Elba ARTICO EF-F5138E(GR) Manual

Elba Fryser ARTICO EF-F5138E(GR)

Læs gratis den danske manual til Elba ARTICO EF-F5138E(GR) (4 sider) i kategorien Fryser. Denne vejledning er vurderet som hjælpsom af 19 personer og har en gennemsnitlig bedømmelse på 4.6 stjerner ud af 10 anmeldelser. Har du et spørgsmål om Elba ARTICO EF-F5138E(GR), eller vil du spørge andre brugere om produktet?

Download PDF

Side 1/4

EF-F4132E(GR)

CHEST FREEZER

EF-E5138E(GR)

For The Warranty Terms & Conditions, Please Refer To Warranty Certificate

• This appliance should not be used in the immediate vicinity of water, such as

bathtub, washbowls, swimming pool etc. where the likelihood of splashing

could occur.

• Always switch off and unplug the plug from outlet when not in use and before

cleaning.

• When the appliance is operating, the condenser and compressor will be hot.

• This appliance must be grounded and the ground wire should not be

connected to any heating pipe and gas pipe.

• Do not place carbonated or fizzy drinks into the freezer.

• Do not attempt to touch the freezer when your hand is damp or wet as this

could cause skin abrasions or frost burns.

• This appliance is designed to operate in ambient temperatures (surrounding

air temperature) between 16ºC and 32ºC.

• This appliance will create frost in the freezer compartment if the environment

has high humidity or the appliance door is opened frequently.

• Do not store explosive substances such as aerosol cans or flammable

propellant in the appliance.

• The refrigerant contained in the refrigerant circuit of the appliance is high level

of environmental compatible, which is also however flammable.

• During transportation and installation of the appliance, make sure none of the

components of the refrigerant circuit become damaged.

• It is dangerous to alter the specifications or modify this product in any way.

REMOVE ALL PACKING MATERIALS FROM THIS APPLIANCE BEFORE

USING IT. THIS APPLIANCE MUST BE INSTALLED ON A FLAT SURFACE.

PLEASE ENSURE THE ELECTRICITY SUPPLY TO THIS APPLIANCE IS

DISCONNECTED BEFORE INSTALLING.

Please read this instruction carefully. It is advisable to keep this instruction

manual in a safe place for future reference.

1. Keep this appliance out of reach from children. Do not let them to operate the

appliance without supervision.

2. Check the current rating on the rating plate and make sure the current supplied

is matched with the appliance before using.

3. This appliance must be stationed at least 10cm away from the surrounding

objects. There should not be anything to be placed on top of the appliance.

4. This appliance is for household and indoor use only.

5. This appliance is not intended for use by person (including children) with

reduced physical, sensory or mental capabilities unless they have been given

supervision or instruction concerning use of the appliance by a person

responsible for their safety.

6. If the power cord or plug is damaged, it must be replaced by the service centre

or a qualified service technician to avoid hazard.

7. This appliance should not be placed near possible heating resources or under

direct sunlight to avoid decreasing the efficiency of refrigeration.

8. This appliance should be placed in a cool dry place where there is no vicinity

of water splashing or high humidity.

WARNING - to reduce the risk of fire, electrical shock or injury to persons or

property, please read and follow below instructions carefully:

• Always operate the appliance from a power source of the same voltage,

frequency and rating as indicated on the appliance identification marking.

• Do not operate this appliance if it has malfunctioned, damaged cord or plug or

appears damaged in any way. Return the complete product to the place of

purchase for inspection, repair or replacement.

1. This appliance is heavy. Care should be taken when moving it.

2. When you transport the appliance, the angle between the compartment body

and the ground should not be less than 45º.

WARNING: Never put the appliance upside down.

3. Once the appliance has landed properly on a flat and stable surface, remove

all the packing material including any plastic packaging material in the appliance.

4. The back of the appliance should be close to a wall but leaving the required

distance for ventilation.

5. Wash the inside of the appliance with lukewarm water with a little bicarbonate

of soda added (5ml to 0.5 litre of water). Do not use soap, detergent or any

abrasive cleaner to wash. Dry the appliance thoroughly after cleaning.

6. Open the fridge door for ventilation of internal compartments. Idle for 4 hours

before connecting the electrical mains to ensure the refrigerant in the compressor

has settled well.

7. Connect the electrical mains and switch on the power for 4 hours initially

before adding any goods. Make sure the ground is solid and will not vibrate when

the appliance is operating.

8. If these temperatures are exceeded i.e., colder or warmer, the appliance will

not operate correctly. Should the ambient temperatures be exceeded for long

periods, the temperature in the freezer section will rise above -18ºC and food

spoilage may occur.

9. This appliance has to manually defrost and frosting will occur as normal. It is

advisable to manually defrost the appliance when the frosting is at 5mm thick.

1. The electronic thermostat situated on the appliance regulates the temperature.

Press 'SET' key to adjust the temperature. Press once, the temperature range LED

indicator will be turned on when reaching each level. After 5 seconds without adjust

the temperature, the electronic thermostat will confirm the settings automatically.

NOTE: Running (Indicator light) will turn on green light when compressor is running.

Freezer will automatically record the last operate mode when switch off.

Press “OFF 3’S” key for 3 seconds to switch off the freezer.

2. Regulate the cooling level to “Level 5” to check on the operation before switching

to higher cooling level.

NOTE: The optimum cooling level is position on “Level 4 or 5” (to avoid over

cooling and damaged to the compressor).

3. Check the temperature after 4 hours. If the cooling has reached to acceptable

level, you may start using the appliance.

4. The temperature will be affected by:

- Room temperature;

- How often the door is opened; and

- How much food is stored

5. In determining the correct temperature control setting, all the above factors

have to be considered and some experimentation may be required.

6. Always store the hot food after it has completely cold. Never store hot items

into the appliance.

7. Always pack the food completely before putting into the appliance to avoid

taste mixing and frosting together.

8. If there is an electricity cut-off, please wait 10 minutes before operating the

appliance again to avoid damage to the compressor.

SAFETY PRECAUTIONS SAFETY PRECAUTIONS

PRODUCT DESCRIPTIONS INSTALLATION OPERATING THE APPLIANCE

1. Exterior handle

2. Drain hole

3. Basket

4. Power cord

5. Electronic control panel

Castors

7. Lock

Fridge mode (Level 1,2)

Fast Freezing mode (Level 7)

Freezer mode (Level 3,4,5,6)

LED Indicator Status

Produkt Specifikationer

Mærke:	Elba
Kategori:	Fryser
Model:	ARTICO EF-F5138E(GR)
