Side 1/6

EVERFOCUS

1/3" CCD Outdoor Vari-Frequency IR Camera

Operation Instructions

Model No.

ECZ330E/230E

Please read this manual first for correct installation and operation. This manual should be retained

for future reference. The information in this manual was current when published. The

manufacturer reserves the right to revise and improve its products. All specifications are therefore

subject to change without notice.

PRECAUTIONS

1. Do not have camera immersed in water.

2. Do not disassemble it or place it on an unstable base.

3. Do not touch the surface of CCD sensor by hand directly.

4. Never face the camera toward the sun.

5. Use proper power source otherwise the camera will not function correctly.

6. Use the camera at temperatures within -10°C~50°C (14°F~122°F) and humidity between

20%~ 80%. The input power source is 12VDC.

INTRODUCTION

The ECZ330E/230E series of cameras contain a CCD camera in a stylish and attractive

weatherproof housing. ECZ330E/230E series uses a 1/3”Sony super HAD CCD sensor with low

Lux performance. This Day & Night camera allows users to execute 24 hours surveillance. Even

in low Lux condition (0 Lux), ECZ330E/230E camera’s performance is still brilliant.

FEATURES

z High Resolution 520 TVL (ECZ330E)

z Standard Resolution 380 TVL (ECZ230E)

z 0 Lux when IR LED is ON

z Intelligent Vari-frequency of IR control

z IP66 Weatherproof rated

z Easy installation

z Save electricity

z Auto Electronic Shutter function

z Automatic Gain Control function

z Auto White Balance function

z View angle 50~78 degree-range, IR distance 10~15 meters / 33~49 feet

z Low light sensitivity 0.4 Lux/F=1.2 (AGC ON) is achieved by using the advanced

1/3” interline transfer color CCD. – ECZ330E High Resolution model

z Low light sensitivity 0.3 Lux/F=1.2 (AGC ON) is achieved by using the advanced

1/3” interline transfer color CCD. – ECZ230E Standard Resolution model

z Lifespan of IR LED is 20,000 hours

Vari-frequency of IR control:

The brightness of IR LED will be adjusted according to environment’s lighting. When the

environment is dark, LED’s brightness will be increased. By contrast, when the environment

is brilliant, LED’s brightness to save power consumption. will be decreased, as a result

When an object approaches the camera, LED’s brightness will automatically be adjusted as

well. Consequently, image will not be overexposed nor result vibration.

PACKAGE LIST

z Camera unit

z Operation Instructions (this document)

z Sun shield

z Mounting bracket

Produkt Specifikationer

Mærke:	EverFocus
Kategori:	Overvågningskamera
Model:	ECZ230
Kode for international beskyttelse (IP):	IP66
Bredde:	50 mm
Højde:	80 mm
Vægt:	181 g
Produktfarve:	Sølv
Wi-Fi:	Ingen
Formfaktor:	Kugle
Relativ luftfugtighed ved drift (H-H):	20 - 80 %
Format til analogt signal:	NTSC, PAL
Ethernet LAN:	Ingen
Strømforbrug (typisk):	3 W
Driftstemperatur (T-T):	-10 - 50 °C
Maksimal opløsning:	- pixel
Forbindelsesteknologi:	Ledningsført
Webbaseret administration:	Ingen
Indbygget kortlæser:	Ingen
Indbygget HDD:	Ingen
Effektkrav:	12 - 24 VAC
Understøttet placering:	Udendørs
Hvidbalance:	Automatisk
Sensortype:	CCD
Optisk zoom:	- x
Grænseflade:	BNC
Strøm over Ethernet (PoE):	Ingen
Minimumsbelysning:	0 Lux
Optisk sensorstørrelse:	1/3 "
Nattesyn:	Ja
LED type:	IR
Infrarød bølgelængde:	850 nm
Kameraets lukkerhastighed:	1/60 - 1/100000 sek./side
Signal/støjforhold:	48 dB
Kamera lukker type:	Elektronisk
Nattesyn, afstand:	15 m
Antal TV-linier:	380
NTSC opløsninger:	510 x 494 pixel
PAL opløsninger:	500 x 582 pixel
