Side 1/15

2 Megapixel Full HD-CCTV

Camera

Operation Instructions

Model No. EQH5200

Please read this manual first for correct installation and operation. This manual should be retained for future

reference. The information in this manual was current when published. The manufacturer reserves the right

to revise and improve its products. All specifications are therefore subject to change without notice.

PRECAUTIONS

1. Do not install the camera near electric or magnetic fields.

Install the camera away from TV/radio transmitters, magnets, electric motors, transformers and audio

speakers since the electromagnetic fields generated from these devices may distort the video image.

2. Never disassemble the camera beyond the recommendations in this manual nor introduce

materials other than those recommended herein.

Improper disassembly or introduction of corrosive materials may result in equipment failure or other

damage.

3. Try and avoid facing the camera toward the sun.

In some circumstances, direct sunlight may cause permanent damage to the sensor and/or internal

circuits.

4. Keep the power cord away from water and other liquids and never touch the power cord with

wet hands.

Touching a wet power cord with hands or touching the power cord with wet hands may result in electric

shock.

5. Never install the camera in areas exposed to water, oil or gas.

Water, oil or gas may result in equipment failure, electric shock or, in extreme cases, fire.

6. Cleaning

Do not touch the surface of the sensor directly with the hands. Use a damp soft cloth to remove any

dirt from the camera body. Use lens tissue or a cotton tipped applicator and ethanol to clean the sensor

and the camera lens. Please do not use complex solvents, corrosive or abrasive agents for cleaning.

7. Do not operate the camera beyond the specified temperature, humidity or power source ratings.

Use the camera at temperatures within 0℃ ~ 45℃ (32℉~113℉) and humidity between 20~80%.

The input power source is 12VDC/24VAC.

- 1 -

TABLE OF CONTENTS

1. PRODUCT OVERVIEW...............................................................................................................2

1.1 Main Features ............................................................................................................................................... 2

1.2 Package Contents.......................................................................................................................................... 2

1.3 Specifications ................................................................................................................................................ 3

1.4 Dimensions ................................................................................................................................................... 3

2. NAMES AND FUNCTIONS OF PARTS .........................................................................................4

2.1 Front panel.................................................................................................................................................... 4

2.2 Top/Bottom Mounting ..................................................................................................................................... 4

2.3 Back panel and connections ........................................................................................................................... 5

3. INSTALLATION...........................................................................................................................6

4. OSD Menu & Configuration..........................................................................................................7

4.1 Exposure .................................................................................................................................................... 10

4.1.1 Lens ........................................................................................................................................................ 10

4.1.2 Shutter..................................................................................................................................................... 10

4.1.3 Iris ........................................................................................................................................................... 10

4.1.4 AGC (Auto Gain Control – basic low light signal amplification) ....................................................................... 10

4.1.5 BLC ......................................................................................................................................................... 10

4.1.6 Anti-Flicker ................................................................................................................................................11

4.2 White Balance Control...................................................................................................................................11

4.3 Day/Night.....................................................................................................................................................11

4.4 Special........................................................................................................................................................ 12

4.4.1 Resolution ................................................................................................................................................ 12

4.4.2 Camera Title............................................................................................................................................. 12

4.4.3 D-Effect.................................................................................................................................................... 12

4.4.4 TV standard.............................................................................................................................................. 13

4.4.5 Language................................................................................................................................................. 13

4.4.6 Default ..................................................................................................................................................... 13

4.5 Image Adjust ............................................................................................................................................... 13

4.5.1 Sharpness................................................................................................................................................ 13

4.5.2 Brightness ................................................................................................................................................ 13

4.5.3 Contrast ................................................................................................................................................... 13
