- Housing made of stainless steel
- Bottum made of power-varnished sheet steel
- Tilt guard switch, if the heater is tilting the gas
- Reflector (2) made of aluminium
- Regulator for continuously adjustment of heating
- Mobile with castors (6)
- Thermoelectric ignition (not illustrated)
Gas hose and regulator (not illustrated)
ciency terrace heater for cooler days creates comfortable warmth. The heating capacity can be adjusted
continuously. The equipment is examined to newest standard EN 14543 and equipped with a tilt guard switch.
- Gas connection: p50 (mbar)
- Rated heat load max.: 12 KW (Hi) / 13 KW (Hs)
- Gas consumption max: approx. 0.946 kg/h
- Heating period: approx. 12 h at large operating
- Type of gas: propane/butane
- Height: approx. 2.23 mtrs.
- Reflector size: Ø approx. 79 cm
- Packing dimensions: 790 x 400 x 790 mm
For commercial and private use, where ever comfortable warmth is required
outdoor during cold days and evenings.
The gas bottle can be stored in the base of the heater.
On account of the integrated tilt guard the heater is suitable for the mobile use
(also without ground connection) according to EN 14543.
ion for the commercial use:
According to BGV D34 (VBG 21) and TRF are in Germany by
commercial use (e. g. on fair grounds) a hose faction protection
according to DIN 30 693 “Hose faction protections for liqueed
gas constructions”, a safety pressure controller and during mobile
usage you have to put a tilt guard (already integrated) according to
EN 14543 onto the heater. Hose faction protection and safety
pressure controller are not belongs to the scope of delivery.
Corresponding arrangements in the specied countries of
destination are stringently to observe.
