ECS BAT-I2 Manual (126 Sider)

USER GUIDE

Version:1.0B

40-012-KB3102

®

BAT-I2 USER MANUAL

i

Preface

Copyright

This publication, including all photographs, illustrations and software, is protected

any of the material contained herein, may be reproduced without written consent of

the author.

Version 1.0B

Disclaimer

The information in this document is subject to change without notice. The manufac-

turer makes no representations or warranties with respect to the contents hereof

and specifically disclaims any implied warranties of merchantability or fitness for

any particular purpose. The manufacturer reserves the right to revise this publica-

tion and to make changes from time to time in the content hereof without obligation

of the manufacturer to notify any person of such revision or changes.

Trademark Recognition

Microsoft, MS-DOS and Windows are registered trademarks of Microsoft Corp.

MMX, Pentium, Pentium-II, Pentium-III, Celeron are registered trademarks of Intel

Corporation.

Other product names used in this manual are the properties of their respective owners

and are acknowledged.

Federal Communications Commission (FCC)

This equipment has been tested and found to comply with the limits for a Class B

digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to

provide reasonable protection against harmful interference in a residential instal-

lation. This equipment generates, uses, and can radiate radio frequency energy and,

if not installed and used in accordance with the instructions, may cause harmful

interference to radio communications. However, there is no guarantee that interfer-

ence will not occur in a particular installation. If this equipment does cause harmful

interference to radio or television reception, which can be determined by turning

the equipment off and on, the user is encouraged to try to correct the interference by

one or more of the following measures:

•Reorient or relocate the receiving antenna

•Increase the separation between the equipment and the receiver

•Connect the equipment onto an outlet on a circuit different from that to

which the receiver is connected

•Consult the dealer or an experienced radio/TV technician for help

Shielded interconnect cables and a shielded AC power cable must be employed with

this equipment to ensure compliance with the pertinent RF emission limits govern-

ing this device. Changes or modifications not expressly approved by the system’s

manufacturer could void the user’s authority to operate the equipment.

BAT-I2 USER MANUAL

ii

Declaration of Conformity

This device complies with part 15 of the FCC rules. Operation is subject to the follow-

ing conditions:

•This device may not cause harmful interference.

•This device must accept any interference received, including interference

that may cause undesired operation.

Canadian Department of Communications

This class B digital apparatus meets all requirements of the Canadian Interference-

causing Equipment Regulations.

Cet appareil numérique de la classe B respecte toutes les exigences du Réglement

sur le matériel brouilieur du Canada.

The manual consists of the following:

Describes features of the

motherboard.

Hpage 1

Describes installation of

motherboard components.

Hpage 7

Hpage 25

Hpage 51

Installing the Motherboard

Introducing the Motherboard

Provides information on us-

ing the BIOS Setup Utility.

Describes the motherboard

software.

Limits and methods of mesurement of radio disturbance char-

acteristics of information technology equipment

EN 55022

EN 61000-3-2 Disturbances in supply systems caused

EN 61000-3-3 Disturbances in supply systems caused by household appli-

ances and similar electrical equipment “ Voltage fluctuations”

EN 55024 Information technology equipment-Immunity characteristics-

Limits and methods of measurement

EN 60950 Safety for information technology equipment including electri-

cal business equipment

CE marking

About the Manual



This device is in conformity with the following EC/EMC directives:

Chapter 4

Chapter 1

Chapter 2

Chapter 3

Using BIOS

Using the Motherboard Software

Chapter 5

Trouble Shooting

Provides basic trouble shoot-

ing tips.

page 55

H

BAT-I2 USER MANUAL

iv

Chapter 4 51

Using the Motherboard Software 51

Auto-installing under Win 7 x64/Win8.1 x86/x64/

Win10 x86/x64.........................................................................51

Running Setup.........................................................................51

Manual Installation..........................................................................53

ECS Utility Software (Intelligent EZ Utility) (Optional).................53

Chapter 5 55

Trouble Shooting 55

Start up problems during assembly..............................................55

Start up problems after prolong use............................................56

Maintenance and care tips..............................................................56

Basic Troubleshooting Flowchart...................................................57

1

BAT-I2 USER MANUAL

Chapter 1

Introducing the Motherboard

Introduction

Thank you for choosing the BAT-I2 motherboard. This motherboard is a high perfor-

mance, enhanced function. This motherboard has onboard Intel® Bay Trail-D J1800/

J1900/J2900 SOC for high-end business or personal desktop markets.

It supports up to 8 GB of system memory with single channel DDR3 1333MHz

SO-DIMM. It supports one mini PCI Express slot for extending usage (the mini PCIE

supports half-card and you can install a wireless card for it).

It implements an EHCI (Enhanced Host Controller Interface) compliant interface that

provides eight or nine USB 2.0 ports (four USB 2.0 ports at the rear panel and two USB

2.0 headers support additional four USB 2.0 ports and one 5-pin USB 2.0 header

(optional) supports one USB 2.0 port ) and one USB 3.0 port (one USB 3.0 port or one

5-pin USB 2.0 header supports one USB 2.0 port at the rear panel).

The motherboard is equipped with advanced full set of I/O ports in the rear panel,

including one DC_IN port (optional), PS/2 Keyboard & PS/2 Mouse connectors, one

USB 3.0 port(or one 5-pin USB 2.0 header supports one USB 2.0 port), four USB 2.0

ports, one RJ45 LAN connector, one D-sub (VGA) port, one HDMI port and audio jacks

for line-in, line-out and microphone.

In addition, this motherboard supports two SATA 3Gb/s connectors for expansion.

Your motherboard package ships with the following items:

Package Contents

BAT-I2 Motherboard

User Manual

DVD

I/O Shield

2 SATA Cables



Accessories may vary, please refer to actual goods you purchase.

Chapter 1

2

BAT-I2 USER MANUAL

SOC

Specifications

• Signal channel DDR3 SO-DIMM memory architecture

• 1 x 204-pin DDR3 SO-DIMM socket supports up to 8 GB

• Supports DDR3 1333 MHz DDR3 SDRAM

Memory

• 1 x mini PCI Express slot

(the mini PCIE (half-card) supports extension cards with PCIE

signal

• Supported by Intel® Bay Trail-D J1800/J1900/J2900 SOC

- 2 x Serial ATA 3Gb/s devices

Expansion

Slots

Storage

• 1 x PS/2 Keyboard & PS/2 Mouse connectors

• 1 x USB 3.0 port(or one 5-pin USB 2.0 header)

• 4 x USB 2.0 ports

• 1 x RJ45 LAN connector

• 1 x D-sub (VGA) port

• 1 x HDMI port

• 1 x Audio port (1 x line-in, 1 x line-out, 1 x Microphone)

Rear Panel I/O

LAN • Realtek 8111G Gigabit LAN (or RTL8106E 10/100 LAN)

• Realtek ALC662 Codec

- 6 Channel High Definition Audio Codec

- Compliant with HD audio specification

Audio

• Onboard Intel® Bay Trail-D J1800/J1900/J2900 SOC

• 1 x 24-pin ATX Power Supply connector (optional)

• 1 x 4-pin 19V power connector (optional)

• 1 x 4-pin CPU_FAN connector

• 1 x 4-pin SYS_FAN connector

• 2 x USB 2.0 header support additional four USB 2.0 ports

• 1 x USB 3.0 port or 1 x 5-pin USB 2.0 header supports one

USB 2.0 port (optional)

• 2 x Serial ATA 3Gb/s connectors

• 1 x BZ

• 1 x Front Panel switch/LED header

• 1 x Front Panel audio header

• 1 x Clear CMOS jumper

• 1 x BKLT_PWR jumper (optional)

• 1 x LVDS select jumper (LCD_PWR) (optional)

• 1 x LVDS connector (optional)

• 1 x LVDS brightness control header (DISP_BRT) (optional)

• 1 x LPT header

• 2 x COM headers

• 1 x LDC header

• 1 x Case open header

• 1 x SATA power connector (optional)

Internal I/O

Connectors &

Headers

Note: Please go to ECS website for the latest CPU support list.

Note: Please go to ECS website for the latest Memory support list.

• 1 x DC_IN port (optional)

3

BAT-I2 USER MANUAL

Chapter 1

System BIOS

Form Factor • Mini ITX Size, 170mm x 170mm

• AMI BIOS with 64Mb SPI Flash ROM

- Supports Plug and Play

- Supports ACPI & DMI

- Supports STR (S3) /STD (S4)

- Supports Hardware monitor

- Audio, LAN, can be disabled in BIOS

• Supports eBLU*1/eDLU/eSF

• 3rd Party Bundled Software: Cyberlink*2 /Norton*2/Muzee*2

Ap/ Bundled

Software

Support

- F7 hot key for boot up devices option

- Supports PgUp clear CMOS Hotkey (Has PS2 KB Model only)

- Supports Dual Display

- Supports Multi-Language

- Supports AC’97/HD Audio auto detect (default)

Note: *1Microsoft .NET Framework 3.5 is required.

*2Free bundle software is including ECS DVD: Cyberlink/

Norton/Muzee

5

BAT-I2 USER MANUAL

Chapter 1

Table of Motherboard Components

LABEL COMPONENTS

1. ATX_PWR Standard 24-pin ATX power connector (optional)

2. CPU_FAN 4-pin CPU cooling fan connector

3. CLR_CMOS Clear CMOS jumper

4. DIMM1 204-pin DDR3 SDRAM SO-DIMM

5. CASE Case open header

6. COM1~2 Onboard serial port headers

7. LDC Debug card header

8. LPT Onboard parallel port header

9. SYS_FAN 4-pin system cooling fan connector

10. F_PANEL Front panel switch/LED header

11. DISP_BRT LVDS brightness control header (optional)

12. LVDS LVDS connector (optional)

13. BKLT_PWR Backlight power jumper (optional)

14. LCD_PWR LVDS select jumper (optional)

15. BZ Buzzer

16. MINIPCIE mini PCIE (half card) slot

17. SATA_PWR SATA power connector (optional)

18. F_AUDIO Front panel audio header

19. SATA1~2 Serial ATA 3Gb/s connectors

20. F_USB1~2 Front panel USB 2.0 headers

21. ATX19V 4-pin +19V power connector (optional)

Chapter 1

6

BAT-I2 USER MANUAL

I/O Ports

2. PS/2 Mouse (green)

Use the upper PS/2 port to connect a PS/2 mouse.

LAN LED Status Description

OFF No data

Orange blinking Active

OFF No link

Green Link

Activity LED

Link LED

LAN Port

3. PS/2 Keyboard (purple)

Use the lower PS/2 port to connect a PS/2 keyboard.

4. USB 3.0 Port (or one 5-pin USB 2.0 header supports one USB 2.0 port )

Use the USB 3.0/2.0 port to connect USB 3.0/2.0 device.

5. USB 2.0 Ports

Use the USB 2.0 ports to connect USB 2.0 devices.

6. LAN Port

Connect an RJ-45 jack to the LAN port to connect your computer to the Network.

8. HDMI Port

You can connect the display device to the HDMI port.

7. VGA Port

Connect your monitor to the VGA port.

9. Line-in (blue)

It can be connected to an external CD/DVD player, Tape player or other audio

devices for audio input.

10. Line-out (lime)

It is used to connect to speakers or headphones.

11. Microphone (pink)

It is used to connect to a microphone.

1. DC_IN Port (optional)

Connect the DC_IN port to the power adapter.

or

BAT-I2 USER MANUAL

7

Chapter 2

Installing the Motherboard

2-1. Safety Precautions

2-2. Installing the motherboard in a Chassis

This motherboard carries a Mini ITX form factor of 170 x 170 mm. Choose a chassis

that accommodates this form factor. Make sure that the I/O template in the chassis

matches the I/O ports installed on the rear edge of the motherboard. Most system

chassis have mounting brackets installed in the chassis, which corresponds to the

holes in the motherboard. Place the motherboard over the mounting brackets and

secure the motherboard onto the mounting brackets with screws.

Follow these safety precautions when installing the motherboard:

• Wear a grounding strap attached to a grounded device to avoid damage

from static electricity.

• Discharge static electricity by touching the metal case of a safely grounded

object before working on the motherboard.

• Leave components in the static-proof bags.

• Always remove the AC power by unplugging the power cord from the power

outlet before installing or removing the motherboard or other hardware

components.

Do not over-tighten the screws as this can stress the motherboard.

BAT-I2 USER MANUAL

9

Chapter 2

2. LCD_PWR: LVDS Select Jumper (optional)

3. BKLT_PWR: Backlight Select Jumper (optional)

BAT-I2 USER MANUAL

10

Chapter 2

2-4-1. Installing Memory Modules

• This motherboard accommodates one memory module. It can support

one 204-pin DDR3 1333.

• Do not remove any memory module from its antistatic packaging until

you are ready to install it on the motherboard. Handle the modules only

by their edges. Do not touch the components or metal parts. Always wear

a grounding strap when you handle the modules.

• You must install one module in the slot. Total memory capacity is 8 GB.

• Refer to the following to install the memory modules.

Install the DIMM module into the slot and press it firmly down until it

seats correctly. Check that the cutouts on the DIMM module edge

connector match the notches in the DIMM slot.

2-4. Installing Hardware

DIMM1

BAT-I2 USER MANUAL

11

Chapter 2

2-4-2. Installing Add-on Cards

The slots on this motherboard are designed to hold expansion cards and connect

them to the system bus. Expansion slots are a means of adding or enhancing the

motherboard’s features and capabilities. With these efficient facilities, you can

increase the motherboard’s capabilities by adding hardware that performs tasks

that are not part of the basic system.

Before installing an add-on card, check the documentation for the card

carefully. If the card is not Plug and Play, you may have to manually

configure the card before installation.

miniPCIE

Slot

The mini PCIE (half-card) supports extension cards with PCIE signal.

BAT-I2 USER MANUAL

14

Chapter 2

2. COM1~2: Onboard Serial Port Headers

Connect serial port extension brackets to these headers to add serial ports to your

system.

3. LDC: Debug Card Header

BAT-I2 USER MANUAL

16

Chapter 2

6. LVDS: LVDS Connector (optional)

1. You can connect the large end of the cable to the LED panel, and connect

the other small end to the slot on the motherboard.

2. Due to the chipset limitation, using dual displays LVDS(AIO) + VGA or

LVDS(AIO) + HDMI will cause the problem that you may not enter BIOS setup

or have the display problem.

BAT-I2 USER MANUAL

18

Chapter 2

If you use AC’ 97 Front Panel, please don’ t tick off “Using Front Jack Detect ”. If you

use HD Audio Front Panel, please t “ ”.ick off the option of Using Front Jack Detect

* For reference only

SATA 1~2 connectors support the Serial ATA 3Gb/s device, simpler disk drive cabling

and easier PC assembly. It eliminates limitations of the current Parallel ATA

interface. But maintains register compatibility and software compatibility with

Parallel ATA.

8. SATA1~2: Serial ATA Connectors

BAT-I2 USER MANUAL

19

Chapter 2

The motherboard has one USB 2.0 header supporting two USB 2.0 ports.

Additionally, some computer cases have USB 2.0 ports at the front of the case. If you

have this kind of case, use auxiliary USB 2.0 connector to connect the front-mounted

ports to the motherboard.

9. F_USB1~2: Front Panel USB 2.0 Headers

Please make sure that the USB cable has the same pin assignment as

indicated above. A different pin assignment may cause damage or system

hang-up.

BAT-I2 USER MANUAL

20

Chapter 2

2-4-4. Installing a SATA Hard Drive

This section describes how to install a SATA Hard Drive.

About SATA Connectors

Your motherboard features two SATA connectors supporting a total of two drives.

SATA refers to Serial ATA (Advanced Technology Attachment) is the standard

interface for the IDE hard drives which are currently used in most PCs. These

connectors are well designed and will only fit in one orientation. Locate the SATA

connectors on the motherboard and follow the illustration below to install the SATA

hard drives.

Installing Serial ATA Hard Drives

To install the Serial ATA (SATA) hard drives, use the SATA cable that supports the Serial

ATA protocol. This SATA cable comes with a SATA power cable. You can connect either

end of the SATA cable to the SATA hard drive or the connector on the motherboard.

Refer to the illustration below for proper installation:

1 Attach either cable end to the connector on the motherboard.

2 Attach the other cable end to the SATA hard drive.

3 Attach the SATA power cable to the SATA hard drive and connect the other

end to the power supply.

* For reference only

BAT-I2 USER MANUAL

21

Chapter 2

After you have installed the motherboard into a case, you can begin connecting the

motherboard components. Refer to the following:

2-4-5. Connecting Case Components

No. Components No. Components

1 ATX_POWER (optional) 4 F_PANEL

2 CPU_FAN 5 SATA_PWR (optional)

3 SYS_FAN 6 ATX19V (optional)

1 & 6. ATX_POWER (ATX 24-pin Power Connector) (optional) & ATX19V

(ATX19V Power Connector) (optional)

Connect the standard power supply connector to ATX_POWER.

Connect the auxiliary case power supply connector to ATX19V.

BAT-I2 USER MANUAL

22

Chapter 2

4. F_PANEL: Front Panel Header

The front panel header (F_PANEL) provides a standard set of switch and LED headers

commonly found on ATX or Micro ATX cases. Refer to the table below for information:

2 & 3. CPU_FAN (CPU Cooling FAN Power Connector) & SYS_FAN (System

Cooling FAN Power Connector)

Users please note that the fan connector supports the CPU cooling fan of 1.1A

~ 2.2A (26.4W max) at +12V.

Connect the CPU cooling fan cable to CPU_FAN.

Connect the system cooling fan connector to SYS_FAN.

BAT-I2 USER MANUAL

23

Chapter 2

This concludes Chapter 2. The next chapter covers the BIOS.

Hard Drive Activity LED

Connecting pins 1 and 3 to a front panel mounted LED provides visual indication that

data is being read from or written to the hard drive. For the LED to function properly,

an IDE drive should be connected to the onboard IDE interface. The LED will also

show activity for devices connected to the SCSI (hard drive activity LED) connector.

Power/Sleep/Message waiting LED

Connecting pins 2 and 4 to a single or dual-color, front panel mounted LED provides

power on/off, sleep, and message waiting indication.

Reset Switch

Supporting the reset function requires connecting pin 5 and 7 to a momentary-con-

tact switch that is normally open. When the switch is closed, the board resets and

runs POST.

Power Switch

Supporting the power on/off function requires connecting pins 6 and 8 to a momen-

tary-contact switch that is normally open. The switch should maintain contact for at

least 50 ms to signal the power supply to switch on or off. The time requirement is

due to internal de-bounce circuitry. After receiving a power on/off signal, at least

two seconds elapses before the power supply recognizes another on/off signal.

5. SATA_PWR: SATA power connector (optional)

BAT-I2 USER MANUAL

25

Chapter 3

About the Setup Utility

The computer uses the latest “American Megatrends Inc. ” BIOS with support for

Windows Plug and Play. The CMOS chip on the motherboard contains the ROM setup

instructions for configuring the motherboard BIOS.

The BIOS (Basic Input and Output System) Setup Utility displays the system’s

configuration status and provides you with options to set system parameters. The

parameters are stored in battery-backed-up CMOS RAM that saves this information

when the power is turned off. When the system is turned back on, the system is

configured with the values you stored in CMOS.

The BIOS Setup Utility enables you to configure:

• Hard drives, diskette drives and peripherals

• Video display type and display options

• Password protection from unauthorized use

• Power Management features

The settings made in the Setup Utility affect how the computer performs. Before

using the Setup Utility, ensure that you understand the Setup Utility options.

This chapter provides explanations for Setup Utility options.

The Standard Configuration

A standard configuration has already been set in the Setup Utility. However, we rec-

ommend that you read this chapter in case you need to make any changes in the

future.

This Setup Utility should be used:

• when changing the system configuration

• when a configuration error is detected and you are prompted to make

changes to the Setup Utility

• when trying to resolve IRQ conflicts

• when making changes to the Power Management configuration

• when changing the password or making other changes to the Security

Setup

Entering the Setup Utility

When you power on the system, BIOS enters the Power-On Self Test (POST) routines.

POST is a series of built-in diagnostics performed by the BIOS. After the POST routines

are completed, the following message appears:

Press DEL to enter SETUP

Chapter 3

Using BIOS

BAT-I2 USER MANUAL

26

Chapter 3

Press the delete key to access BIOS Setup Utility.

Using BIOS

When you start the Setup Utility, the main menu appears. The main menu of the

Setup Utility displays a list of the options that are available. A highlight indicates

which option is currently selected. Use the cursor arrow keys to move the highlight

to other options. When an option is highlighted, execute the option by pressing

<Enter>.

Some options lead to pop-up dialog boxes that prompt you to verify that you wish to

execute that option. Other options lead to dialog boxes that prompt you for

information.

Some options (marked with a triangle ) lead to submenus that enable you to change

the values for the option. Use the cursor arrow keys to scroll through the items in the

submenu.

Resetting the Default CMOS Values

When powering on for the first time, the POST screen may show a “CMOS Settings

Wrong” message. This standard message will appear following a clear CMOS data

at factory by the manufacturer. You simply need to Load Default Settings to reset

the default CMOS values.

Note: Changes to system hardware such as different CPU, memories, etc. may

also trigger this message.



BIOS Information

System Language [English]

System Date [Wed 11/27/2013]

System Time [00:00:09]

+/- :Change Opt.

Enter : Select

F1:General Help



Choose the system default

language.



:Select Screen

:Select Item

F2:Previous Values

F3:Optimized Defaults

F4:Save & Exit

ESC:Exit

Main Advanced Chipset M.I.B III Security Boot Exit

BAT-I2 USER MANUAL

27

Chapter 3

The default BIOS setting for this motherboard apply for most conditions

with optimum performance. We do not suggest users change the default

values in the BIOS setup and take no responsibility to any damage caused

by changing the BIOS settings.

BIOS Navigation Keys

The BIOS navigation keys are listed below:

KEY FUNCTION

Scrolls through the items on a menu

+/- Modifies the selected field’s values

F2 Previous Values

F3 Optimized Defaults

F1 General Help

ESC Exits the current menu



Enter Select

In this manual, default values are enclosed in parenthesis. Submenu items are

denoted by a triangle .

F4 Save & Exit

For the purpose of better product maintenance, the manufacture reserves

the right to change the BIOS items presented in this manual. The BIOS setup

screens shown in this chapter are for reference only and may differ from

the actual BIOS. Please visit the manufacture’s website for updated

manual.



BAT-I2 USER MANUAL

28

Chapter 3

System Language (English)

This item is used to set the language.

System Date & Time

The Date and Time items show the current date and time on the computer. If you are

running a Windows OS, these items are automatically updated whenever you make

changes to the Windows Date and Time Properties utility.

The Advanced menu items allow you to change the settings for the CPU and other

system.

Advaned Menu

LAN Configuration

PC Health Status

Power Management Setup

PCI Express Configuration

ACPI Settings

CPU Configuration

SATA Configuration

USB Configuration

Inetl (R) Smart Connect Technology

Super IO Configuration

+/- : Change Opt.

Enter : Select

F1:General Help

 

LAN Configuration Parameters



:Select Screen

:Select Item

F2:Previous Values

F3:Optimized Defaults

F4:Save & Exit

ESC:Exit























Main Advanced Chipset M.I.B III Security Boot Exit









When you enter the BIOS Setup program, the main menu appears, giving you an

overview of the basic system information. Select an item and press <Enter> to

display the submenu.

Main Menu

BIOS Information

System Language [English]

System Date [Wed 11/27/2013]

System Time [00:00:09]

+/- :Change Opt.

Enter : Select

F1:General Help

 

Choose the system default

language.



:Select Screen

:Select Item

F2:Previous Values

F3:Optimized Defaults

F4:Save & Exit

ESC:Exit

Main Advanced Chipset M.I.B III Security Boot Exit

BAT-I2 USER MANUAL

29

Chapter 3

Onboard LAN Controller (Enabled)

Use this item to enable or disable the Onboard LAN.

LAN Configuration

The item in the menu shows the LAN-related information that the BIOS

automatically detects.

LAN Configuration

Onboard LAN Controller [Enabled]

Network Stack [Disabled]

+/- : Change Opt.

Enter : Select

F1:General Help

 

Enable/Disable Onboard LAN 1

Controller



:Select Screen

:Select Item

F2:Previous Values

F3:Optimized Defaults

F4:Save & Exit

ESC:Exit

Press <Esc> to return to the Advanced Menu page.

Network Stack (Disabled)

Use this item to enable or disable the UEFI Network Stack.

Main Advanced Chipset M.I.B III Security Boot Exit

BAT-I2 USER MANUAL

30

Chapter 3



PC Health Status

On motherboards support hardware monitoring, this item lets you monitor the

paremeters for critical voltages, temperatures and fan speeds.

System Temperature : 27°C

CPU Fan Speed : 3214 RPM

System Fan Speed : 0 RPM

CPU Voltage : 1.056V

DIMM Voltage : 1.380V

TCC Activation Temperature (DTS) 35

Smart Fan Function



PC Health Status

Main Advanced Chipset M.I.B III Security Boot Exit

CPU/System Smart FAN Control (Enabled)

This item allows you to enable or disable the control of the CPU/system fan speed by

changing the fan voltage.

Scroll to this item and press <Enter> to view the following screen:

Smart Fan Function

CPU Smart Fan Control [Enabled]

Smart Fan Mode [Normal]

Smart Fan start PWM value 180

Smart Fan start PWM TEMP(DTS) 70

DeltaT +3

Smart Fan Slope PWM value 10 PWM value/unite

CPU Fan Full Speed Offset (DTS) 77

System Smart Fan Control [Enabled]

Smart Fan Mode [Normal]

Smart Fan start PWM value 180

Smart Fan start PWM TEMP(DTS) 70

DeltaT +3

Smart Fan Slope PWM value 10 PWM value/unite

System Fan Full Speed Offset (DTS) 77

Enable CPU SmartFan

Main Advanced Chipset M.I.B III Security Boot Exit

+/- : Change Opt.

Enter : Select

 



:Select Screen

:Select Item

F1:General Help

F2:Previous Values

F3:Optimized Defaults

F4:Save & Exit

ESC:Exit

+/- : Change Opt.

Enter : Select

 



:Select Screen

:Select Item

F1:General Help

F2:Previous Values

F3:Optimized Defaults

F4:Save & Exit

ESC:Exit

BAT-I2 USER MANUAL

31

Chapter 3

Smart Fan start PWM value (180)

Smart Fan start TEMP(DTS) (70)

This item is used to set the start PWM value of the smart fan.

This item is used to set the start temperature of the smart fan.

DeltaT (+3)

This item specifies the range that controls CPU temperature and keeps it from going

so high or so low when smart fan works.

Smart Fan Slope PWM value (10 PWM value/unite)

This item is used to set the Slope Select PWM of the smart fan.

This item is used to set the CPU/system fan full speed offset value.

CPU/System Fan Full Speed Offset(DTS) (77)

Smart Fan Mode (Normal)

This item allows you to select the fan mode (Normal, Quiet, Silent, or Manual) for a

better operation environment. If you choose Normal mode, the fan speed will be

auto adjusted depending on the CPU temperature. If you choose Quite mode, the

fan speed will be auto minimized for quiet environment. If you choose Silent mode,

the fan speed will be auto restricted to make system more quietly. If you choose

Manual mode, the fan speed will be adjust depending on users’ parameters.

Press <Esc> to return to the PC Health Status page.

• System Temperature

• CPU Fan Speed

• System Fan Speed

• CPU Voltage

• DIMM Voltage

System Component Characteristics

These items display the monitoring of the overall inboard hardware health events,

such as System & CPU temperature, CPU & DIMM voltage, CPU & system fan

speed,... etc.

Press <Esc> to return to the Advanced Menu page.

BAT-I2 USER MANUAL

32

Chapter 3

+/- : Change Opt.

Enter : Select

 



:Select Screen

:Select Item

Power Management Setup

Resume By PME [Disabled]

Resume By USB [Enabled]

Resume By PS2 KB [Disabled]

Resume By PS2 MS [Disabled]

Resume By RTC Alarm [Disabled]

EUP Function [Enabled]

Power LED Type [Dual Color LED]

F1:General Help

F2:Previous Values

F3:Optimized Defaults

F4:Save & Exit

ESC:Exit

About Resume by PCI/PCI-E/

LAN/Ext.USB 3.0 PME



Power Management Setup

This page sets up some parameters for system power management operation.

Press <Esc> to return to the Advanced Menu page.

Resume By PME (Disabled)

The system can be turned off with a software command. If you enable this item, the

system can automatically resume if there is an incoming call on the PCI/PCI-E

Modem or PCI/PCI-E LAN card. You must use an ATX power supply in order to use this

feature. Use this item to do wake-up action if inserting the PCI/PCI-E card.

Resume By USB (Enabled)

This item allows you to enable or disable the USB device wakeup function from S3

mode.

Resume By PS2 KB (Disabled)

This item enables or disables you to allow keyboard activity to awaken the system

from power saving mode.The system can be turned off with a software command.

If you enable this item, the system can automatically resume at a fixed time

basedon the system’s RTC (realtime clock). Use the items below this one to set

the date and time of the wake-up alarm. You must use an ATX power supply in order

to use this feature.

Resume By RTC Alarm (Disabled)

EUP Function (Enabled)

This item allows user to enable or disable EUP support.

Power LED Type (Dual Color LED)

This item shows the type of the Power LED.

The system can be turned off with a software command. If you enable this item,

the system can automatically resume at a fixed time based on the system’s RTC

(realtime clock). Use the items below this one to set the date and time of the wake-

up alarm. You must use an ATX power supply in order to use this feature.

Main Advanced Chipset M.I.B III Security Boot Exit

Resume By PS2 MS (Disabled)

This item enables or disables you to allow mouse activity to awaken the system

from power saving mode.

BAT-I2 USER MANUAL

33

Chapter 3



ACPI Configuration

The item in the menu shows the highest ACPI sleep state when the system enters

suspend.

ACPI Sleep State (S3(Suspend to RAM))

This item allows user to enter the ACPI S3 (Suspend toRAM) Sleep State(default).

+/- : Change Opt.

Enter : Select

 



:Select Screen

:Select Item

ACPI Settings

ACPI Sleep State [S3 (Suspend to RAM)]

F1:General Help

F2:Previous Values

F3:Optimized Defaults

F4:Save & Exit

ESC:Exit

Select the highest ACPI sleep

state the system will enter

when the SUSPEND button is

pressed.

PCIE Express Configuration

mPCIE Speed [Auto]

+/- :Change Opt.

Enter : Select

F1:General Help

 

Configure PCIE slot speed.



:Select Screen

:Select Item

F2:Previous Values

F3:Optimized Defaults

F4:Save & Exit

ESC:Exit

The item in the menu shows the information of PCI Express Configuration.

PCI Express Configuration

mPCIE Speed (Auto)

This item allows user to configure the mPCIE speed.

Press <Esc> to return to the Advanced Menu page.

Main Advanced Chipset M.I.B III Security Boot Exit

BAT-I2 USER MANUAL

34

Chapter 3



CPU Configuration

The item in the menu shows the CPU information.

CPU Configuration

Socket 0 CPU Information

CPU Speed 2.41 GHz

64-bit Supported

Limit CPUID Maximum [Disabled]

Execute Disable Bit [Enabled]

Hardware Prefetcher [Enabled]

Adjacent Cache Line Prefetch [Enabled]

Intel Virtualization Technology [Enabled]

Power Technology [Energy Efficient]

Enhanced Halt (C1E) [Enabled]

Socket specific CPU Information

+/- : Change Opt.

 



:Select Screen

:Select Item

F2:Previous Values

F3:Optimized Defaults

F4:Save & Exit

ESC:Exit

Enter : Select

F1:General Help



Main Advanced Chipset M.I.B III Security Boot Exit

Scroll to this item and press <Enter> to view the following screen:

Socket 0 CPU Information

Main Advanced Chipset M.I.B III Security Boot Exit

Socket 0 CPU Information

Intel(R) Celeron(R) CPU J1800 @2.41GHz

CPU Signature 30673

Microcode Patch 312

Max CPU Speed 2410 MHz

Min CPU Speed 1333 MHz

Processor Cores 2

Intel HT Technology Not Supported

Intel VT-X Technology Supported

L1 Data Cache 24 KB X 2

L1 Code Cache 32 KB X 2

L2 Cache 1024 KB X 1

L3 Cache Not Present

Intel(R) Celeron(R) CPU J1800 @ 2.41GHZ

This is display-only field and displays the information of the CPU installed in your

computer.

+/- : Change Opt.

Enter : Select

 



:Select Screen

:Select Item

F1:General Help

F2:Previous Values

F3:Optimized Defaults

F4:Save & Exit

ESC:Exit

CPU Signature (30673)

This item shows the information of the CPU signature.

BAT-I2 USER MANUAL

35

Chapter 3

CPU Speed (2.41 GHz)

This item shows the processor speed.

Excute Disable Bit (Enabled)

This item allows the processor to classify areas in memory by where application

code can execute and where it cannot. When a malicious worm attempts to insert

code in the buffer, the processor disables code execution, preventing damage or

worm propagation. Replacing older computers with Execute Disable Bit enabled

systems can halt worm attacks, reducing the need for virus related repair.

64-bit (Supported)

This item shows the CPU installed in your computer support 64-bit or not.

Limit CPUID Maximum (Disabled)

Use this item to enable or disable the maximum CPUID value limit, you can enable

this to prevent the system from “rebooting” when trying to install Windows NT 4.0.

Hardware Prefetcher (Enabled)

If you enable this item, the processor fetches data and instructions from the memory

into the cache that are likely to be required in the near future. This reduces the

latency associated with memory reads.

Adjacent Cache Line Prefetch (Enabled)

If you enable this item, the processor fetches the currently requested cache line, as

well as the subsequent cache line. This reduces the cache latency by making the

next cache line immediately avaiable if the processor requires it as well.

Microcode Patch (312)

This item shows the version of Microcode patch.

Max CPU Speed (2410 MHz)

This item shows the max speed of the CPU.

Min CPU Speed (1333 MHz)

This item shows the min speed of the CPU.

Processor Cores (2)

This item shows the number of cores of the processor.

Intel HT Technology (Not Supported)

This item shows the computer supports Intel HT technology or not.

Intel VT-X Technology (Supported)

This item shows the computer supports Intel VT-X technology or not.

L1 Data Cache (24 KB X 2)

This item shows the size of CPU L1 Data Cache memory.

L1 Code Cache (32 KB X 2)

This item shows the size of CPU L1 Code Cache memory.

L2/L3Cache (1024 KB X1/Not present)

These items show the size of CPU L2/L3 Cache memory.

Press <Esc> to return to the CPU Configuration page.

BAT-I2 USER MANUAL

36

Chapter 3

Intel Virtualization Technology (Enabled)

When enabled, a VMM can utilize the additional hardware capabilities provided by

Vandor Pool Technology.

Power Technology (Energy Efficient)

This item enables or disables the power management features.

Enhanced Halt (C1E) (Enabled)

Use this item to enable the CPU energy-saving function when the system is not

running.

Press <Esc> to return to the Advanced Menu page.

BAT-I2 USER MANUAL

37

Chapter 3



SATA Configuration

Use this item to show the mode of serial SATA configuration options.

SATA Configuration

SATA Mode [AHCI Mode]

SATA Port1 Not Present

SATA Port2 Not Present

+/- : Change Opt.

 



:Select Screen

:Select Item

F1:General Help

F2:Previous Values

F3:Optimized Defaults

F4:Save & Exit

ESC:Exit

Enter : Select

Select IDE/ AHCI

SATA Port1/2 (Not Present)

This motherboard supports two SATA channels, and each channel allows one SATA

device to be installed. These items will display the information of devices installed.

SATA Mode (AHCI Mode)

Use this item to select SATA mode.

Press <Esc> to return to the Advanced Menu page.

Main Advanced Chipset M.I.B III Security Boot Exit

BAT-I2 USER MANUAL

38

Chapter 3

All USB Devices (Enabled)

Use this item to enable or disable all USB devices.



USB Configuration

Use this item to show the information of USB configuration.

+/- : Change Opt.

Enter : Select

 



:Select Screen

:Select Item

USB Configuration

All USB Devices [Enabled]

F1:General Help

F2:Previous Values

F3:Optimized Defaults

F4:Save & Exit

ESC:Exit

USB Support Parameters

Press <Esc> to return to the Advanced Menu page.



Intel (R) Smart Connect Technology

Use this item to show the information of Intel (R) Samrt Connect Technology.

+/- : Change Opt.

Enter : Select

 



:Select Screen

:Select Item

ISCT Support [Disabled]

F1:General Help

F2:Previous Values

F3:Optimized Defaults

F4:Save & Exit

ESC:Exit

Enable/Disable ISCT Support

ISCT Support (Disabled)

Use this item to enable or disable ISCT Support.

Press <Esc> to return to the Advanced Menu page.

Main Advanced Chipset M.I.B III Security Boot Exit

BAT-I2 USER MANUAL

39

Chapter 3



Super IO Configuration

Use this item to show the information of Super IO configuration.

+/- : Change Opt.

Enter : Select

 



:Select Screen

:Select Item

Super IO Configuration

Super IO Chip IT8622E-EX

Serial Port 1 Configuration

Serial Port 2 Configuration

Parallel Port Configuration

F1:General Help

F2:Previous Values

F3:Optimized Defaults

F4:Save & Exit

ESC:Exit

Set Parameters of Serial Port

1 (COMA)



Serial Port 1 Configuration

Scroll to this item and press <Enter> and view the following screen.

Serial Port (Enabled)

This item allows you to enable or disable serial port.

Device Settings (IO=3F8h; IRQ=4)

This item shows the information of the device settings.

Change Settings (Auto)

Use this item to change device settings.

+/- : Change Opt.

Enter : Select

 



:Select Screen

:Select Item

Serial Port 1 Configuration

Serial Port [Enabled]

Device Settings IO=3F8h; IRQ=4;

Change Settings [Auto]

F1:General Help

F2:Previous Values

F3:Optimized Defaults

F4:Save & Exit

ESC:Exit

Enable or Disable Serial Port

(COM)



Main Advanced Chipset M.I.B III Security Boot Exit

Press <Esc> to return to the Super IO Configuration page.

Super IO Chip (IT8622E-EX)

This item shows the information of the super IO chip.

BAT-I2 USER MANUAL

40

Chapter 3

Serial Port 2 Configuration

Scroll to this item and press <Enter> and view the following screen.

Serial Port (Enabled)

This item allows you to enable or disable serial port.

Device Settings (IO=2F8h; IRQ=3)

This item shows the information of the device settings.

Change Settings (Auto)

Use this item to change device settings.

+/- : Change Opt.

Enter : Select

 



:Select Screen

:Select Item

Serial Port 2 Configuration

Serial Port [Enabled]

Device Settings IO=2F8h; IRQ=3;

Change Settings [Auto]

F1:General Help

F2:Previous Values

F3:Optimized Defaults

F4:Save & Exit

ESC:Exit

Enable or Disable Serial Port

(COM)

Press <Esc> to return to the Super IO Configuration page.

Main Advanced Chipset M.I.B III Security Boot Exit

BAT-I2 USER MANUAL

41

Chapter 3

Parallel Port Configuration

Scroll to this item and press <Enter> and view the following screen.

Parallel Port (Enabled)

This item allows you to enable or disable serial port.

Device Settings (IO=378h; IRQ=5)

This item shows the information of the device settings.

Change Settings (Auto)

Use this item to change device settings.

+/- : Change Opt.

Enter : Select

 



:Select Screen

:Select Item

Parallel Port Configuration

Parallel Port [Enabled]

Device Settings IO=378h; IRQ=5;

Change Settings [Auto]

Device Mode [Standard Parallel...]

F1:General Help

F2:Previous Values

F3:Optimized Defaults

F4:Save & Exit

ESC:Exit

Enable or Disable Parallel

Port (LPT/LPTE)

Main Advanced Chipset M.I.B III Security Boot Exit

Device Mode (Standard Parallel...)

This item is used for Printer port mode selection, it can be set to Standard Parallel

Port Mode (SPP) or EPP Mode.

Press <Esc> to return to the Super IO Configuration page.

BAT-I2 USER MANUAL

42

Chapter 3

Azalia HD Audio (Enabled)

This item enables or disables Azalia HD audio.

SoC Configuration

Scroll to this item and press <Enter> and view the following screen.

DVMT Pre-Allocated (64M)

This item is used to select DVMT 5.0 Pre-Allocated (Fixed) Graphics Memory size

used by the Internal Graphics Device.

+/- : Change Opt.

Enter : Select

 



:Select Screen

:Select Item

F1:General Help

F2:Previous Values

F3:Optimized Defaults

F4:Save & Exit

ESC:Exit

SoC Parameters

SoC Configuration

TXE Information



Main Advanced Chipset M.I.B III Security Boot Exit

+/- : Change Opt.

Enter : Select

 



:Select Screen

:Select Item

F1:General Help

F2:Previous Values

F3:Optimized Defaults

F4:Save & Exit

ESC:Exit

Select DVMT 5.0 Pre-Allocated

(Fixed) Graphics Memory size

used by the Internal Graphics

Device.

SoC Configuration

DVMT Pre-Allocated [64M]

DVMT Total Gfx Mem [256MB]

Restore AC Power Loss [Power Off]

Audio Configuration

Azalia HD Audio [Enabled]

Azalia Interal HDMI Codec [Enabled]

Case Open Warning [Disabled]

Chassis Opened [No]

DVMT Total Gfx Mem (256MB)

This item shows the information of DVMT 5.0 total graphic memory size used by

Internal Graphics Device.

Restore AC Power Loss (Power Off)

This item enables your computer to automatically restart or return to its operating

status.

Main Advanced Chipset M.I.B III Security Boot Exit

The chipset menu items allow you to change the settings for the SoC chip and other

system.

Chipset Menu

BAT-I2 USER MANUAL

43

Chapter 3

TXE Information

Scroll to this item and press <Enter> to view the following screen.

+/- : Change Opt.

Enter : Select

 



:Select Screen

:Select Item

F1:General Help

F2:Previous Values

F3:Optimized Defaults

F4:Save & Exit

ESC:Exit

Enable/Disable TXE Firmware

TXE Information

Sec RC Version 00.05.00.00

TXE FW Version 01.00.02.1060

TXE Mode [Enabled]

Press <Esc> to return to the Chipset Menu page.

Azalia internal HDMI Codec (Enabled)

This item enables or disables Azalia internal HDMI codec.

Sec RC Version (00.05.00.00)

This item shows the Sec Reference Code Version.

TXE FW Version (01.00.02.1060)

This item shows the TXE Firmware Version.

TXE Mode (Enabled)

This is TXE mode control item, it is used to enable or disable the TXE firmware.

Case Open Warning (Disabled)

This item enables or disables the warning if the case is opened up, and the item

below indicates the current status of the case.

Chassis Opened (No)

This item indicates whether the case has been opened.

Main Advanced Chipset M.I.B III Security Boot Exit

BAT-I2 USER MANUAL

44

Chapter 3

M.I.B III (MB Intelligent BIOS III)

CPU Frequency 83.3 MHz

CPU Ratio 29

Intel(R) Celeron(R) CPU J1800 @ 2.41GHz

CPU Speed 2.41 GHz

Memory Frequency 1333 MHz

Total Memory 2048 MB (LPDDR3)

Memory Voltage Control



Main Advanced Chipset M.I.B III Security Boot Exit

+/- : Change Opt.



:Select Screen

:Select Item

F1:General Help

F2:Previous Values

F3:Optimized Defaults

F4:Save & Exit

ESC:Exit

Enter : Select

CPU Frequency (83.3 MHz)

This item shows the frequency of CPU reference clock.

CPU Ratio (29)

This item shows the max CPU ratio supported.

Intel(R) Celeron(R) CPU J1800 @ 2.41 GHZ

This is display-only field and displays the information of the CPU installed in your

computer.

CPU Speed (2.41 GHz)

This item shows the CPU speed.

Memory Frequency (1333 MHz)

This item shows the memory frequency.

Total Memory (2048 MB (LPDDR3))

This item shows the total memory.

This page displays the information of clock speeds and enables you to set the

memory voltage for your system. The clock speeds are determined by the kind of

processor installed in your system.

M.I.B III (MB Intelligent BIOS III) Menu

BAT-I2 USER MANUAL

45

Chapter 3

Memory Voltage Control

Scroll to this item to view the following screen:

Auto: DDR3L standard voltage

Low Voltage: Lowest voltage

supported by memory modules

Manual: User customized

Memory Voltage Control

Memory Voltage Configuration [Auto]

Main Advanced Chipset M.I.B III Security Boot Exit

+/- : Change Opt.



:Select Screen

:Select Item

F1:General Help

F2:Previous Values

F3:Optimized Defaults

F4:Save & Exit

ESC:Exit

Enter : Select

Memory Voltage Configuration (Auto)

This item provides 3 configuration modes for the voltage of memory modules. Auto:

Always provide DDR3L standard voltage (1.35V). Low Voltage: Provide the lowest

voltage memory module supported. Manual: User customized (provide 1.35V or

1.50V).

BAT-I2 USER MANUAL

46

Chapter 3

This page enables you to set setup administrator and password.

Security Menu

+/- : Change Opt.

Enter : Select



:Select Screen

:Select Item

F1:General Help

F2:Previous Values

F3:Optimized Defaults

F4:Save & Exit

ESC:Exit

Set Administrator Password

Main Advanced Chipset M.I.B III Security Boot Exit

Administrator Password Status Not Installed

User Password Status Not Installed

Administrator Password

Secure Boot menu

  

Administrator Password Status (Not Installed)

This item shows administrator password installed or not.

User Password Status (Not Installed)

This item shows user password installed or not.

Secure Boot menu

Scroll to this item and press <Enter> to view the following screen.

Secure Boot can be enabled if

1. System running in User mode

with enrolled Platform Key(PK)

2. CSM function is disabled

System Mode Setup

Secure Boot Not Active

Secure Boot [Disabled]

System Mode (Setup)

This item shows system of secure boot (can be setup or user).

Main Advanced Chipset M.I.B III Security Boot Exit

Secure Boot (Not Active)

This item shows the active state of secure boot.

Secure Boot (Disabled)

Use this item to enable or disable secure boot state.

+/- : Change Opt.

Enter : Select



:Select Screen

:Select Item

F1:General Help

F2:Previous Values

F3:Optimized Defaults

F4:Save & Exit

ESC:Exit

BAT-I2 USER MANUAL

47

Chapter 3

This page enables you to set the keyboard NumLock state.

Boot Menu

Fast Boot (Disabled)

Use this item to enable or disable the fast boot.

Bootup NumLock State (On)

This item enables you to select NumLock state.

Set Boot Priority

This item enables you to set boot priority for all boot devices.

Quiet Boot (Enabled)

Use this item to enable or disable the Quiet boot.

Boot Option #1/ 2/ 3/ 4/ 5/ 6 /7

These items show the boot priorities and can be used to set the boot priorities of

various device categories.

+/- : Change Opt.

Enter : Select



:Select Screen

:Select Item

F1:General Help

F2:Previous Values

F3:Optimized Defaults

F4:Save & Exit

ESC:Exit

Enables or disables boot with

initialization of a minimal set of

devices required to launch boot

option. Has no effect for BBS boot

options.

Boot Configuration

Operation System Select [Windows 7 or other OS]

Fast Boot [Disabled]

Bootup NumLock State [On]

Quiet Boot [Enabled]

Set Boot Priority

Boot Option #1 [Hard Disk]

Boot Option #2 [CD/DVD]

Boot Option #3 [USB/Floppy]

Boot Option #4 [USB CD/DVD]

Boot Option #5 [USB Hard Disk]

Boot Option #6 [USB Flash: UEFI: J...]

Boot Option #7 [Network]

UEFI USB Flash Drive Priorities

Main Advanced Chipset M.I.B III Security Boot Exit

Mærke:	ECS
Kategori:	Bundkort
Model:	BAT-I2

ECS BAT-I2 Manual

Produkt Specifikationer

Har du brug for hjælp?

Bundkort ECS Manualer

Bundkort Manualer

Nyeste Bundkort Manualer
