EEXXPPLLOODDEEDD VVIIEEWW
ROUTER
The following symbols are used throughout this manual:
Denotes risk of personal injury, loss of life or
damage to the tool in case of non-observance of
the instructions in this manual.
Denotes risk of electric shock.
Carefully read this manual before using the machine.
Make sure that you know how the machine functions and
how to operate it. Maintain the machine in accordance
with the instructions to make sure it functions properly.
Keep this manual and the enclosed documentation with
the machine.
SAFETY INSTRUCTIONS
When using electric machines always observe the
safety regulations applicable in your country to
reduce the risk of fire, electric shock and personal
injury. Read the following safety instructions and also
the enclosed safety instructions.
Keep these instructions in a safe place!
• Check workpieces for any protruding nails etc. and
remove these.
• Keep your hands away from the surface to be cut.
TECHNICAL SPECIFICATIONS
Voltage 230 V~
Frequency 50 Hz
Power input 550 W
No load speed 8000–32000/min
Max. cutter diameter 30 mm
Cutting depth 35 mm
Collet 6 mm
Weight 3.25 kg
L
pa
(sound pressure) 81.3 dB(A)
L
wa
(sound power) 94.3 dB(A)
Vibration value < 4.0 m/s
2
Fuses 230 V machines 10 A
Electrical safety
Always check that the power supply corre-
sponds to the voltage on the rating plate.
Your machine is double insulated in accordance
with EN 50144; therefore no earthwire is requi-
red.
Replacing cables or plugs
Immediately throw away old cables or plugs when they
have been replaced by new ones. It is dangerous to insert
the plug of a loose cable in the wall outlet.
Using extension cables
Only use an approved extension cable suitable for the
power input of the machine. The minimum conductor size
is 1.5 mm
2
. When using a cable reel always unwind the
reel completely.
PACKAGE CONTENTS
1 router
1 cutter
1 parallel guide
2 screws
1 6 mm collet (1/4”)
1 8 mm collet
2 open-ended spanners
1 hexagonal key
1 instruction manual
1 safety instructions
1 guarantee card
Check the machine, loose parts and accessories for trans-
port damage.
