MS-010 Tripod Boom
User Manual
Specifications
Payload
Tube DimensionModel
MS-010
10kg / 22.0lbs
60cm / 23.6in 30mm / 1.2in
The E-IMAGE MS-010 Tripod Boom is made from high-grade aluminium alloy, it can mounts on
any column with 3/8" thread. On its total length of 600mm you can even mount up to four
devices.
Add: No.1230 South Cihai Rd,Luotuo Industry zone, Zhenhai, Ningbo, China. 315202
Tel: 86-574-86590031/86590061
E-mail: sales@eimagevideo.com
Visit for more informationwww.eimagevideo.com
NINGBO EIMAGE STUDIO EQUIPMENT CO., LTD
Contact Information
EIMAGE official QR code
1/4" Screw
1/4" Screw
3/8" Screw hole3/8" Screw 3/8" Screw
Locking wheel Locking wheel
Length Net Weight
1750g / 3.9lbs
In the Box
Manual
MS-010 p1-x1 User Guide p1-x1
Ensure that you adjust the MS-010 to the desired
position before installing the PTZ cameras.
After installing the cameras, securely lock them
in place to prevent any accidental camera drops.
*
Connect the M-PTZ-PEDESTAL Motorized Elevation System
1
Attach the MS-010 to the M-PTZ-PEDSTAL with a 3/8" screw through the bottom screw hole.
2
Install PTZ cameras on the MS-010 with 1/4" screw provided, allowing for the simultaneous mounting of two PTZ cameras.
3
Adjust PTZ camera placement by manipulating the locking knobs on the MS-010 (upright or upside-down).
Rotate the locking knob to release the lateral fasteners, can move it in horizontally and 360°
rotation in tilt.
360 rotation°
MS-010 Tripod Boom User Manual
