Side 1/12

EVERFOCUS

1/3” Color Rugged Dome Camera

Operation Instructions

Model No.

EHD300N

Please read this manual first for correct installation and operation. This manual should be retained

for future reference. The information in this manual was current when published. The

manufacturer reserves the right to revise and improve its products. All specifications are therefore

subject to change without notice.

PRECAUTIONS

1. Do not install the camera near electric or magnetic fields.

Install the camera away from TV, radio transmitter, magnet, electric motor, transformer,

audio speakers since the magnetic fields generate from above devices will distort the video

images.

2. Never disassemble the camera nor put impurities in it.

Disassembly or impurities may result in trouble or fire.

3. Never face the camera toward the sun.

Direct sunlight or severe ray may cause fatal damage to sensor and internal circuit.

4. Keep the power cord away from water and liquid.

Touching the wet power cord may result in electric shock.

5. Never install the camera in areas exposed to water, oil or gas.

Water, oil or gas may result in failure, electric shock or fire.

6. Cleaning

Do not touch the surface of sensor by hand directly. Use a soft cloth to remove the dirt from

the camera body. Use lens tissue or a cotton swab and ethanol to clean the sensor and the

camera lens.

7. Do not operate the camera beyond the specified temperature, humidity or

power source ratings.

Use the camera at temperatures within –10℃~ 50℃/14℉

~ 122℉ and humidity between

20%~ 80%. The input power source is 12VDC/24VAC.

PREFACE

The most technically advanced EHD series are the newest vandal-resistant Color Rugged

Dome Camera from EverFocus Electronics. The Color Rugged Dome Camera can withstand

a blow from a 10-pound sledgehammer and has a built-in heater that allows for operation in

low temperatures. It is perfect for all high-profile crime-prone applications such as building

entrances, retail stores, and shopping malls. EHD series are unquestionably one of the

world's toughest cameras and is your best choice for vandal resistance.

FEATURES

z 1/3” SONY Super HAD color CCD pick up device for more than 520 TV lines of

horizontal resolution

z Low light sensitivity of 0.4 lux/F=1.2 is achieved by using 1/3” SONY Super HAD

interline transfer color CCD

z The electronic shutter and AGC allow the camera to be used in environment with

varying light levels

z 12VDC/24VAC switches automatically power supply

z S/N Ratio reaches 48 dB or more

z Built-in Vari-focal lens

z Flickerless, Mirror, AGC and BLC ON/OFF switchable

z With manual Pan/Tilt mechanism

z Rugged dome designed for vandal proof

z Rugged Dome designed with 3-axis which provides the best installation for ceiling

and wall mount

z IP66 weatherproof

Produkt Specifikationer

Mærke:	EverFocus
Kategori:	Overvågningskamera
Model:	EHD300
Kode for international beskyttelse (IP):	IP66
Bredde:	130 mm
Dybde:	130 mm
Højde:	98.8 mm
Vægt:	1700 g
Produktfarve:	Hvid
Wi-Fi:	Ingen
Formfaktor:	Kuppel
Relativ luftfugtighed ved drift (H-H):	20 - 80 %
Format til analogt signal:	NTSC, PAL
Ethernet LAN:	Ingen
Strømforbrug (typisk):	4 W
Driftstemperatur (T-T):	0 - 40 °C
Maksimal opløsning:	- pixel
Forbindelsesteknologi:	Ledningsført
Webbaseret administration:	Ingen
Indbygget kortlæser:	Ingen
Indbygget HDD:	Ingen
Effektkrav:	12 - 24 VAC
Understøttet placering:	Udendørs
Hvidbalance:	Automatisk
Sensortype:	CCD
Optisk zoom:	- x
Grænseflade:	BNC
Strøm over Ethernet (PoE):	Ingen
Minimumsbelysning:	0.4 Lux
Optisk sensorstørrelse:	1/3 "
Brændviddeområde:	2.9 - 10 mm
Kameraets lukkerhastighed:	1/60 - 1/100000 sek./side
Signal/støjforhold:	48 dB
Kamera lukker type:	Elektronisk
Antal TV-linier:	520
NTSC opløsninger:	768 x 494 pixel
PAL opløsninger:	752 x 582 pixel
