Side 1/4

IMPORTANT:

Go to www.extron.com for the complete

user guide,

installation instructions,

and

specifications bef

ore connecting the

oduct to the po

wer source.

DSC HD-3G A Scaler • Setup Guide

The Extron DSC HD-3G A is an HDMI to 3G-SDI scaler that converts HDMI signals to 3G-SDI, HD-SDI, and SD-SDI. It accepts

computer and SMPTE video resolutions up to 1920x1200 and 2K, and offers multiple output rates from 480i up to HDTV

1080p @ 60 Hz and 2K. The DSC HD-3G A features advanced Extron video signal processing with 1080i deinterlacing and Deep

Color processing for optimal image quality. Dual SDI outputs, stereo audio embedding, and genlock are also provided. This

setup guide provides step-by-step instructions for an experienced user to set up and configure a DSC HD-3G A. It covers how to

perform basic operations using the front panel controls and selected Simple Instruction Set™ (SIS™) commands.

NOTE: For full installation, configuration, menu, connector wiring, and operation details, see the DSC 3G-HD A and

DSC HD-3G A User Guide, available at www.extron.com.

Installation

Rear Panel Features

Mounting and Cabling the DSC HD-3G A

1. Disconnect power — Turn off or disconnect all equipment power sources.

2. Mount the unit: (Optional) Mount the DSC HD-3G A either in a rack using

shelf mounting brackets (RSU 129 or RSB 129) or under furniture using

furniture mounting brackets (MBU 125) (see gures 1 and 2 at right). A false

half-rack faceplate can be tted next to the DSC if desired.

3. Connect the input — Connect an HDMI video source to the HDMI input

connector C.

4. Connect analog audio input — (Optional) Connect analog audio from the

source to the captive screw audio input connector B.

NOTE: To embed audio from this input, set it up using the on-screen

display SIS commands

(OSD) (see page 2) or (see page 4).

5. Connect the output — Connect one or two SDI display devices to the

3G/HD/SD-SDI output connectors E for SDI output with optional embedded

analog or HDMI audio.

6. Connect a sync device — (Optional) Attach an external sync device

to the input (right) Sync connector (D). Connect any downstream

device to be synchronized by genlocking to the output (left) Sync

connector (D).

7. Connect a control device — For remote control via SIS commands

or the PCS Windows®-based control software:

zRS-232 — For serial RS-232 control, connect a host computer or

control system to the 3-pole captive screw RS-232 connector F.

RS-232 protocol default values are 9600 baud, 1 stop bit, no

parity, 8 data bits, no ow control.

zUSB — Connect a host computer or control system to the front

panel mini USB port (B in the front panel illustration on page 2)

for conguration and control via Extron PCS software.

8. AC power connector — Connect the supplied US IEC power cord

to this connector A from a 110-220 V, 50-60 Hz AC, power source.

Figure 2. Under-furniture Mounting

DVC 50 1 SD

DIGI

TAL V

EO CO NVERTER

(2) 4-40 x 3/16" screws

Use 2 mounting holes on

opposite corners.

Half-rack

false front panel

uses 2 front holes.

A AC power connector

B 5-pole captive screw audio input

connector

C HDMI video input connector

D Genlock sync connectors

E 3G/HD/SD-SDI output connectors

F 3-pole RS-232 captive screw

connector

AA BB CC DD EE FF

100-240V ~ .3A MAX

50-60 Hz

DSC HD-3G A

REMOTEOUTPUT

HDMI 3G/HD/SD-SDI

SYNC

AUDIO

INPUT

GENLOCK

RS-232

Tx Rx G

MBU 125 Mounting Bracket

#8 Screw

(4) Places

Each Side

Mounting

Screws

(2) Places

Each Side

Figure 1. Rack Mounting

DSC HD-3G A • Setup Guide (Continued)

Front Panel Overview

DSC HD-3G A

AUTO-


Ext nro MENU

ENTER HOLD FOR 720p 1080i

INPUT OUTPUT

SYNC

2.97 Gbps

1.485 Gbps

270 Mbps

SIGNAL

2CH-LPCM

MULTI-CH PCM

ANALOG

CONFIG

AA BB CC DD EE FF

A — Lights amber steadily when there is power but no signal, blinks amber every 3 seconds when the unit is in Status LED

standby mode, and lights green steadily when both power and an input signal are present.

B — Connect a control system or computer to this mini USB port (cable not supplied) for device USB configuration port

configuration, control, and firmware upgrading.

C — The Signal LED lights to indicate presence of an HDMI input signal. An audio signal LED (2CH-LPCM, Multi-Input LEDs

CH PCM, or Analog) lights to indicate the type of audio signal (two-channel LPCM, multi-channel PCM, or analog) if present.

D — Light to indicate the presence of sync and the rate specified for the output:Output LEDs

zSync: Sync is present (does not light if video sync is muted).

z2.97 Gbps: SMPTE 424M

z1.485 Gbps: SMPTE 292M

z270 Mbps: SMPTE 259M

E — Let you access the OSD and select submenus and items from the menus.Menu and Enter buttons

F — Press these , , Navigation buttons   , and arrow buttons to step through the OSD 

submenus, to lock the front panel (see the next section), perform Auto-Image (press ), and reset the output rate (hold for 

5 seconds).

Locking the Front Panel (Executive Mode)

To prevent unauthorized access or accidental changes to DSC settings, you can lock the front panel controls, making control

available only by SIS commands. (The default state is unlocked.) You can lock and unlock the front panel as follows:

zUsing the front panel buttons: lock To , press the and buttons simultaneously and hold them until the OSD 

displays (approximately 5 seconds). To , repeat this process. unlock

zSIS commands: lock To (enable executive mode), enter . To (disable executive mode), enter .unlock

Conﬁguring the DSC HD-3G A

The DSC HD-3G A can be configured through a host connected to

the RS-232 or USB port, using Extron PCS configuration software

(available at no charge at www.extron.com SIS commands) or

(see page 4 for a selection of basic commands). You can also

configure it using the OSD menu system, described below.

On-Screen Display (OSD) Menu System

The OSD menu system consists of seven submenus and two

information screens. To access the menus, press the front panel

button. With the main menu displayed, use the arrow

buttons to step through the submenus and submenu items.

Press the button to select the item that you highlight. The

and screens are read-only and do

not provide selections.

• • • Setup

• • •

NOTE: The OSD times out and closes after 1 minute if no

buttons are pressed.
