Side 1/9

Indoor DWDR 3-Axis Varifocal

700TVL IR Dome Camera

Operation Instructions

Model No. ED640

Please read this manual first for correct installation and operation. This manual should be

retained for future reference. The information in this manual was current when published.

The manufacturer reserves the right to revise and improve its products. All specifications are

therefore subject to change without notice.

PRECAUTIONS

1. Do not install the camera near electric or magnetic fields.

Install the camera away from TV/radio transmitters, magnets, electric motors, transformers and

audio speakers since the electromagnetic fields generated from these devices may distort the

video image or otherwise interfere with camera operation.

2. Never disassemble the camera beyond the recommendations in this manual nor introduce

materials other than those recommended herein. Improper disassembly or introduction of

corrosive materials may result in equipment failure or other damage.

3. Try to avoid facing the camera toward the sun.

In some circumstances, direct sunlight may cause permanent damage to the sensor and/or

internal circuits, as well as creating unbalanced illumination beyond the capability of the camera

to compensate.

4. Keep the power cord away from water and other liquids and never touch the power cord

with wet hands. Touching a wet power cord with your hands or touching the power cord with

wet hands may result in electric shock.

5. Never install the camera in areas exposed to oil, gas or solvents.

Oil, gas or solvents may result in equipment failure, electric shock or, in extreme cases, fire.

6. Cleaning

For cameras with interchangeable lenses, do not touch the surface of the sensor directly with the

hands. Use lens tissue or a cotton tipped applicator and ethanol to clean the sensor and the

camera lens. Use a damp soft cloth to remove any dirt from the camera body. Please do not use

complex solvents, corrosive or abrasive agents for cleaning of any part of the camera.

7. Do not operate the camera beyond the specified temperature, humidity or power source

ratings. This camera is suitable for indoor operation only. Use the camera at temperatures within

-10° ~ +50° (14

℉

~122

℉

) and humidity between 30% and 90%. The input power source is

12VDC. Regulated power supply required.

8. Mounting

Use care in selecting a solid mounting surface which will support the weight of the camera plus

any wind, snow, ice or other loading, and securely attach the camera to the mounting surface

using screws and anchors which will properly support the camera. If necessary (e.g. when

mounting to drop ceilings) use a safety wire to provide additional support for the camera.

Table of Contents

Product Overview ………………………………………………………………… 2

Main Features ……………………………………………………………………... 2

Box Contents ……………………………………………………………………….. 2

Specifications…………………………………………………………………….... 3

Dimensions ………………………………………………………………………... 4

Installation ………………………………………………………………………… 5

OSD Menu Controls and Test Point ……………………………………………….. 5

Lens Adjustment…………………………………………….………………………. 5

Menu Setting ………………………………………………………………………..... 6

Product Overview

Get superior performance and high resolution images in bright light or no light. The EverFocus ED640 uses a Sony

Super HAD II Color CCD to produce high quality color images with a minimum of 630 horizontal TV lines of resolution.

Combine this with digital day/night, a native low light sensitivity of 0.01 lux, and 24 IR LEDs with a range of 82 feet

(depending on scene IR reflectivity), a 3-axis wall or ceiling mount indoor plastic housing and you have a cost effective

camera that fits a wide variety of indoor applications. The ED640 comes with a 2.8~12mm VF AI lens that covers a

field of view up to 82° wide, or can magnify images for increased detail. With low 12VDC current draw, this is the

camera that you have been waiting for to create analog CCTV systems that deliver superior image clarity in a wide

range of indoor applications at virtually any light level.

Features

• 1/3” Sony Super HAD II Color CCD with high resolution of 700TVL for high image clarity

• Full OSD with features like DWDR, HLC/BLC, DNR, Anti-Color-Roll and more

• 2.8~12mm VF AI lens covers from wide angle of 82° to moderate telephoto field of view

• 3-Axis camera mount for flexible mounting and positioning

• 24 smart IR LEDs with range of 82 feet for long distance coverage

• Smart LEDs avoid over exposure of close in objects

• Digital Day/Night for color in bright light, IR illuminated B/W in low light

• DC12V only 320mA draw

Box Contents

Camera

User Guide

Mounting Screw (3)

Power adaptor pigtail

Housing Opener

Mounting template

Video Test Point Cable

Produkt Specifikationer

Mærke:	EverFocus
Kategori:	Overvågningskamera
Model:	ED640
Type:	CCTV sikkerhedskamera
Højde:	87 mm
Vægt:	205 g
Brugervejledning:	Ja
Produktfarve:	Hvid
Wi-Fi:	Ingen
Formfaktor:	Kuppel
Opbevaringstemperatur (T-T):	-20 - 60 °C
Relativ luftfugtighed ved drift (H-H):	0 - 90 %
Format til analogt signal:	NTSC
Ethernet LAN:	Ingen
Driftstemperatur (T-T):	-10 - 50 °C
Maksimal opløsning:	768 x 494 pixel
Understøttelse af sprog:	CHI (SIMPL), CHI (TR), DEU, ENG, ESP, FRE, JPN, POL, POR
Forbindelsesteknologi:	Ledningsført
Certificering:	CE, FCC
Monteringstype:	Loft/væg
Diameter:	112 mm
Full HD:	Ingen
Understøttet placering:	Indendørs
Hvidbalance:	Automatisk
Sensortype:	Super HAD CCD II
Støjreduktion:	Ja
Strømforbrug:	320 mA
Strøm over Ethernet (PoE):	Ingen
Bredt dynamikområde (WDR):	Ja
Dag/nat funktion:	Ja
Minimumsbelysning:	0 Lux
Optisk sensorstørrelse:	1/3 "
Nattesyn:	Ja
LED type:	IR
Fortrolighedspolitik maskering:	Ja
DC udgangsspænding:	12
Antal kameraer:	1
Synsfelt vinkel (FOV):	82 °
Infrarød bølgelængde:	850 nm
Brændviddeområde:	2.8 - 12 mm
Bevægelsessensor:	Ja
Signal/støjforhold:	52 dB
Videoudgang:	NTSC CVBS
Output impedans:	75 ohm (Ω)
Antal lysende LED:	24
Nattesyn, afstand:	25 m
Skruer inkluderet:	Ja
Antal TV-linier:	700
Automatisk forstærkningskontrol:	Ja
Flip & spejl:	Ja
Antal sprog:	8
Maksimalt udgangsniveau:	1 Vpp
