Side 1/10

Covert Color Camera in

Working PIR Motion Detector Case

Operation Instructions

Model No. ECMD200

Please read this manual first for correct installation and operation. This manual should be retained for future

reference. The information in this manual was current when published. The manufacturer reserves the right

to revise and improve its products. All specifications are therefore subject to change without notice.

PRECAUTIONS

1. Do not install the camera near electric or magnetic fields.

Install the camera away from TV/radio transmitters, magnets, electric motors, transformers and audio

speakers since the electromagnetic fields generated from these devices may distort the video image or

otherwise interfere with camera operation.

2. Never disassemble the camera beyond the recommendations in this manual nor introduce

materials other than those recommended herein. Improper disassembly or introduction of

corrosive materials may result in equipment failure or other damage.

3. Try to avoid facing the camera toward the sun.

In some circumstances, direct sunlight may cause permanent damage to the sensor and/or internal

circuits, as well as creating unbalanced illumination beyond the capability of the camera to

compensate.

4. Keep the power cord away from water and other liquids and never touch the power cord with

wet hands. Touching a wet power cord with your hands or touching the power cord with wet hands

may result in electric shock.

5. Never install the camera in areas exposed to oil, gas or solvents.

Oil, gas or solvents may result in equipment failure, electric shock or, in extreme cases, fire.

6. Cleaning

For cameras with interchangeable lenses, do not touch the surface of the sensor directly with the

hands. Use lens tissue or a cotton tipped applicator and ethanol to clean the sensor and the camera

lens. Use a damp soft cloth to remove any dirt from the camera body. Please do not use complex

solvents, corrosive or abrasive agents for cleaning of any part of the camera.

7. Do not operate the camera beyond the specified temperature, humidity or power source ratings.

This camera is suitable for indoor operation only. Use the camera at temperatures within

-10°C~50°C (14°F~122°F) and humidity between 20%~ 80%; this device is not rated as submersible.

The input power source is 12VDC. Be sure to connect the proper + / - polarity and voltage, as

incorrect polarity or too high a voltage will likely cause the camera to fail, and such damage is

not covered by the warranty. The use of properly fused or Class 2 power limited type supplies is

highly recommended.

8. Mounting

Use care in selecting a solid mounting surface which will support the weight of the camera plus any

wind, snow, ice or other loading, and securely attach the camera to the mounting surface using screws

and anchors which will properly support the camera. If necessary (e.g. when mounting to drop ceilings)

use a safety wire to provide additional support for the camera.

OVERVIEW

The ECMD200 is a working PIR motion detector with a hidden color camera which utilizes a

Sony 1/3” Super HAD II CCD Sensor and advanced DSP solution for excellent light

sensitivity. providing well defined color and B/W video for surveillance applications. The

PIR sensor can be connected to an alarm system, light control, recording device or other

application. The camera is concealed within the device and enables surveillance of the

monitored area without reveling the fact that the area is under camera surveillance. The two

security systems combine to give improved protection in the desired area. A stylish design

combined with low current consumption delivers an excellent combination of intrusion

detection protection, image quality, value and performance.

Produkt Specifikationer

Mærke:	EverFocus
Kategori:	Overvågningskamera
Model:	ECMD200
Type:	CCTV sikkerhedskamera
Bredde:	70.104 mm
Dybde:	48.006 mm
Højde:	119.888 mm
Vægt:	130 g
Brugervejledning:	Ja
Produktfarve:	Hvid
Wi-Fi:	Ingen
Formfaktor:	Konveter
Relativ luftfugtighed ved drift (H-H):	20 - 80 %
Format til analogt signal:	NTSC, PAL
Ethernet LAN:	Ingen
Driftstemperatur (T-T):	-10 - 50 °C
Kabler inkluderet:	DC
Forbindelsesteknologi:	Ledningsført
Monteringstype:	Væg
Understøttet placering:	Indendørs
Hvidbalance:	ATW
Sensortype:	Super HAD CCD II
Støjreduktion:	Ja
Grænseflade:	BNC
Strømforbrug:	10 mA
Strøm over Ethernet (PoE):	Ingen
Bredt dynamikområde (WDR):	Ja
Dag/nat funktion:	Ja
Minimumsbelysning:	0.05 Lux
Optisk sensorstørrelse:	1/3 "
Maksimale blænderåbning tal:	2
Fast brændvidde:	3.7 mm
Nattesyn:	Ja
LED type:	IR
DC udgangsspænding:	12
Antal kameraer:	1
Kameraets lukkerhastighed:	1/50 - 1/100000 sek./side
Bevægelsessensor:	Ja
Signal/støjforhold:	52 dB
Monteringsbeslag inkluderet:	Ja
Videoudgang:	1
Kamera lukker type:	Elektronisk
Output impedans:	75 ohm (Ω)
Skruer inkluderet:	Ja
Antal TV-linier:	600
Automatisk forstærkningskontrol:	Ja
Opdagelsesafstand:	10 m
Registreringsvinkel:	100 °
NTSC opløsninger:	768 x 494 pixel
Maksimalt udgangsniveau:	1 Vpp
