Side 1/2

Gas Spring

L Shape WrenchGas Spring Cover

8 Hexagonal Socket Bolts 2 small bolts and 2 screw covers

Back rest Seat

Model A Mechanism

Model B Mechanism Five Star Base

NOTES

※ ※

1. Please avoid the fire, direct sunlight and

wet environment.

2. Please do not put the chair on a high or

unstable place, in case falling down.

3. Please put the chair on a flat ground.

4. Please pay attention to your kids when

they are climbing the chair.

5. Please pay attention to the natural loosen

of the bolts after long-term using, avoid

sharp things scratch the chair.

6. Please avoid excessive tilt using in case

falling down.

MANUAL

Thanks for buying our product.

Please read this manual carefully

before installation and use as the

manual said. In order to refer more

information please take care of the

manual.

Model A

Model B

5 Wheels

2 Recliner Covers

Mounting diagram for model B

Mounting diagram for model A

Picture 1

Picture 2

STEP

Put the back rest and seat together

Put the back rest and seat together as the

picture 1. Please pay attention to the red

marked place ( left and right sides) which

need aim at the bolts holes.

STEP

Install the mechanism

Use the bolts to lock the mechanism

and seat together, and make sure the

bolts are screwed in tight.

Install the handles and push them

to the bottom

STEP

Install the mechanism

Use the bolts to lock the mechanism

and seat together, and make sure the

bolts are screwed in tight.

STEP

Install the wheel

STEP

Install the gas spring

STEP

Put on the gas spring cover

STEP

Lock the back rest and seat

Lock the 4 bolts on the left and right side

as the picture step by step.

(Please remove the bolts that are pre-mounted

on the backrest; two bolts are located on each

side of the backrest.Place the backrest on the

seat. Begin at the right side where the tilting

handle is located.Screw both bolts on the right

side half way in and then screw in the two bolts

on the left side. Now tighten the bolts on both

sides)

STEP

Install the recliner covers

Attach the lower snap button first. Lock the screw into the hole

on the recliner cover, and then attach the screw cover on it.

Model A

Model B

STEP

8 Put the chair body on the gas spring

Aim at the top of gas spring and the hole of mechanism,

then put the chair body down.

Usage & Safety Instructions

Sit in the center of the chair,

with your back to the backrest.

Do not sit at the front edge of

the chair.

Do not push the chair

aroundwhen a person

is sitting in it.

Do not place all your

weight on

the backrest only.

Do not place your hand

orfingers near the

recline mechanics.

Do not push down

on thebackrest when

a person is reclined.

Do not stand on the chair. Do not use the chair with more

than one person
