EVERFOCUS

Dual Power High Resolution Vandal Proof

Weather Resistant 3-Axis IR Dome Camera

Operation Instructions

Model No. E 3HD36

Please read this manual rst for correct installation and operation. This manual should be retained for

future reference. The information in this manual was current when published. The manufacturer reserves

the right to revise and improve its products. All specications are therefore subject to change without

notice.

PRECAUTIONS

1. Do not install the camera near electric or magnetic fields.

Install the camera away from TV/radio transmitters, magnets, electric motors, transformers and audio

since the electromagnetic fields generated from these devices may distort the video image or otherwise

with camera operation.

2. Never disassemble the camera beyond the recommendations in this manual nor introduce materials

other than those recommended herein.

Improper disassembly or introduction of corrosive materials may result in equipment failure or other damage.

3. Try to avoid facing the camera toward the sun.

In some circumstances, direct sunlight may cause permanent damage to the sensor and/or internal circuits, as

well as creating unbalanced illumination beyond the capability of the camera to compensate.

4. Keep the power cord away from water and other liquids and never touch the power cord with wet

hands.

Touching a wet power cord with your hands or touching the power cord with wet hands may result in electric

shock.

5. Never install the camera in areas exposed to oil, gas or solvents.

Oil, gas or solvents may result in equipment failure, electric shock or, in extreme cases, fire.

6. Cleaning

For cameras with interchangeable lenses, do not touch the surface of the sensor directly with the hands. Use

lens tissue or a cotton tipped applicator and ethanol to clean the sensor and the camera lens. Use a damp soft

cloth to remove dirt from the camera body. Please do not use complex solvents, corrosive or abrasive any

agents for cleaning of any part of the camera.

7. Do not operate the camera beyond the specified temperature, humidity or power source ratings. This

camera is suitable for indoor and outdoor operation.

Use the camera at temperatures within -10°C to +50°C (14°F to 122°F) and in an IP66 compliant environment;

this device is not rated as submersible. The input power source is 12VDC or AC24V. Be sure to connect the

proper voltage, as too high a voltage will likely cause the camera to fail, and such damage is not

covered by the warranty. The use of properly fused or Class 2 power limited type supplies is highly

recommended. Regulated supply is required for 12VDC operation.

8. Mounting

Use care in selecting a solid mounting surface which will support the weight of the camera plus any wind,

snow, ice or other loading, and securely attach the camera to the mounting surface using screws and anchors

which will properly support the camera. If necessary (e.g. when mounting to drop ceilings) use a safety wire to

provide additional support for the camera.

OVERVIEW

The EHD363 an outdoor, vandal resistant 3-axis IR dome camera which utilizes a 960H is Sony 1/3”

Exview HAD CCD Sensor and enhanced Efo-E DSP to provide high resolution 700TVL color video

for security surveillance applications. Advanced functions including Digital WDR/ATR (Adaptive Tone

Reproduction), 2D-NR (2D Noise Reduction) and Anti CR (Anti Color Rolling) insure optimum image

quality under low or unbalanced lighting conditions. Vandal Proof materials and an IP66 weather

resistant housing allow reliable operation in outdoor and indoor environments. True day/night operation

combined with 30m (~98ft.) range high efciency IR LEDs makes the EHD363 suitable for a wide range

of day and night surveillance situations. Plus, dual voltage 12VDC/24VAC operation, 3-axis mechanical

design and built-in f=3.7~12mm varifocal auto iris lens bring exibility to installation and eld of view

adjustment.

FEATURES

 Sony 960H EXview HAD II high resolution CCD sensor for 700TVL images 1/3”

 Employs Sony Enhanced Efo-E Digital Signal Processor (DSP) chip-set for advanced image

processing.

 Built-in Auto Gain Control (AGC), Auto Tracing White Balance (ATW) enhance image quality

 Advanced DSP functions enhance image quality: Digital WDR/ATR (Adaptive Tone Reproduction),

2D-NR (2D Noise Reduction), Anti CR (Anti Color Rolling)

 Varifocal DC iris 3.7~12mm lens and 3-Axis design for exible eld of view adjustment

 Eleven high efciency IR LEDs with 30m (~98 .) range in for low/no light applications ft

 True day/night auto switching for best day time color and low light performance

 Vandal proof to withstand impact of a 10 pound sledgehammer.

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION:

TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE

COVER (OR BACK), NO USER SERVICEABLE PARTS INSIDE.

REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

Produkt Specifikationer

Mærke:	EverFocus
Kategori:	Overvågningskamera
Model:	EHD363
Kode for international beskyttelse (IP):	IP66
Type:	CCTV sikkerhedskamera
Vekselstrømsindgangsspænding:	24 V
Højde:	115.5 mm
Vægt:	979 g
Produktfarve:	Hvid
Wi-Fi:	Ingen
Formfaktor:	Kuppel
Format til analogt signal:	NTSC
Ethernet LAN:	Ingen
Strømforbrug (typisk):	8 W
Driftstemperatur (T-T):	-10 - 50 °C
Maksimal opløsning:	976 x 494 pixel
Beskyttelsesfunktioner:	Hærværkssikret
Kabler inkluderet:	BNC, DC
Forbindelsesteknologi:	Ledningsført
Certificering:	CE, FCC
Monteringstype:	Loft/væg
Diameter:	142 mm
Full HD:	Ingen
Understøttet placering:	Udendørs
Hvidbalance:	ATW
Sensortype:	HAD CCD II
Støjreduktion:	Ja
Grænseflade:	BNC
Strømforbrug:	283 mA
Strøm over Ethernet (PoE):	Ingen
Bredt dynamikområde (WDR):	Ja
Dag/nat funktion:	Ja
Infrarød (IR) cut-off filter:	Ja
Vandafvisende:	Ja
Minimumsbelysning:	0 Lux
Optisk sensorstørrelse:	1/3 "
Maksimale blænderåbning tal:	1.4
Nattesyn:	Ja
LED type:	IR
DC udgangsspænding:	12
Antal kameraer:	1
Infrarød bølgelængde:	850 nm
Brændviddeområde:	3.7 - 12 mm
Kameraets lukkerhastighed:	1/60 - 1/100000 sek./side
Signal/støjforhold:	54 dB
Output impedans:	75 ohm (Ω)
Antal lysende LED:	11
Nattesyn, afstand:	30 m
Skruer inkluderet:	Ja
Antal TV-linier:	700
Automatisk forstærkningskontrol:	Ja
Iris:	Ja
Maksimalt udgangsniveau:	1 Vpp
