B85H3-M9 USER MANUAL

The information in this document is subject to change without notice. The

manufacturer makes no representations or warranties with respect to the contents

hereof and specifically disclaims any implied warranties of merchantability or

fitness for any particular purpose. The manufacturer reserves the right to revise this

publication and to make changes from time to time in the content hereof without

obligation of the manufacturer to notify any person of such revision or changes.

This equipment has been tested and found to comply with the limits for a Class B

digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to

provide reasonable protection against harmful interference in a residential

installation. This equipment generates, uses, and can radiate radio frequency

energy and, if not installed and used in accordance with the instructions, may cause

harmful interference to radio communications. However, there is no guarantee that

interference will not occur in a particular installation. If this equipment does cause

harmful interference to radio or television reception, which can be determined by

turning the equipment off and on, the user is encouraged to try to correct the

interference by one or more of the following measures:

•Reorient or relocate the receiving antenna

•Increase the separation between the equipment and the receiver

•Connect the equipment onto an outlet on a circuit different from that to

which the receiver is connected

•Consult the dealer or an experienced radio/TV technician for help

Shielded interconnect cables and a shielded AC power cable must be employed with

this equipment to ensure compliance with the pertinent RF emission limits

governing this device. Changes or modifications not expressly approved by the

system’s manufacturer could void the user’s authority to operate the equipment.

Federal Communications Commission (FCC)

Disclaimer

Declaration of Conformity

This device complies with part 15 of the FCC rules. Operation is subject to the follow-

ing conditions:

•This device may not cause harmful interference.

•This device must accept any interference received, including interference

that may cause undesired operation.

Limits and methods of mesurement of radio disturbance char-

acteristics of information technology equipment

EN 55022

EN 61000-3-2 Disturbances in supply systems caused

EN 61000-3-3 Disturbances in supply systems caused by household appli-

ances and similar electrical equipment “ Voltage fluctuations”

EN 55024 Information technology equipment-Immunity characteristics-

Limits and methods of measurement

EN 60950 Safety for information technology equipment including electri-

cal business equipment

CE marking



This device is in conformity with the following EC/EMC directives:

B85H3-M9 USER MANUAL

TABLE OF CONTENTS

Preface i

Brief Introduction 1

Specifications......................................................................................1

Motherboard Components................................................................3

Header Pin Definition and Jumper Settings.........................................4

I/O Ports...............................................................................................6

Multi-language Quick Installation Guide 7

English..................................................................................................7

Brazilian Portuguese..........................................................................9

Hindi....................................................................................................................11

French......................................................................................................13

Deutsch................................................................................................15

Russian................................................................................................17

Spanish................................................................................................19

Indonesian.............................................................................................21

Arabic.......................................................................................................23

Simplified Chinese...............................................................................25

Korean......................................................................................................27

Produkt Specifikationer

Mærke:	ECS
Kategori:	Bundkort
Model:	B85H3-M9
Bredde:	- mm
Dybde:	- mm
Antal HDMI-porte:	1
Ethernet LAN-porte (RJ-45):	1
Antal USB 2.0-porte:	2
Antal USB 3.2 Gen 1 (3.1 Gen 1) type-A-porte:	2
Ethernet LAN:	Ja
Lyd-output kanaler:	5.1 kanaler
Certificering:	CE/FCC, WHQL, WHCK
Strømkilde type:	ATX
Maksimal intern hukommelse:	16 GB
Medfølgende software:	ECS Intelligent EZ Utility : eBLU, eDLU, eSF\r\nNorton Internet Security, CyberLink PowerDVD, CyberLink PowerDirector 9
Processorproducent:	Intel
Drivere inkluderet:	Ja
Antal VGA-porte (D-sub):	1
Ethernet-grænsefladetype:	Fast Ethernet,Gigabit Ethernet
Prøvesoftware:	Muzee
Komponent til:	PC
Antal PS/2-porte:	2
Processor sokkel:	LGA 1150 (stik H3)
Systembus-hastighed:	5 GT/s
DirectX-version:	11.1
Kompatibel processor serie:	Intel Celeron,Intel Pentium
Bundkort chipset familie:	Intel
Bundkort chipsæt:	Intel® B85
Understøttede hukommelsestyper:	DDR3-SDRAM
Antal hukommelsesstik:	2
Hukommelses slots type:	DIMM
Ikke-fejlkorrigerende kode:	Ja
Understøttede hukommelsesclock-hastigheder:	1600 Mhz
Ikke-bufferet hukommelse:	Ja
Antal SATA III-stik:	4
LAN Kontroller:	Realtek RTL8111G
Hukommelseskanaler:	Dual-channel
USB 2.0-stik:	2
USB 3.2 Gen 1 (3.1 Gen 1) stik:	1
S/PDIF-udgangsstik:	Ja
CPU-ventilatorstik:	Ja
ATX strømstrik (24 stikben):	Ja
Indbrudsttik til kabinet:	Ja
Lydstik på frontpanel:	Ja
Motherboard form faktor:	micro ATX
Understøttede lagerdrev brugerflader:	SATA,SATA II,SATA III
BIOS-type:	AMI
BIOS-hukommelsesstørrelse:	64 Mbit
Nulstil CMOS-jumper:	Ja
Wake-on-LAN klar:	Ja
Strømstik til ventilator:	Ja
PCI Ekspres x16 (Gen 3.x) slots:	1
Maksimalt antal SMP-processorer:	1
PCI Ekspres x1 (Gen 2.x) slots:	1
Intel® Core i3/i5/i7/i9 serie:	i3-4xxx,i5-4xxx,i7-4xxx
