Electro

Disc LED

SPECIFICATIONS:

Model: Electro Disc LED

Voltage: 100V-240V 50/60Hz

LEDs: 107 x 10mm LEDs (36

Red, 36 Green, & 35 Blue)

Beam Angle: 30 Degrees

Power Consumption: 14W

Weight: 3lbs./ 1.2kgs.

Size: 10.25”(L) x 9.5”(W) x 4”(H)

Fuse: 1 Amp

Power Cord Daisy Chain: 40 Fixtures Max.

Working Position: Any Safe position

Duty Cycle: None

DMX Channels: 4 DMX Channels

Colors: Multiple Colors

Warranty: 1 Year

CAUTION! Please read and under-

stand these instructions before

installing or operating this unit.

Operating Instructions:

The Electro Disc LED has been tested at the factory, there is no assembly required. The unit is ready

to be plugged into a power outlet. This unit is a 4 channel DMX intelligent LED wash. It has 6 oper-

ating modes; Static Color mode, Color Change mode, Color Fade mode, Auto Run mode, Sound

Active mode, or DMX mode. The Electro Disc LED can be used as a stand alone unit or in a master-

slave conguration.

Power Cord Daisy Chaining: With this feature you can connect the xtures to one another using the

IEC input and output sockets. The quantity that can be connected is 40 xtures maximum. After 40

xtures you will need to use a new power outlet. They must be the same xtures. DO NOT mix xtures.

©Eliminator® Los Angeles, CA. - www.EliminatorLighting.com

Caution! Never open unit when in use. Always

disconnect main power before replacing fuse.

Remember to always replace with the exact same

type fuse.

1 Year Limited Warranty: Eliminator Lighting warranty is valid from the date of purchase. Our

1 year limited warranty covers manufacturing defects only. Serial number, place of purchase with

dated valid receipt must be submitted at time of service. Eliminator Lighting warranty does not cover

items or parts prone to wear and tear: lamps, fuses, brushes and belts. Eliminator Lighting warranty

is only valid with-in the United States.

Electro IR (Remote Control) On/Off:

This function is used to activate and deactivate the Electro IR (sold separately). When this function is acti-

vated you can control the xture using the Electro IR. Please see the last page for the controls and functions.

1. Plug the xture in and press the MODE button until “IrXX” is displayed. “XX” represents either “on” or

“oF”.

3. Press the UP or DOWN buttons to either activate the remote function (On) or deactivate it (Off).

Static Color Mode:

1. Plug the xture in and press the MODE button until “CL.XX” is displayed.

2. There are 7 colors to choose from. Select your desired color by pressing the UP and DOWN but

tons. After you have selected your desired color you can activate strobing by pressing the SET

UP button to enter the Flash (strobe) mode.

3. “FS.XX” will be displayed, this is Flash mode. The Flash can be adjusted between “FS.0F” (ash

off) to “FS.99” (fastest ash).

Color Change Mode:

1. Plug the xture in and press the MODE button until “JP.XX” is displayed.

2. Use the UP and DOWN buttons to adjust the color change speed the speed can be adjusted

between “JP.01” (slowest) to “JP.99” (fastest).

3. After you have adjusted and selected your desired color change speed you can activate strobing

by pressing the SET UP button to enter the Flash (strobe) mode. “FS.XX” will be displayed, this is

Flash mode. The Flash can be adjusted between “FS.0F” (ash off) to “FS.99” (fastest ash).

Color Fade Mode:

1. Plug the xture in and press the MODE button until “FD.XX” is displayed.

2. Use the UP and DOWN buttons to adjust the color fade speed the speed can be adjusted

between “FD.01” (slowest) to “FD.99” (fastest).

3. After you have adjusted and selected your desired color fade speed you can activate strobing by

pressing the SET UP button to enter the Flash (strobe) mode. “FS.XX” will be displayed, this is

Flash mode. The Flash can be adjusted between “FS.0F” (ash off) to “FS.99” (fastest ash).

Auto Run Mode:

1. Plug the xture in and press the MODE button until “AUTO” is displayed. In Auto Run mode the

unit will run the color change mode and color fade mode alternatively. The speed of each mode is

determined by the setting in each of those respective modes.

2. You can activate strobing by pressing the SET UP button to enter the Flash (strobe) mode.

“FS.XX” will be displayed, this is Flash mode. The Flash can be adjusted between “FS.0F” (ash

off) to “FS.99” (fastest ash).

Sound Active Mode:

In this mode the Electro Disc LED will react to sound, and chase through the different colors.

1. Plug the xture in and press the MODE button until “SU.XX” is displayed. “XX” represents the

sound senstivity level.

2. Use the UP and DOWN buttons to adjust the sound sensitivity, the sensitivity can be adjusted

between “SU.00” (least sensitive) to “SU.31” (most sensitive).

3. After you have adjusted and set your desired sensitivity you can press the SET UP button to

enter the Flash (strobe) mode. “FS.XX will be displayed when you enter Flash mode. You can

use the UP or DOWN buttons to adjust the strobe rate. The Flash can be adjusted between

“FS.OF” (stobe is off) to “FS.99” (fastest ash).

©Eliminator® Los Angeles, CA. - www.EliminatorLighting.com
