ENTES MPR-14S-M3609 Manual

ENTES Måleudstyr MPR-14S-M3609

Læs gratis den danske manual til ENTES MPR-14S-M3609 (20 sider) i kategorien Måleudstyr. Denne vejledning er vurderet som hjælpsom af 57 personer og har en gennemsnitlig bedømmelse på 4.4 stjerner ud af 29 anmeldelser. Har du et spørgsmål om ENTES MPR-14S-M3609, eller vil du spørge andre brugere om produktet?

Download PDF
Side 1/20
1
Index
SAFETY AND WARNING ................................................................................................................................ 2
Attention .................................................................................................................................................. 2
Safety ....................................................................................................................................................... 3
Guarantee ................................................................................................................................................ 3
OPERATING CONDITIONS ............................................................................................................................. 4
INTRODUCTION ............................................................................................................................................ 5
General Specifications ................................................................................................................................. 5
Applications.............................................................................................................................................. 6
MPR-1 Product Family ............................................................................................................................. 6
Appearance and Interface ....................................................................................................................... 7
Terminals ...................................................................................................................................................... 7
Front Panel ................................................................................................................................................... 7
Terminal Structures.................................................................................................................................. 8
CONNECTION ............................................................................................................................................. 12
3P4W (Three-Phase Four-Wire) Connection ......................................................................................... 12
3P3W (Three-Phase Three-Wire) Connection ....................................................................................... 13
ARON Connection .................................................................................................................................. 13
3P4W BLN (Three-Phase Four-Wire Balanced) Connection .................................................................. 14
3P3W BLN (Three-Phase Three-Wire Balanced) Connection................................................................. 14
Communication Line Termination Resistance ....................................................................................... 15
OPERATING DEVICE .................................................................................................................................... 16
Device Communication Settings………………………………………………………………………………………………..…….…..16
TECHNICAL INFORMATION AND ATTACHMENTS………………………………………………………………………………….17
Technical Information…………………………………………………………………………………………………………………………..17
Standards………………………………………………………………………………………………………….………………………………….19
MPR-1 SERIES NETWORK ANALYZER
OPERATING MANUAL
2
SAFETY AND WARNING
Attention
If the following instructions are not carefully followed, the circumstances which can
cause death and serious injuries might happen.
The installation of the device must be performed by the qualified and trained
personnel.
Please, cut the whole power while installing the device. Please, use a suitable
circuit breaker on the installation terminal.
You must connect the power lead-ins of the device by using a current
transformer. Do not apply direct current connection.
Never, remove the front panel while the device is connected to the mains.
Never, clean the device by any solvent or similar material. Only use dry cloth for
cleaning it.
Before, turning on the device, make sure that the connections are correct.
Please, contact your authorized dealer in case of any problem with your device.
The device is only for interior electrical / fire enclosure panel type assembly.
Only the front panel of the device should be accessible from the switchboard.
The fuse to be used must be CATIII and F type and the current limit value
should be 1A.
Current measurement inputs must be connected with auxiliary current
transformers which have reinforced insulation.
The power meter shall not be used for primary protection or applications where
its failure can cause harm or death.
Please de-energize the device before replacing RTC backup battery. It must be
Li/MnO
2
battery.
The manufacturer firm cannot be held responsible in any way for any circumstance
which might arise if the aforementioned precautions are not implemented
.
