Dear Purchaser!
The operation manual reflects peculiar technical features of the automatic washing machine (hereinafter
referred to as the machine), it contains the required information about its operation, the useful information
about washing. After attentively studying the operation manual before connecting and using the machine,
you will be able to properly and safely operate it..
Keep the operation manual during the whole period of its service.
1 G E N E R A L
1.1In accordance with figure 1 the automatic washing machine (hereinafter referred to as the machine) is
intended for washing textile goods, sports footwear with the use of synthetic washing means of low foaming, as
well as for rinsing and wringing out. All operations of treating the goods are automatically performed in compliance
with the preset program.
1.2 The machine is intended for operation only in household conditions. The use for industrial purposes (in
restaurants, cafes, offices, kinder gardens, hospitals, etc.) is not allowed.
1.3 Modern washing technologies are used in the machine which allow to achieve maximal results of washing
with the minimal consumption of water and electrical power. Therefore, when the machine operates, the water level
may not visually be determined through the door glass.
1.4 The electronic control system is stipulated in the machine which contributes to uniform distribution of the
linen in the drum before every wringing out for exclusion of excessive vibrations and noise.
1.5 The protecting system in the filling hose stipulated in the machine depending on the model determines the
water leakage when the hose is damaged – water supply is terminated to the machine from the water line, washing
is stopped and a malfunction is shown on the display.
1.6 An additional protecting system “Aquastop” preventing water leakage inside the machine, which is stipulated
in some models, stops water supply from the water line to the machine when the latter is damaged – washing is
stopped, water is drained from the tank and a malfunction is shown on the display
Figure 1
Dispenser drawer
Filter cap
Door
Gasket
Drum
Control panel
