Side 1/3

EK-PSK2 / EK- PSK4

EK-PAK2 / EK- PAK4

2/4 ports PS2 KVM Switches

Introduction

The Edimax KVM switch series is a 2/4-port Slim Palmtop

PS/2 KVM Switch with optional audio and microphone

switching function. It allows you to access, control, boot and

reboot multiple PS/2-enabled computers using only one

keyboard, video, mouse, and optional speaker set and

microphone. It also offers user-programmable

simultaneous/independent switching of PC channel and

Audio/Mic channel for flexible multimedia application with

KVM switching. For users who might need to use a hotkey

preceding sequence other than two scroll locks, we also

offer five key alternatives for free configuration.

Before you install

The default setting of the KVM switches is appropriate for

most systems. The KVM Switch is a Plug-and-Play device

for installation. In fact, you do not need to configure the KVM

Switch before installation.

For the first time installation of the KVM Switch, please

follow the instructions below for correct setup sequence:

The correct setup sequence is ……

(1) Connect the shared keyboard, monitor and mouse (and

optional speaker set and microphone) to the KVM Switch first,

and then connect your computers.

(2) Power up your connected computers…

Since the KVM Switch receives power from the computer’s PS/2

interface, it is powered up when you connect the KVM Switch to a

PC.

Out-of-the-box Installation

Take the KVM Switch out of the box and begin installation….

DO NOT TRY to connect the KVM Switch to the computers

while the computers are still in powered-on states. Otherwise, the

computer will have difficulty recognizing your shared keyboard and

mouse.

Step 1. Make sure all the computers that are to be

connected to the KVM Switch and their peripherals

are in powered-off state. If not, power them off

before you proceed with the following steps.

Step 2. Connect the shared PS/2 keyboard, mouse, monitor,

speaker set and microphone to the KVM switch.

Step 3. Connect each of your computers to the KVM switch,

using appropriate KVM & Audio/Mic cables.

Configuration Diagram

Step 4. (Now your KVM Switch should have been powered-

up….) Power up the connected computers one by

one. After your computers are powered up, the

keyboard and mouse will be recognized and now

you can begin operating the KVM switch.

Easy Operation

There are two methods to control your KVM Switch for PC

switching: using the face-panel push button or a hotkey

sequence. For audio/mic switching, use the hotkey

command. See Quick Reference Sheet

Face-panel buttons

The face-panel buttons allows you a direct control over PC

port switching. Simply press the button to switch PC port. By

default, PC port switching and Audio/Mic port switching are

bound together (both will be switched simultaneously).

If you want to enable the binding of PC and audio/mic port

switching, use the hotkey sequence, ScrLk +ScrLk + Q. To

disable the binding again, just hit ScrLk +ScrLk + W. See

Quick Reference Sheet

Keyboard hotkey

A keyboard hotkey sequence consists of at least three

specific keystrokes: See Quick Reference Sheet

Hotkey sequence = [ScrLk]* + [ScrLk] * + Command key(s)

* User-definable = SCROLL LOCK, CAPS, ESC, F12 or NUM

LOCK

Hotkey preceding sequence configuration: For users

who want to use a preceding sequence other than two

consecutive Scroll Locks, there is also one convenient way

to configure it:

Step 1. Hit ScrollLock + ScrollLock + H, then two beeps will signal

readiness for new preceding sequence selection. [or Press

and hold down the last front-panel button (Button 2 or Button

4) until you hear two beeps, and then release the button.]

Step 2. Select and press the key you would like to use as your

preceding sequence (SCROLL LOCK, CAPS, ESC, F12 or

NUM LOCK keys are available for selection) and you’ll hear

a beep for selection confirmation. Now you can use the new

preceding sequence to execute your hotkey commands.

Another way to activate the Hotkey preceding sequence

configuration is to press the last front-panel button (button 2/button

4) for over 3 seconds to set the KVM switch into hotkey

configuration mode. Then you select and press the key that you’ll

choose as the preceding sequence.

Each keystroke within a hotkey sequence should be pressed

within 2 seconds. Otherwise, the hotkey sequence will not be

validated.

For detailed Hotkey sequences and their corresponding

functional commands, please refer to the Quick reference sheet.

Produkt Specifikationer

Mærke:	Edimax
Kategori:	Skifte
Model:	EK-PSK2
Bredde:	96 mm
Dybde:	61 mm
Højde:	24 mm
Vægt:	95.4 g
Produktfarve:	Sort
Indbygget skærm:	Ingen
Relativ luftfugtighed ved drift (H-H):	0 - 90 %
Driftstemperatur (T-T):	0 - 50 °C
Maksimal opløsning:	2048 x 1536 pixel
Forbindelsesteknologi:	Ledningsført
Antal VGA-porte (D-sub):	2
Antal kontrollerede computere:	2
Tastatur porttype:	PS/2
Mus porttype:	PS/2
Video porttype:	VGA
Lydforbindelse:	Ingen
Antal PS/2-porte:	2
Båndbredde:	350 Mhz
