BAT-I USER MANUAL

Preface

This publication, including all photographs, illustrations and software, is protected

any of the material contained herein, may be reproduced without written consent of

the author.

Version 1.0

Disclaimer

The information in this document is subject to change without notice. The manufac-

turer makes no representations or warranties with respect to the contents hereof

and specifically disclaims any implied warranties of merchantability or fitness for

any particular purpose. The manufacturer reserves the right to revise this publica-

tion and to make changes from time to time in the content hereof without obligation

of the manufacturer to notify any person of such revision or changes.

Trademark Recognition

Microsoft, MS-DOS and Windows are registered trademarks of Microsoft Corp.

MMX, Pentium, Pentium-II, Pentium-III, Celeron are registered trademarks of Intel

Corporation.

Other product names used in this manual are the properties of their respective owners

and are acknowledged.

Federal Communications Commission (FCC)

This equipment has been tested and found to comply with the limits for a Class B

digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to

provide reasonable protection against harmful interference in a residential instal-

lation. This equipment generates, uses, and can radiate radio frequency energy and,

if not installed and used in accordance with the instructions, may cause harmful

interference to radio communications. However, there is no guarantee that interfer-

ence will not occur in a particular installation. If this equipment does cause harmful

interference to radio or television reception, which can be determined by turning

the equipment off and on, the user is encouraged to try to correct the interference by

one or more of the following measures:

•Reorient or relocate the receiving antenna

•Increase the separation between the equipment and the receiver

•Connect the equipment onto an outlet on a circuit different from that to

which the receiver is connected

•Consult the dealer or an experienced radio/TV technician for help

Shielded interconnect cables and a shielded AC power cable must be employed with

this equipment to ensure compliance with the pertinent RF emission limits govern-

ing this device. Changes or modifications not expressly approved by the system’s

manufacturer could void the user’s authority to operate the equipment.

BAT-I USER MANUAL

Declaration of Conformity

This device complies with part 15 of the FCC rules. Operation is subject to the follow-

ing conditions:

•This device may not cause harmful interference.

•This device must accept any interference received, including interference

that may cause undesired operation.

Canadian Department of Communications

This class B digital apparatus meets all requirements of the Canadian Interference-

causing Equipment Regulations.

Cet appareil numérique de la classe B respecte toutes les exigences du Réglement

sur le matériel brouilieur du Canada.

The manual consists of the following:

Describes features of the

motherboard.

page 1

Describes installation of

motherboard components.

page 7

page 23

page 51

Installing the Motherboard

Introducing the Motherboard

Provides information on us-

ing the BIOS Setup Utility.

Describes the motherboard

software.

Limits and methods of mesurement of radio disturbance char-

acteristics of information technology equipment

EN 55022

EN 61000-3-2 Disturbances in supply systems caused

EN 61000-3-3 Disturbances in supply systems caused by household appli-

ances and similar electrical equipment “ Voltage fluctuations”

EN 55024 Information technology equipment-Immunity characteristics-

Limits and methods of measurement

EN 60950 Safety for information technology equipment including electri-

cal business equipment

CE marking

About the Manual



This device is in conformity with the following EC/EMC directives:

Chapter 4

Chapter 1

Chapter 2

Chapter 3

Using BIOS

Using the Motherboard Software

Chapter 5

Trouble Shooting

Provides basic trouble shoot-

ing tips.

page 55



Produkt Specifikationer

Mærke:	ECS
Kategori:	Bundkort
Model:	BAT-I (V1.0)
Bredde:	170 mm
Dybde:	170 mm
Antal HDMI-porte:	1
Ethernet LAN-porte (RJ-45):	1
Antal USB 2.0-porte:	4
Antal USB 3.2 Gen 1 (3.1 Gen 1) type-A-porte:	1
Ethernet LAN:	Ja
Lyd-output kanaler:	5.1 kanaler
Certificering:	CE/FCC, ErP/EuP, WHQL, WHCK
Strømkilde type:	ATX
Maksimal intern hukommelse:	8 GB
On-board grafikkort:	Ja
Mikrofonindgang:	Ja
Medfølgende software:	Norton Internet Security , CyberLink PowerDVD, CyberLink PowerDirector 9
Understøttede Windows-operativsystemer:	Windows 8 Enterprise x64, Windows 8 Pro x64, Windows 8 x64
Processorproducent:	Intel
Processormodel:	J1800
Antal VGA-porte (D-sub):	1
Ethernet-grænsefladetype:	Gigabit Ethernet
Prøvesoftware:	Muzee
Komponent til:	PC
Grafikadapter:	HD Graphics
Kølingstype:	Passiv
Antal PS/2-porte:	1
Processor sokkel:	BGA 1170
Understøttelse af parallel behandlingsteknologi:	Ikke understøttet
DirectX-version:	11
Kompatibel processor serie:	Intel® Celeron®
Bundkort chipset familie:	Intel
Lydchip:	VIA VT1705
Understøttede hukommelsestyper:	DDR3-SDRAM
Antal hukommelsesstik:	1
Hukommelses slots type:	SO-DIMM
Understøttede hukommelsesclock-hastigheder:	1333,1600 MHz
LAN Kontroller:	Realtek 8111G
USB 2.0-stik:	1
CPU-ventilatorstik:	Ja
Lydstik på frontpanel:	Ja
Antal SATA II stik:	2
Motherboard form faktor:	mini ITX
Understøttede lagerdrev brugerflader:	SATA II
BIOS-type:	AMI
BIOS-hukommelsesstørrelse:	64 Mbit
ACPI-version:	5.0
Intel® Virtualization Teknologi (Intel® VT):	VT-x
Strømstik til ventilator:	Ja
Maksimalt antal SMP-processorer:	1
Antal understøttede skærme:	2
Grafikadapter familie:	Intel
Parallelt stik:	Ja
PCI Ekspres x1 (Gen 2.x) slots:	1
Seriel port overskrifter:	1
Mini PCI ekspres slots:	1
