Side 1/8

User Instructions

ELAR TRI PAR IP Introduction

Elation Architectural - www.elationlighting.com - ELAR TRI PAR IP Instruction Manual Page 2

Rev. 8/11

Unpacking: Thank you for purchasing the ELAR TRI PAR IP by Ela-

tion Architectural . Every ELAR TRI PAR IP has been thoroughly tested ®

and has been shipped in perfect operating condition. Carefully check

the shipping carton for damage that may have occurred during ship-

ping. If the carton appears to be damaged, carefully inspect your x-

ture for any damage and be sure all accessories necessary to operate

the unit has arrived intact. In the case damage has been found or parts

are missing, please contact our customer support number for further

instructions. Do not return this unit to your dealer without rst contact-

ing customer support.

Introduction: The ELAR TRI PAR IP is part of ArchitecturalElation ®

continuing pursuit for creating high quality affordable intelligent fix-

tures. The ELAR TRI PAR IP is a powerful DMX intelligent RGB LED

wash. This wash is light weight and compact which makes it a great

piece for mobile DJ’s and clubs. This unit can be used as a stand alone,

or a sound-active mode. The unit can also be controlled via DMX con-

troller.

Customer Support: Elation©® provides a customer support line, to

provide set up help and to answer any question should you encounter

problems during your set up or initial operation. You may also visit us

on the web at www.elationlighting.com for any comments or sugges-

tions. Service Hours are Monday through Friday 9:00 a.m. to 5:00 p.m.

Pacic Standard Time.

Voice: (323) 582-3322

Fax: (323) 832-9142

E-mail: support@elationlighting.com

Warning! To prevent or reduce the risk of electrical shock or re, do

not expose this unit to rain or moisture.

Caution! There are no user serviceable parts inside this unit. Do not

attempt any repairs yourself, doing so will void your manufactures war-

ranty. In the unlikely event your unit may require service please contact

©Elation customer support.

PLEASE recycle the shipping carton when ever possible.

6122 S. Eastern Ave.

Los Angeles CA. 90040

www.elationlighting.com

ELAR TRI PAR IP

ELAR TRI PAR IP Safety Precautions

Elation Architectural - www.elationlighting.com - ELAR TRI PAR IP Instruction Manual Page 4Elation Architectural - www.elationlighting.com - ELAR TRI PAR IP Instruction Manual Page 3

• Do not spill water or other liquids into your unit.

• Do not attempt to operate this unit if the power cord has been

frayed or broken. Do not attempt to remove or break o the ground

prong from the electrical cord. This prong is used to reduce the risk

of electrical shock and re in case of an internal short.

• Disconnect from main power before making any type of connection.

• Do not remove the cover under any conditions. There are no user

serviceable parts inside.

• Never operate this unit when it’s cover is removed.

• Never plug this unit in to a dimmer pack

• Always be sure to mount this unit in an area that will allow proper

ventilation. Allow about 6” (15cm) between this device and a wall.

• Do not attempt to operate this unit, if it becomes damaged.

• During long periods of non-use, disconnect the unit’s main power.

• Always mount this unit in safe and stable matter.

• Power-supply cords should be routed so that they are not likely to

be walked on or pinched by items placed upon or against them,

paying particular attention to the point they exit from the unit.

• Cleaning -The fixture should be cleaned only as recommended by

t he manufacturer. See page 14 for cleaning details.

• Heat -The appliance should be situated away from heat sources

such as radiators, heat registers, stoves, or other appliances (inclu-

d ing amplifiers) that produce heat.

• The fixture should be serviced by qualified service personnel when:

A. The power-supply cord or the plug has been damaged.

B. Objects have fallen, or liquid has been spilled into the appliance.

C. The appliance does not appear to operate normally or exhibits a

marked change in performance.

ELAR TRI PAR IP Warranty Registration

ELAR TRI PAR IP Features

To optimize the performance of this product, please read these

operating instructions carefully to familiarize yourself with the basic

operations of this unit. These instructions contain important safety

information regarding the use and maintenance of this unit. Please

keep this manual with the unit, for future reference.

ELAR TRI PAR IP General Instructions

• Multi-Colors

• 3 LEDs Per Lens

• Built in Microphone

• Five Operating Modes

• DMX-512 protocol

• Six DMX Modes: 1 Channel Mode, 2 Channel Mode, 3 Channel

Mode, 4 Channel Mode, 6 Channel Mode, & 7 Channel Mode

• Dimming 0-100% in 2 Channel Mode, 4 Channel Mode, 6 Channel

Mode, & 7 Channel Mode.

• Daisy Chain Units Together in DMX Mode

The ELAR TRI PAR IP carries a year limited warranty. Please fill two

out the enclosed warranty card to validate your purchase. All returned

service items whether under warranty or not, must be freight pre-paid

and accompany a return authorization (R.A.) number. The R.A. number

must be clearly written on the outside of the return package. A brief

description of the problem as well as the R.A. number must also be

written down on a piece of paper included in the shipping carton. If

the unit is under warranty, you must provide a copy of your proof of

purchase invoice. You may obtain a R.A. number by contacting our

customer support team on our customer support number. All pack-

ages returned to the service department not displaying a R.A. number

on the outside of the package will be returned to the shipper.
