizon Hobby, Inc.

The Spektrum trademark is used with permission of Bachmann Industries, Inc.

Spektrum radios and accessories are exclusively available from Horizon Hobby, Inc.

E-flite® products are distributed exclusively by

Horizon Hobby, Inc.

4105 Fieldstone Road

Champaign, IL 61822

Multiple patents pending.

Horizon Hobby UK

Units 1-4, Ployters Road

Staple Tye —Southern Way

Harlow

Essex

CM187NS

United Kingdom

Horizon Hobby Deutschland GmbH

Otto Hahn Str. 9a

25337 Elmshorn

Germany

E-fliteRC.com

13412

Specifications

Length .................................................7.9 in (200mm)

Height .................................................4.7 in (120mm)

Main Rotor Diameter .............................7.5 in (190mm)

Weight with Battery ...............................1.0 oz (28 g)

Main Motor ..........................................Micro coreless (2 installed)

Battery .................................................1S 3.7V 110mAh LiPo (included)

Charger ................................................1S 3.7V DC LiPo (included)

Transmitter ..........................................MLP4DSM 2.4GHz DSM2 4-channel (included)

On-Board Electronics .............................5-in-1 receiver/servos/mixer/ESCs/gyro (installed)

RTF Instruction Manual

Introduction

As an ultra micro-sized version of the Blade ® CX/CX2, the Blade mCX offers

first-time pilots the ability to learn how to fly with ease and experienced

heli pilots the ability to fly anywhere, anytime. The Blade mCX offers

unsurpassed stability and incredible control through the coaxial, counter-

rotating head design and Spektrum™ 2.4GHz DSM2™ technology. And,

thanks to its rotor span of just 7.5 inches and one ounce flying weight, the

Blade mCX can be flown indoors almost anywhere—from an office to a

small bedroom or living room.

The Blade mCX comes 100% factory-assembled, flight-tested and ready

to fly right out of the box—no assembly or setup required. Included in the

box is the LiPo flight battery and convenient AA battery-powered DC LiPo

charger, 4-channel transmitter equipped with Spektrum 2.4GHz DSM2

technology, and 8 AA batteries (4 for the transmitter, 4 for the charger). The

DSM2 technology offers freedom from frequency restrictions and allows the

Blade mCX to be flown anywhere, anytime with full 4-channel control.

And although the Blade mCX is ready-to-fly right from the box, please take

the time to read through this manual for tips on battery safety and charging,

control checks and more before making your first flight. We also suggest

viewing the Instructional Video located on the product page for the Blade

mCX on www.e-fliterc.com.

Warning

An RC helicopter is not a toy! If misused, it can cause serious bodily harm

and damage to property. Fly only indoors, in open areas following all

instructions and as recommended in this manual. Keep loose items that

can get entangled in the rotor blades away from the main and tail blades,

including loose clothing, or other objects such as pencils and screwdrivers.

Especially keep your hands away from the rotor blades.

Table of Contents

Speciﬁcations ......................................................................................... 1

Introduction ............................................................................................ 3

Warning .................................................................................................. 3

Note on Lithium Polymer Batteries ............................................................ 4

Instructions for Disposal of WEEE by Users in the European Union ............ 4

Additional Safety Precautions and Warnings ............................................... 4

FCC Information ...................................................................................... 5

Blade MCX RTF Contents ......................................................................... 6

Additional Equipment ............................................................................... 6

Preparing for the First Flight Checklist ....................................................... 6

Flying Checklist ....................................................................................... 7

Battery Warnings and Guidelines ............................................................... 7

Battery Charging ................................................................................... 10

Installing the Transmitter Batteries .......................................................... 11

Installing the Flight Battery ..................................................................... 11

Transmitter Control Identiﬁcation ............................................................ 12

Control Test .......................................................................................... 13

5-in-1 Control Unit Description, Arming and Motor Control Test .................. 16

Understanding the Primary Flight Controls ............................................... 19

Dual Rates ............................................................................................ 22

Choosing a Flying Area .......................................................................... 23

Flying the Blade MCX ............................................................................. 24

Transmitter and Receiver Binding ............................................................ 26

Exploded View Parts Listing ................................................................... 27

Exploded View....................................................................................... 29

Replacement Parts List .......................................................................... 30

Optional Parts List ................................................................................. 31

Warranty Period .................................................................................... 31

Limited Warranty ................................................................................... 31

Damage Limits ...................................................................................... 32

Safety Precautions ................................................................................ 32

Questions, Assistance and Repairs ......................................................... 33

Inspections or Repairs ........................................................................... 33

Warranty Inspection and Repairs ............................................................. 34

Non-Warranty Repairs ............................................................................ 34

Product Registration .............................................................................. 35
