Side 1/20

Index

SAFETY AND WARNING ................................................................................................................................ 2

Attention .................................................................................................................................................. 2

Safety ....................................................................................................................................................... 3

Guarantee ................................................................................................................................................ 3

OPERATING CONDITIONS ............................................................................................................................. 4

INTRODUCTION ............................................................................................................................................ 5

General Specifications ................................................................................................................................. 5

Applications 6 ..............................................................................................................................................

MPR-1 Product Family 6 .............................................................................................................................

Appearance and Interface 7 .......................................................................................................................

Terminals ...................................................................................................................................................... 7

Front Panel ................................................................................................................................................... 7

Terminal Structures 8 ..................................................................................................................................

CONNECTION ............................................................................................................................................. 12

3P4W (Three-Phase Four-Wire) Connection .........................................................................................12

3P3W (Three-Phase Three-Wire) Connection .......................................................................................13

ARON Connection .................................................................................................................................. 13

3P4W BLN (Three-Phase Four-Wire Balanced) Connection ..................................................................14

3P3W BLN (Three-Phase Three-Wire Balanced) Connection . ................................................................ 14

Communication Line Termination Resistance ....................................................................................... 15

OPERATING DEVICE .................................................................................................................................... 16

Device Communication Settings………………………………………………………………………………………………..…… …... 16

TECHNICAL INFORMATION AND ATTACHMENTS………………………………………………………………………………….17

Technical Information…………………………………………………………………………………………………………………………..17

Standards………………………………………………………………………………………………………… ………………………………….. 19

MPR-1 SERIES NETWORK ANALYZER

OPERATING MANUAL

SAFETY AND WARNING

Attention

If the following instructions are not carefully followed, the circumstances which can

cause death and serious injuries might happen.

 The installation of the device must be performed by the qualied and trained

personnel.

 Please, cut the whole power while installing the device. Please, use a suitable

circuit breaker on the installation terminal.

 You must connect the power lead-ins of the device by using a current

transformer. Do not apply direct current connection.

 Never, remove the front panel while the device is connected to the mains.

 Never, clean the device by any solvent or similar material. Only use dry cloth for

cleaning it.

 Before, turning on the device, make sure that the connections are correct.

 Please, contact your authorized dealer in case of any problem with your device.

 The device is only for interior panel type assembly. electrical / re enclosure

Only the front panel of the device should be accessible from the switchboard.

 The fuse to be used must be CATIII and F type and the current limit value

should be 1A.

 Current measurement inputs must be connected with auxiliary current

transformers which have reinforced insulation.

 The power meter shall not be used for primary protection or applications where

its failure can cause harm or death.

 Please de-energize the device before replacing RTC backup battery. It must be

Li/MnO2 battery.

The manufacturer rm cannot be held responsible in any way for any circumstance

which might arise if the aforementioned precautions are not implemented
