1
IMPORTANT:
I
I
I
IM
M
M
MP
P
P
PO
O
O
ORT
RT
RT
RTA
A
A
AN
N
N
NT:
T:
T:
T:
Go to for the
complete user guide, installation
instructions, and specifications.
www.extron.com
EWB 210 Series • Installation Guide
Overview
The Extron EWB 210 Series consists of a one-gang (EWB 211),
a two-gang (EWB 212), and a three-gang (EWB 213) EU external
wall box. These boxes provide complete compatibility in t
and nish with Extron Flex 55 and EU devices and assist with
cable management. Figure 1 shows a typical application for the
EWB 212.
This guide provides basic instructions for installation of all three
models by an experienced installer.
Equipment Needed But Not Provided
• •
Stud detector Cable raceway (optional)
• • Electric drill Fasteners for wall mounting
(see the table below)
• Screwdriver
• Small wire cutters
O FFO N
VIDEO
VOL
PC
VO L
OFF
ON
VIDEO
VOL
PC
VOL
MLC 55 RS EU
EWB 212
Figure 1. Typical Application for EWB 210 Series Wall Box
EWB 210 Series Mounting Holes
EWB 210 series boxes can be mounted directly to the wall, or an EU junction box. Use the mounting holes shown in gure 2.
EWB 211
A
A
A
A
A
A
B
B
B
B
B
B B
B
B
B
B
B
C
C
C
C
C
C
D
D
D
D
D
D
E
E
E
E
E
E
F
F
F
F
F
F
EWB 212
A
A
A
A
A
A A
A
A
A
A
A
B
B
B
B
B
B B
B
B
B
B
B
C
C
C
C
C
C
D
D
D
D
D
D
E
E
E
E
E
E
F
F
F
F
F
F
F
F
F
F
F
F
EWB 213
A
A
A
A
A
A A
A
A
A
A
AC
C
C
C
C
C
D
D
D
D
D
D
E
E
E
E
E
E
F
F
F
F
F
F
F
F
F
F
F
FB
B
B
B
B
B
B
B
B
B
B
B
Figure 2. EWB 210 Series Mounting Holes
A Device mounting holes —
EWB 211 has two, EWB 212
has four, and EWB 213 has six.
Use M3 screws.
B EU junction box mounting holes
— all three models have two
(60 mm center to center).
C Wall mounting holes — all three
models have four holes.
Use screws and fasteners that
are appropriate for the wall (see
table below).
D Hole for optional M3 hex
grounding screw.
E Hole for optional #6 hex
grounding screw.
NOTE: The nuts and
screws are not provided.
F Knockout covers —
EWB 211 has two, EWB 212
and EWB 213 have four (see
Knockout Covers on the next
page).
Wall Type Fastener Minimum Size
Fastener
Quantity Drill Bit Size Notes
Drywall Toggle bolts 3/16 inch (4.76 mm) at least 2 1/2 inch (12.7 mm) Wall thickness 3/8 inch (9.5 mm)
minimum
Solid wood Wood screws #6 at least 2 1/8 inch (3.18 mm)
Masonry 3/16 inch (4.76 mm) at least 2 Do not mount to masonry joints.Masonry screws 5/32 inch (4.0 mm) masonry bit
268-2875-01 B 07 22
EWB 210 Series • Installation Guide (Continued)
© 2016 - 2022 Extron All rights reserved. All trademarks mentioned are the property of their respective owners. www.extron.com
Installation
The EWB 210 series wall boxes can be mounted directly to a wall or to an existing in-wall
EU junction box. The illustrations for this procedure show the EWB 212. Mount the EWB
211 and EWB 213 in the same way.
Decide where to mount the wall box and how to run cables to it. You can use any of the
two openings in the EWB 211 (right and left sides) or four openings in the EWB 212 and
EWB 213 (one on each side) with a surface raceway.
Fill any unused openings with knockout covers, as described below.
Knockout Covers
The rear panel has two (EWB 211) or four (EWB 212 and EWB 213) covers that can be
removed to ll the openings that are not used.
1. Use small wire cutters to cut the plastic attaching the knockout cover to the wall box.
2. Ensure the knockout cover is in the correct orientation and slide it into place.
NOTE: The larger knockout covers have smaller knockouts nested inside.
mall wire
s to r
emove
out cover.
U
se s
m
cutte
r
s
k
nock
o
knockout
onto slots.
Slide
k
co
v
e
r
o
2
Figure 3. Covering Knockouts
(Rear View)
Wall Mounting
1. If required, locate the center of a wall stud and hold the wall box
where it will be mounted.
2. Mark the position of the four wall mounting holes (see gure 4).
Wall studs should be used where possible. If they are not
available, use appropriate fasteners to secure the screws.
3. Select a suitable fastener and drill the holes (see the wall
mounting holes table on the previous page).
4. If required, insert a grounding screw (not provided, see figure 2,
D and E on the previous page).
5. Fasten the wall box to the wall.
6. If required, install a cable raceway to manage the cables.
Wall Stud
Figure 4. Wall Mounting
Mounting to an Existing In-wall
EU Junction Box
EWB
EU Box
212 M3 mounting holes (4)
Figure 5. Mounting to an Existing EU Junction Box
1. Align the mounting holes of the wall box with the two holes in the EU
junction box (see , figure 2 B and gure 5).
2. Secure the wall box to the junction box, using M3 screws.
Completing the Installation
1. Run and connect cables to the device following the instructions in the
device user guide.
2. Mount the device (see gure 6).
MLC 55 RS EU
EWB 212
RESET
OFF
ON
Figure 6. Completing the Installation
