Edimax GS-5208PLG Manual

Edimax Skifte GS-5208PLG

Læs gratis den danske manual til Edimax GS-5208PLG (36 sider) i kategorien Skifte. Denne vejledning er vurderet som hjælpsom af 14 personer og har en gennemsnitlig bedømmelse på 4.9 stjerner ud af 7.5 anmeldelser. Har du et spørgsmål om Edimax GS-5208PLG, eller vil du spørge andre brugere om produktet?

Download PDF

Side 1/36

GS-5208PLG

User Manual

11 2020- / v1.1

CONTENTS

Chapter 1 Product Informaon ............................................................. 3

1-1 Product Overview 3 .................................................................................................................

1-2 Features ................................................................................................................................. 3

1-3 External Component Descripon ......................................................................................... 4

1-3-1 Front Panel .................................................................................................................... 4

1-3-2 Rear Panel ...................................................................................................................... 5

1-4 Package Contents .................................................................................................................. 5

1-5 Rack-mountable Installaon 6 ................................................................................................

Chapter 2 Connect & Login 7 ...................................................................

2-1 Switch to End Node ............................................................................................................... 7

2-2 Login 8 ......................................................................................................................................

Chapter 3 Switch Conguraon ........................................................... 10

3-1 System ................................................................................................................................. 11

3-1-1 Device Name Setup ..................................................................................................... 12

3-2 Management ....................................................................................................................... 13

3-3 Port ...................................................................................................................................... 15

3-4 VLAN .................................................................................................................................... 16

3-4-1 IEEE 802.1Q VLAN ........................................................................................................ 16

3-5 Trunking ............................................................................................................................... 18

3-6 QoS ....................................................................................................................................... 20

3-7 Broadcast Storm Control ....................................................................................................22

3-8 Rate Liming .......................................................................................................................23

3-9 Loop Detect/Prevent ........................................................................................................... 24

3- IGMP Snooping10 .................................................................................................................... 25

3- POE11 ....................................................................................................................................... 26

3- Password12 ............................................................................................................................. 28

3- Logout13 .................................................................................................................................. 29

Produkt Specifikationer

Mærke:	Edimax
Kategori:	Skifte
Model:	GS-5208PLG
Vekselstrømsindgangsspænding:	100 - 240 V
Vekselstrømsindgangsfrekvens:	50 - 60 Hz
Bredde:	184 mm
Dybde:	265 mm
Højde:	44 mm
Vægt:	1700 g
Produktfarve:	Sort
Formfaktor:	1U
Opbevaringstemperatur (T-T):	-40 - 70 °C
Relativ luftfugtighed ved drift (H-H):	10 - 90 %
Relativ luftfugtighed ved opbevaring (H-H):	5 - 90 %
Driftstemperatur (T-T):	0 - 40 °C
Certificering:	FCC A, CE
Netværksstandarder:	IEEE 802.1Q, IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x
Webbaseret administration:	Ja
Knap til nulstilling:	Ja
Servicekvalitet support (QoS):	Ja
LED-indikatorer:	Activity, Link, Power, Status
Firmware kan opgraderes:	Ja
Fiber optisk strømstik:	SFP
Strøm over Ethernet (PoE):	Ja
Monteringsbeslag inkluderet:	Ja
Switch-type:	Administreret
Total Power over Ethernet (PoE):	130 W
Power over Ethernet plus (PoE+) porte, antal:	8
Power over Ethernet (PoE) effekt pr. port:	30 W
10G understøttelse:	Ingen
VLAN understøttelse:	Ja
Antal VLAN'er:	4094
Kobber ethernet kabelteknologi:	10BASE-T, 100BASE-TX, 1000BASE-T
Broadcast stormkontrol:	Ja
Vituelle LAN funktioner:	Tagged VLAN
Basis omskiftning RJ-45 Ethernet porte, antal:	8
Basis omskiftning RJ-45 Ethernet porttype:	Gigabit Ethernet (10/100/1000)
IGMP snooping:	Ja
Adgangskontrolliste (ACL):	Ja
Loop beskyttelse:	Ja
Fiber ethernet kabelteknologi:	1000BASE-X
Opbevar-og-frem:	Ja
MAC adresselabel:	4000 entries
Switch kapacitet:	20 Gbit/sek.
Antal køer:	4
Jumbo Frames support:	Ja
Jumbo rammer:	9200
Stativ-montering:	Ja
Multicast-understøttelse:	Ja
Antal SFP modulslots:	2
Bufferstørrelse:	192 KB
Hastighed for videresendelse:	14.88 Mpps
Pakke videresendelsesrate (1 Gbps):	1488000 pps
Pakke videresendelsesrate (100 Mbps):	148800 pps
Pakke videresendelsesrate (10 Mbps):	14880 pps
Antal filtrerede multicast-grupper:	129
