FANTEC TV-LHD
CONTENTS
1. Product Feature ....................................................................................................................... 3
2. Safety Precautions .................................................................................................................. 4
3. Product Specification ............................................................................................................. 6
4. Descriptions & Product Contents .......................................................................................... 7
4-1 Description ........................................................................................................................ 7
4-2 Product packing list ........................................................................................................ 7
4-3 Part Descriptions .............................................................................................................. 8
5. Network based data sharing with a PC ................................................................................. 9
5-1 LAN Cable connection between PLAYER and a PC ................................................ 9
5-2 Network-based Data Sharing with a PC .................................................................... 10
6. Remote Control ..................................................................................................................... 21
7. Connecting FANTEC TV-LHD ............................................................................................... 24
7-1 Connection with A/V (Composite) TV output ........................................................... 24
7-2. Connection with HDMI output .................................................................................... 24
7-3 Connection with 2 Channel of Cinch Audio ............................................................ 25
7-4 Connection with Coaxial output .................................................................................. 25
7-5 Connection with Optical output .................................................................................. 26
8. SETUP Menu .......................................................................................................................... 27
8-1 A/V (Audio / Video Setting) ......................................................................................... 28
8-2 ETC Enhanced Technical Calibration .................................................................... 29
9-3 Network ............................................................................................................................ 30
8-4 Exit .................................................................................................................................... 30
9. Main Menu Screen ................................................................................................................. 31
10. Movie Play ............................................................................................................................ 32
11. Music Play ............................................................................................................................ 33
12. Photo Play ............................................................................................................................ 34
13. Firmware Upgrade ............................................................................................................... 35
14. FAQ - Troubleshooting........................................................................................................ 37
15. Appendix .............................................................................................................................. 39
