IMPORTANT:

Go to www.extron.com for the

complete user guide, installation

instructions, and specifications.

TMK Series • Installation Guide

The TMK series Table Mount Kits allow under-table installation for up to two single-space

AAPs (TMK120AAP) or up to three single-space AAPs (TMK130AAP). Both kits secure

to the underside of a table. The kits can also be mounted side-by-side for applications

requiring additional AAP spaces.

NOTE: The location must consider that cables are connected to the AAPs both from

the front and from the rear, and the bracket and AAPs must be readily visible to

prevent accidental contact.

ATTENTION: Do not drill through the table or furniture. If the table is too thin or of a

different material for the supplied screws, use an appropriate type and length.

USB

CHAR G

Install #6 x 1/2 inch wood screws

into the pilot holes.

Tighten until 1/4 inch protrudes.

Drill 3/32-inch (2.4 mm) diameter,

1/4 inch (6.3 mm) deep pilot

holes.

Mark the four yhole locations at ke

the desired mounting location.

Install AAPs in the faceplate.

(4)

#4 x 1/4" (2)

Sheet Metal Screws

#6 x 1/2" (4)

Wood Screws

Co rve

aceplate

Included sPart

Mount the TMK bracket as follows:

USB CHARGER

Tighten

USB CHARGER

Slide the faceplate onto the screws.

Tighten the front yhole screws onlyke .

Connect the cables and wiring

to the AAPs.

Install the two sheet metal screws to

secure the faceplate and cover

together.

Tighten the two rear yhole screwske

through the openings in the cover.

Faceplate

Screws (2)

Slide the co r up and into the ceplatve fa e.

Ma ce ain the rear slots of the co rke rt ve

slide into the rear hole screws.key
