APPLICATIONS
TECHNICAL SPECIFICATIONS PHYSICAL SPECIFICATIONS
The FBT VERTUS CLA 406.2A two-way bi-amplified speaker system incorporates 4 x 6,5” custom woofer with 1,5” voice coil and 1
x 1,4" B&C HF neodymium driver with 2,5 voice coil. The internal Class D amplifier module constructed in die-cast aluminum
delivers 600W for LF, 300W for HF and DSP processor with 8 equalization presets provide unexpected dynamics in a system of these
dimensions. The FBT VERTUS CLA 406.2A shall meet the following performance criteria: frequency response from 65Hz to 20kHz,
maximum SPL of 133dB, horizontal coverage angle of 100°, vertical coverage angle 25°. The FBT VERTUS CLA 406.2A feature a
0,47" birch plywood with internal metal bracing and the front shall be protected by a heavy duty metal grille. The control panel
provides Level control, HF level, Preset, HP filter, Gnd lift, 3 status led ( on, peak, prt/limit ), XLR input & link and Neutrik Powercon
Cable Duplex for power supply. Via new hardware it is possible to couple two or more CLA 406.2A/CLA 206A with an angle of 0°-20°
in 5° steps vertically and additional accessories are available for system suspension; four lateral inserts ( two upper and two lower)
designed to accept quick release pins or M10 screws. It can be integrated elegantly and with minimal intrusion into any environment;
it is ideal for live applications, assisted by sub CLA 118SA, which for fixed installations.
Ideal for both live applications, assisted by the CLA118SA active subwoofer, as
well as for fixed installation
2 way bi-amplified line array column
0,47" birch plywood with scratch resistant varnish
4 x 6,5" custom woofer with 1,5" voice coil
Neodymium B&C compression HF driver with 1,4" throat and 2,5" voice coil
Class D 600W RMS amplifier for LF and 300W RMS for HF
DSP processor with 8 equalization presets
100°H x 25°V dispersion
Completely Manufactured in Italy
2 way bi- biamplified
65Hz - 20kHz
100° H x 25° V
1.2 kHz
640 W
AC Power requirement
133dB
190 x 1140 x 290mm
61,72 lbs / 28 kg
69,44 lbs / 31,5 kg
4 x 6,5" - 1,5" coil
7,48" x 44,88" x 11,41"
306 x 1256 x 416mm
12,04" x 49,44" x 16,37"
0,47" birch plywood
Built-in Amplifiers LF / HF *max.: 600W RMS / 300W RMS
max. peak.: 1200W / 600W
Input Impedance 22kOhm
Maximum SPL ( peak ) **
16,40 ft / 5 mt.Power cord
XLR with loop
MAX.: 2mS burst, rms power on nominal speaker impedance
MAX PEAK: based on max peak output voltage and nominal speaker impedance
PEAK SPL: free space, based on max peak power amp rating and system peak sensitivity, 10mS time average
1 x 1,4" - 2,5" coil
CLA 406.2A
Active Column Line Array
FEATURES
PRODUCT DESCRIPTION
10°
190mm / 7.48" 290mm / 11.41"
1140mm / 44.88"
IN
LINK
PRESET
LEVEL
GND
LIFT
HP
FILT.
OFF ON
OFF ON PEAK
ON
+6dB
0
0
0
1
2
3
4 5
6
7
8
DO NOT EXCEED RATED MAX CURRENT DRAW FROM AC LOOP OUTPUT CONNECTOR
POWER
CONSUMPTION: 640W
AC LOOP OUT
220-230V 50/60Hz
13.2A max
AC INPUT
220-230V 50/60Hz
2.8A max
All acce ss or ie s ar e
spe ci cally rated in
a g r e e m e n t w i t h
s t r u c t u r a l
com put ation s. Never
use other accessories
when assembling the
cabinets than the ones
provided by FBT; FBT will
dec li ne re spo nsi bi lit y
o v e r t h e e n t i r e
accessories range if any
component is purchased
f r om a d i f f e r e n t
supplier.
MADE IN ITALY
CAUTION
TO PREVENT THE RISK
OF FIRE OR ELECTRIC
SHOCK NEVER EXPOSE
THIS EQUIPMENT
TO RAIN OR MOISTURE
RISK OF ELECTRIC
SHOCK DO NOT OPEN
HF LEVEL
LMT
PRT
VERTUS CLA 406.2A
SINGLE:
1-Ground/Sub Stack
2-Hung
GROUND ARRAY:
3-Straight
4-Curved 10°
5-Curved 20°
HUNG ARRAY:
6-Straight
7-Curved 10°
8-Curved 20°
The FBT VERTUS CLA 406.2A provides
a high efficiency class D power amplifier
module with switching power supply
enclosed in a die-cast aluminium
chassis. This provides maximum
protection of the electronics
from dust or dirt, prevents air
loss through the input control
panel that can cause fastidious
noise, and it maximizes heat
dissipation avoiding the use of a
fan to cool the circuitry. 50Hz 100 200 500 1k 2k 5k 10k 20k
dBSPL
111
108
105
102
99
96
93
90
87
84
81
78
75
SPL vs FREQ
CLA 406.2A
Active Column Line Array
CONNECTION PANEL DIMENSIONAL DRAWING
AMPLIFIER MODULE
