H81H3-I USER MANUAL

Brief Introduction

CPU

Specifications

• Intel® H81 Chipset

Chipset

• Dual-channel DDR3 memory architecture

• 2 x 240-pin DDR3 DIMM sockets support up to 16 GB

• Supports DDR3 1600/1333 MHz DDR3 SDRAM

Memory

• 1 x PCI Express x16 Gen2 slot

• 1 x Mini PCI Express p1-x1 slot

• Supported by Intel® H81 Express Chipset

- 2 x Serial ATA 6Gb/s devices, 2 x Serial ATA 3Gb/s devices

Expansion

Slots*

Storage

• 1 x PS/2 keyboard and PS/2 mouse connectors

• 1 x DVI port* (or HDMI port)

• 1 x VGA port

• 4 x USB 2.0 ports* (or 2 x USB 3.0 ports and 2 x USB 2.0 ports)

• 1 x RJ45 LAN connector

• 1 x Audio port (1x Line in, 1x Line out, 1x Mic_in Rear)

Rear Panel I/O

• Realtek RTL8111G Giga LAN

- 10/100/1000 Fast Ethernet Controller

- Wake-on-LAN and remote wake-up support

• LGA1150 socket for 4th Generation Intel ® CoreTM Family/

Pentium/Celeron Processors

Note: Please go to ECS website for the latest CPU support list.

• 1 x 24-pin ATX Power Supply connector

• 1 x 4-pin 12V Power connector

• 1 x 4-pin CPU_FAN connector

• 1 x 4-pin SYS_FAN connector

• 2 x USB 2.0 headers support additional four USB 2.0 ports

• 1 x USB 3.0 header supports additional two USB 3.0 ports

(Co-lay two USB 3.0 ports at the rear panel) *

• 2 x Serial SATA 6Gb/s connectors

• 2 x Serial SATA 3Gb/s connectors

• 1 x COM header

• 1 x Case open header

• 1 x Front Panel audio header

• 1 x Front Panel switch/LED header

• 1 x Speaker header

• 1 x ME_UNLOCK header

• 1 x CLR_CMOS jumper

Internal I/O

Connectors &

Headers

• VIA VT1705CP

- 6 Channel High Definiton Audio Codec

- Compliant with HD audio specification

Audio

LAN

Note: *PCIe SPEC will be changed with Intel latest CPU SPEC.

Note: *Please take the actual motherboard as standard.

Note: *If there are dual USB 3.0 ports at the rear panel, the USB 3.0

header duo to Intel H81 chipset SPEC just supports two USB

3.0 ports. Please take the actual motherboard as standard.
