Side 1/24

Instructions

for the use and installation

of gas cookers

Notice d’emploi

pour l’installation et l’utilisation

des cuisinieres à gaz

2GB

MODELS SPECIFICATIONS

Fig. 1

INSTRUCTION FOR USE

COOK-TOP

This owner’s manual is valid for the Country mentioned on

the appliance.

Keep this manual close to hand and preserve it for any further

consultation.

The packing components (plastic bags, foamed polystyrene,

nails, etc...) are a source of potential risk; never leave them

within the reach of children.

If you use the grill keep the oven door half-open and the grill

deflector assembled as shown in the instructions booklet.

The glass cover (only on some models), before lighting the

over burners of the top and until their turning off, shall be in

open position; it is important to avoid any contact with cookware

during the cooking in order to save from a dangerous

overheating.

Important

After the cooker use it is recommended to:

1) always check that the knobs are in the “ ” position.

2) close the cock of the gas cylinder (if you use liquefied gas)

or the supply cock (in case of natural gas).

3) periodically check the wear of the hosepipe and replace

it if necessary. Do not repair it.

IMPORTANT:

The appliance must be installed only by qualified and competent

technicians in compliance with the national provisions in force.

Any modification that should be necessary to the domestic

system in order to install the appliance shall be carried out

by qualified technicians only. The manufacturer declines all

responsibility for any damage caused by the non-observance

of the rules in force or due to an improper installation.

For any intervention please apply to an authorised aftersales

servicing centre and ask for original spare parts.

REMARK: during and after the use, the glass of the oven

door and accessible parts can be very hot; it is therefore

necessary to keep children away from the appliance.

- Make sure that there is a regular air circulation around the

gas appliance. A poor ventilation reduces the oxygen.

In case of doubts consult the installer.

- The forming of fat or other food can start a fire. Carefully

mind the cooking with oils and fats.

- This appliance has been designed exclusively for the cooking

of food. Any other use (e.g. environment hating) is considered

improper and dangerous.

- Do not install the cooker near flammable material (e.g.

curtains, tea towels, etc...)

- Never clog the holes on the bottom of the oven. Do not cover

with aluminium sheets the oven walls, especially the lower

side.

- Always close the cock of gas supply before any cleaning

and maintenance operations.

- The oven parts in contact with food are made with materials

in compliance with the provisions of Directive EEC 89/109

dated 21/12/88.

- The cooker complies with the European Directives as to gas

EEC 90/395, EEC 93/88 and provisions EN 30-11

and EN 2-1.

- Before operating on the unit remove the plastic films.

COOKER DIMENSIONS 90x60 90x60

AND CHARACTERISTICS with cylinder

compartment

Height of top a1 85 2 cm 85 2 cm± ±

Depth c1 60 cm 60 cm

Width B 90 cm 90 cm

Height of topof open lid a2 141 2 cm± 2 cm 141 ±

Depth with oven door open c2 98 cm 104 cm

Working capacity 58 dm

135 dm

Class 2 subclass 1 2 subclass 1

Burners Burners adaptable for operation with LPG - natural gas

Operating voltage 230 Volt - 50 Hz

ATTENTION

Fig. 2

gas supply closed

maximum

gas position

minimum

gas position

BURNERS USE

MANUAL LIGHTING OF THE COOK-TOP BURNERS

Put a lighted match to the burner, hold down and press the

proper knob to the left up to the max .

Turn the knob to the minimum position in order to reduce

the flame (small flame).

On the control panel next to each knob is drawn a flame

schema where it is indicated the burner position to which

the knob refers to. (fig. 2).

100

The appliance must not be used be people (including

children) with limited physical, sensory or mental abilities,

or without experience or expertise, unless they have

received instructions for using it from those responsible

for their safety. Young children should be supervised to

ensure they not play with the appliance.

Produkt Specifikationer

Mærke:	Fagor
Kategori:	Komfur
Model:	CFF1094X
Vekselstrømsindgangsspænding:	220 - 240 V
Vekselstrømsindgangsfrekvens:	50 Hz
Bredde:	900 mm
Dybde:	600 mm
Højde:	850 mm
Vægt:	86000 g
Produktfarve:	Rustfrit stål
Kontroltype:	Buttons,Rotary
Produkttype:	Fritstående komfur
Strøm:	16 A
Pakkevægt:	93000 g
Pakkedybde:	677 mm
Pakkebredde:	955 mm
Pakkehøjde:	870 mm
Grill:	3200 W
Selvrensende:	Ja
Komfurtype:	Gaskomfur
Antal kogeplader / madlavningsområde:	5
Blus/kogeplade zone 1 strøm:	1000 W
Blus/kogeplade zone 2 strøm:	1750 W
Blus/kogeplade zone 1 type:	Lille
Blus/kogeplade zone 2 type:	Mellem
Kontrolposition:	Top forside
Blus/kogeplade zone 3 type:	Stor
Blus/kogeplade zone 4 type:	Ekstra stor
Samlet indvendig ovn kapacitet:	119 L
Strøm for samtlige ovne:	5000 W
Antal ovne:	1
Ovn nettokapacitet:	119 L
Energiforbrug:	19.5 kWh
Ovn effekt:	5000 W
Antal gasbrændere:	5
Blus/kogeplade zone 4 strøm:	3300 W
Blus/kogeplade zone 3 strøm:	3000 W
Ovn strømkilde:	Naturgas
Ovn samlet kapacitet:	119 L
