This document should only be removed by customer after installation.

P/N: A11302801

Not satised with the installation of your refrigerator? Please contact the store from which you purchased your refrigerator. 

Installation Instructions for Top Mount Refrigerator

To connect the water supply to the rear of your refrigerator:

1 Ensure that the refrigerator is not plugged in.

2 Flush the supply line until water is clear by placing the end of the

copper tube in a sink or bucket and opening the shut-off valve.

3 Remove the plastic cap from the water valve inlet at the rear

of your refrigerator. Discard the cap.

4 Slide the brass compression nut, then the ferrule (sleeve) onto

copper tube.

5 Push the copper tube into water valve inlet as far as it will go (¼”).

6 Slide the ferrule (sleeve) into valve and nger-tighten the

compression nut onto valve. Tighten another half turn with a

wrench. Do not over-tighten.

7 Secure the copper tube to your refrigerator’s rear panel with a

steel clamp and screw (see illustration).

8 Coil the excess copper tubing (about 2½ turns) behind

your refrigerator as shown. Arrange coiled tubing to avoid

vibration or wear against other surfaces.

9 Open water supply shut-off valve and tighten any connections that leak.

Remove Internal Shipping Materials

Doors

Handles are secure and tight

Door seals completely to cabinet on all sides

Freezer door is level across the top

Leveling

Refrigerator is level, side to side and tilted

¼” (6mm) front to back

Toe grille is properly attached to refrigerator

Cabinet is setting solid on all corners

Ƚ Anti tip bracket set

Electrical Power

House power turned on Ƚ Refrigerator plugged in

Ice Maker

House water supply connected to

refrigerator

No water leaks present at all connections -

recheck in 24 hours

Ice Maker is turned ON.

Final Checks

Shipping material removed

Fresh Food and Freezer controls set

Crisper Humidity controls set

Registration Card sent in

 Installation Checkoff List

Prepare The Installation Site

Transport Unpackaged Refrigerator To Site

Location of these materials may vary depending on your model.

garage

temper ature

cold es t

cold

off

* rec ommen ded

garage

temper ature

cold es t

cold

off

* rec ommen ded

2 Pieces of Tape

1 Shelf Spacer

1 Piece of Tape

2 Pieces of Foam

and Tape

Handle Kit

(1 Piece of Tape)

2 Pieces of Tape

1 Pieces of Tape

4 Pieces of Tape

2 Pieces of Tape

2 Pieces of Foam

1 Piece of Tape

2 Pieces of Tape

1 Piece of Tape

2 Pieces of Tape

1 Shelf Spacer

1 Piece of Tape

2 Pieces of Foam

and Tape

Handle Kit

(1 Piece of Tape)

2 Pieces of Tape

1 Pieces of Tape

4 Pieces of Tape

2 Pieces of Tape

2 Pieces of Foam

1 Piece of Tape

2 Pieces of Tape

Include these minimum guidelines in your site

preparation:

• Choose a place near a grounded electrical

outlet.

• Do not use an extension cord or an adapter plug.

• Avoid direct sunlight and close proximity to a

range, dishwasher or other heat source.

• Floor should be level and able to support a fully

loaded refrigerator.

Allow the following clearances for ease of

installation, proper air circulation, and plumbing and

electrical connections:

Sides & Top: 3/8 inch

Rear: 1 inch

By now, you have already removed your refrigerator’s shipping carton.

You may still need to use a hand truck to move it through close spaces or

entrances. If the refrigerator is larger than an entrance, consider two options:

• Remove the entrance door if one exists.

• Remove the refrigerator doors (see how in your Use & Care Guide).

When using a hand truck:

• Load refrigerator from side of cabinet only.

• Do not run retaining straps over handles.

• Do not over-tighten retaining straps.

• Never use refrigerator handles to move the refrigerator.

• Remove tape from doors only after unit is in place.

Connect Water Supply

What you will need:

• Access to a cold water

line with pressure of

30-100 psi.

• Copper tubing with

¼-inch (6.4mm)

OD. Length for this

tubing is the distance from the rear of the

refrigerator to your household water supply

line 7 feet (2.1 meters).plus

• A shut-off valve for the connection between your

household water line and the refrigerator supply

line. Do not use a self-piercing shut-off valve.

• A compression nut and ferrule (sleeve) for the

water supply connection at the rear of your

refrigerator.

Place In Permanent Position

If possible, use a hand truck to position the refrigerator directly in front of its cabinet enclosure.

Be careful not to move the refrigerator beyond its water supply (copper tubing) connections.

Plug in the power cord, and push the refrigerator

straight back into place.

Level Refrigerator & Adjust Doors (if necessary)

Guidelines for nal positioning of your

refrigerator:

• All four corners of the cabinet must rest rmly on

the oor.

• The cabinet should be level at the front and rear.

• The sides should tilt ¼-inch (6 mm) from front-to-

back (to ensure that doors close and seal properly).

• Doors should align with each other and be level.

To level the cabinet using the front rollers:

1 Remove the toe grille (Figure 1).

2 Use a at-blade screwdriver or 3/8 inch socket

wrench to raise or lower the front rollers (Figure

2). Do not raise the cabinet more than 9/16”.

3 Use adjustable wrench to adjust leveling

screws. Lower the leveling screws on each side

clockwise until they contact the oor (Figure 3).

Do not raise the cabinet more than 9/16”.

We use packing foam and tape to secure the internal parts of your refrigerator for shipping.

Once the refrigerator is in position, you can remove this material.

Controls

When changing controls, wait 24 hours before making additional adjustments.

Door Removal (if necessary)

If you need to remove the doors to get your refrigerator into the house, please see “Door

Removal Instructions” in your Use & Care Manual.

WARNING

To avoid electric shock, which can cause death or severe personal injury, do not connect your

refrigerator to an electrical power source until you have completed Step 3 of these instructions.

CAUTION

Room temperatures below 55°F

(13°C) or above 110°F (43°C)

will impair cooling ability of your

refrigerator’s compressor. IMPORTANT

If you are installing your refrigerator without

connecting it to a water supply, make sure the ice

maker’s power switch is turned Off (see the Use &

Care Guide for more details).

NOTE

These installation instructions

are provided only as a possible

customer option. We recommend

that you use a service or kitchen

contracting professional to install

your refrigerator.

NOTE

Information about cabinetry

construction for your new appliance

is available for contractors. Call

1-877-435-3287.

CAUTION

Shifting the refrigerator from side to

side may damage ooring.

NOTE

Kit #53039117950, available from your

dealer, provides all materials for a water

supply installation, including 25 feet of

copper tubing and full instructions.

CAUTION

To avoid property damage:

• Use copper tubing for the water supply line

(plastic tubing is more likely to leak).

• Ensure water supply complies with local

plumbing codes.

CAUTION

• Shifting the refrigerator from side

to side may damage ooring.

• Do not block the toe grille on the

lower front of your refrigerator.

Sufcient air circulation is essential

for proper operation.

NOTE

• The ice maker’s ll valve may operate noisily if the household water supply is shut off.

• After ensuring no water leaks exist at any connection, be sure to check for leaks again in 24 hours.

NOTE

Raise the front of the refrigerator

enough so the doors close freely

when opened halfway. The

refrigerator should slope ¼ inch to

½ inch from front-to-back. Then level

the refrigerator from side-to-side.

Vegetables Fruits

Humidity Control

Figure 1

Figure 3

4 Some models are equipped with an anti-tip bracket (Figure 4). Lower it clockwise until it contacts the oor.

Figure 2

WARNING

The anti-tip device

must be installed

according to the

instructions in your

Use & Care Manual.

Failure to do so will result in injury.

9/16"

(14 mm)

Max

Raise

9/16"

(14 mm)

Max

Tools Necessary:

Phillips Head

Quadrex Head

Screwdriver

(OR)

Socket

Wrench Set

Plastic

Putty

Knife

Adjustable

Wrench

Pliers

Awl

House

plumbing

line

Waterline hookup

Figure 4 (some models)

Anti-tip

Bracket

NOTE

Allow 15 minutes for compressor to start

after initial start up or power interruption.

Plastic Water

Tubing to Ice Maker

Fill Tube

Steel

Clamp

Brass

Compression

Nut

Ferrule

(Sleeve)

Copper

Water Line

Water Valve

Bracket

Valve Inlet

Water Valve

Copper water line from

household water supply

(Include enough tubing in loop

to allow moving refrigerator

out for cleaning.)

Top

Hinge

Cover

Top Hinge

Central

Hinge

Shim

Washer

Hinge

Bottom

Hinge

Screws

Toe

Grille

Door Stop

Screw

Door

Stop
