Side 1/2
11 S li d @ 250 0000 1/6 SPLZ
20 Hz 50 100 200 500 1K 2K 5K 10K 20K
dBSPL
60
65
70
75
80
85
90
95
100
Ohm
8
9
10
20
30
40
50
60
70
SPL vs Freq
Nominal Impedance*
Power Rating**
Watts
Music Program
Resonance
Usable Frequency Range
Sensitivity***
Magnet Weight
Gap Height
Voice Coil Diameter
Specification
MaterialS of conStruction
MountinG inforMation
Recommended Enclosure Volume
Sealed
Vented
Driver Volume Displaced
Overall Diameter
Baffle Hole Diameter
Front Sealing Gasket
Rear Sealing Gasket
Mounting Holes B.C.D.
Depth
Net Weight
Shipping Weight
Fs
Re
Le
Qms
Qes
Qts
Vas
Vd
Cms
BL
Mms
EBP
Xmax
Sd
Xlim
tHiele & SMall paraMeterS
*
Woofer
Subwoofer
Midrange
Midbass Bass Guitar
Sealed Box
Vented Box
Scoop Loading
Horn Loading
freQuencY reSponSe & iMpedance curve
*
Very versatile and great sounding pro
audio midrange in a sealed cabinet, or as
a midbass in a vented satellite enclosure.
ALPHA-6A
6.5”, 165 mm
8 Ω
100 W
200 W
103 Hz
95 Hz – 6 kHz
93.6 dB
20 oz.
0.25”, 6.4 mm
1.5”, 38 mm
103 Hz
7.2 Ω
0.19 mH
5.68
0.6
0.54
0.2 cu.ft., 5.8 liters
44 cc
0.26 mm/N
8 T-M
7 grams
159
3.5 mm
126.7 cm2
4 mm
2.8–5.7 liters,
0.1–0.2 cu.ft.
3.4–15.6 liters,
0.12–0.55 cu.ft.
0.014 cu.ft., 0.41 liters
6.59’’, 167.4 mm
5.65’’, 143.5 mm
Yes
Yes
0.23’’, 5.8 mm
6.06’’, 153.9 mm
2.8”, 71.1 mm
4.1 lbs , 1.86 kg
4.8 lbs , 2.18 kg
Copper voice coil
Polyimide former
Ferrite magnet
Vented and extended core
Pressed steel basket
Paper cone
Cloth cone edge
Solid composition paper dust cap
American Standard series
4
4
4
4 4
learn more at eminence.com
* Please consult www.eminence.com for specifications of models with alternative
impedances.
** Multiple units exceed published ratings evaluated under EIA 426A specification while
tested in a free-air, non-temperature-controlled environment.
*** The average output across the usable frequency range when applying 1W/1m into the
nominal impedance. i.e: 2.83V/8Ω, 4V/16Ω. Eminence response curves are measured
under the following conditions: All speakers are tested at 1W/1m using a variety of test
set-ups for the appropriate impedance | LMS using 0.25" supplied microphone (software
calibrated) mounted 1m from wall/baffle | 2 ft. x 2 ft. baffle is built into the wall with
the speaker mounted flush against a steel ring for minimum diffraction | Carver PM-120
amplifier | 2700 cu. ft. chamber with fiberglass on all six surfaces (three with custom-
made wedges).
**** BETA 8CX, 10CX, and 12CX are coaxial speakers with tweeter sold separately. Published
usable frequency response contingent upon use of ASD:1001 HF Driver.
***** Multiple units exceeded published ratings evaluated under EIA-426A or AES specification
while mounted on Eminence’s H290, H290S, or H2EA horn in a non-temperature-
controlled environment.
******The average on axis output across the entire usable frequency range when applying
1W/1m into the nominal impedance, i.e. 2.83V/8Ω, 4V/16Ω. Eminence response curves
are measured under the following conditions: All speakers are tested at 1W/1m using
a variety of test set-ups for the appropriate impedance | LMS using 0.25” supplied
microphone (software calibrated) mounted 1m from wall/baffle | 2ft x 2ft baffle is built
into the wall with horn front mounted | Carver PM-120 amplifier | 2700 cu.ft. chamber
with fiberglass on all six surfaces (three with custom-made wedges).
Prices, specifications and product cosmetics are subject to change without notice.
footnotes
mission statement
Eminence is dedicated to providing the best Quality, Value and Service
to meet our customers’ needs.
From design and manufacturing to the stage or studio. Once you’ve
experienced the performance of Eminence, you’ll never accept
anything else.
eminence speaker llc
838 Mulberry Pike, Eminence, KY 40019
