STEALTH SPOT

©Eliminator® Los Angeles, CA. - www.EliminatorLighting.com

Introduction:

The Stealth Beam is a DMX intelligent moving head unit. The Stealth Beam has 3 operating modes;

sound active mode, show mode, or controlled via DMX controller. The Stealth Beam has 2 DMX

Channel modes; 5 or 15 channels. The unit can be run as a stand alone unit or in a Master/Slave set

up. This unit has been tested and there is no assembly required. Follow the instructions on the fol-

lowing pages to operate your fixture. To enhance the beams effects you can use a fog machine.

CAUTION! Please read and understand these instructions before installing or operating this unit.

SPECIFICATIONS:

Model: Stealth Spot

Supply Voltage: 100V-240V 50/60Hz

LED: 1 x 60W White LED

Weight: 11lbs./ 5 kgs.

Size: 6.7” (L) x 9.4” (W) x 13.97” (H)

Fuse: 2 Amp

Power Consumption: 90W

Working Position: Any Safe position

Duty Cycle: None

DMX Channels: 2 DMX Channel Modes:

5 Channel Mode &

15 Channel Mode

Gobos: 5 + Spot

Colors: 7 Colors + White

Warranty: 1 Year

CAUTION! Please read and

understand these instructions

before installing or operating

this unit.

Fuse Replacement: Locate and remove

the unit’s power cord. Once the cord

has been removed, the fuse holder is

located inside the power socket. Insert

a flat-head screw driver into the fuse

holder and gently pry out the holder.

Remove the bad fuse and replace with

a new one. The fuse holder has a built-in

second holder for a spare fuse.

©Eliminator® Los Angeles, CA. - www.EliminatorLighting.com

AXXX: In this menu you can set the DMX address. Press the Up or Down buttons until “AXXX” is displayed.

“XXX” is the current displayed DMX address. Press Enter and use the UP or Down buttons to nd your de-

sired address. When you have found your desired address press the Enter button to set it. NOTE: To display

the DMX address you must rst select any show, then press the MENU button to exit and then follow

the directions above.

Chnd: The Stealth Spot has 2 DMX channel modes; 5 channel mode and 15 channel mode. In this menu you

can select your desired channel mode. Press the Up or Down buttons until “CHnd” is displayed and press

ENTER. Either “15CH” or “5CH” will be displayed. Use the Up and Down buttons to toggle between the two

modes and press Enter to make your selection and press Menu to exit.

SPnd (Sound Active Speed): In this menu you can adjust the sound active moving speed. Press the Up or

Down buttons until “SPnd” is displayed and press ENTER. Either “LoSP” (Low Speed) or “HISP” (High Speed)

will be displayed. Use the Up and Down buttons to toggle between the two speed and press Enter to make

your selection. Press the Menu button to exit.

SOUN (Sound Active): In this menu you can activate Sound Active mode. Press the Up or Down buttons until

“SOUN” is displayed and press Enter. Either “On” or “O” will be displayed. Use the Up and Down buttons

toggle between the choices and press Enter to make your selection. Press the Menu button to exit.

SHnd (Show Mode): In this menu you can activate the 1 of 8 show mode’s. Press the Up or Down buttons

until “SHnd” is displayed and press Enter. Either 1 of 8 shows will be displayed. Use the Up and Down

buttons nd your desired show and press Enter to make your selection. Press the Menu button to exit

SLnd (Master/Slave): In this menu you can designate the xture as either a Master or Slave in a master-slave

set up. Press the Up or Down buttons until “SLnd” is displayed and press Enter. Either “Mast” or “SL 1 will be

displayed. Use the Up and Down buttons to nd your desired setting and press Enter to make your selection.

Press the Menu button to exit

PAn (Reverse Pan): In this menu you can reverse the Pan function. Press the Up or Down buttons until “PAn”

is displayed and press Enter. Press the Up or Downs buttons until “On” is

displayed, and press Enter. Press the Menu button to exit. This function works better when you have two units

connected in a Master/Slave setup. Have one unit set to reverse Pan and the other unit in normal Pan.

tIL ( Reverse Tilt): In this menu you can reverse the Tilt function. Press the Up or Down buttons until “tIL” is

displayed and press Enter. Press the Up or Downs buttons until “On” is

displayed, and press Enter. Press the Menu button to exit. This function works better when you have two units

connected in a Master/Slave setup. Have one unit set to reverse Tilt and the other unit in normal Tilt.

dISP (Display): In this menu you can “ip” the display 180°. Press the Up or Down buttons until “dISP” is

displayed and press Enter. Either “ON” or “OFF” will now be displayed. If you want to “ip” the display press

the Up button so that “ON” is displayed, and press Enter. Press the Menu button to exit.

rSt (Reset): In this menu you can activate reset function. Press the Press the Up of Down buttons until “rSt”

is displayed and press Enter. The unit will now begin to reset. Press the Menu button to exit.

rFAC (Default Setting): In this menu you can reset the unit to it default settings. Press the Up or Down but-

tons until “rFAC” is displayed and press Enter. Select “On” and press Enter. Press the Menu button to exit.
