TA B L E O F C O N T E N T S
www.frigidaire.com USA 1-800-944-9044 www.frigidaire.ca Canada 1-800-265-8352
All about the
Use &
Care
of your Refrigerator
Important Safety Instructions 2 ......................
Features At A Glance 4 ..................................
Installation 5 ................................................
Door Removal/Reversal Instructions 7 ............
Handle Installation 10
...................................
Connecting Water Supply 12
..........................
Ice Service 14
...............................................
807876507 (October 2016)
Controls 15
...................................................
Optional Features 17
.....................................
Normal Operating Sounds and Sights 20
.........
Care and Cleaning 21
....................................
Before you Call 23
.........................................
Major Appliance Warranty 24
.........................

2
WARNING
WARNING indicates a potentially hazardous
situation which, if not avoided, could result
in death or serious injury.
IMPORTANT
IMPORTANT indicates installation, operation
or maintenance information which is
important but not hazard-related.
DANGER
DANGER indicates an imminently hazardous
situation which, if not avoided, will result in
death or serious injury.
Denitions
This is the safety alert symbol. It is used to
alert you to potential personal injury hazards.
Obey all safety messages that follow this
symbol to avoid possible injury or death.
Doors
Handles are secure and tight
Door seals completely to cabinet on all sides
Freezer door is level across the top
Leveling
Refrigerator is level, side-to-side and
tilted ¼” (6mm) front-to-back
Toe grille is properly attached to refrigerator
Cabinet is setting solid on all corners
Anti-tip bracket set
Electrical Power
House power turned on
Refrigerator plugged in
Ice Maker
House water supply connected to refrigerator
No water leaks present at all connections
- recheck in 24 hours
Ice maker is turned ON
Ice & water dispenser operates correctly
Frontltermustbeushwithlter
housing (select models)
Final Checks
Shipping material removed
Refrigerator and freezer temperatures set
Crisper humidity controls set
Registration card sent in
Installation Checklist
CAUTION
CAUTION indicates a potentially hazardous
situation which, if not avoided, may result in
minor or moderate injury.
IMPORTANT SAFETY INSTRUCTIONS
For your Safety
• DO NOT store or use gasoline, or other
ammableliquidsinthevicinityofthisor
any other appliance. Read product labels
forwarningsregardingammabilityand
other hazards.
• DO NOT operate the refrigerator in the
presence of explosive fumes.
• Avoid contact with any moving parts of
automatic ice maker.
• Remove all staples from the carton. Staples
can cause severe cuts, and also destroy
nishesiftheycomeincontactwithother
appliances or furniture.
WARNING
Please read all instructions before using this
refrigerator.
Child Safety
Destroy or recycle the carton, plastic bags, and
any exterior wrapping material immediately
after the refrigerator is unpacked. Children
should never use these items to play. Cartons
covered with rugs, bedspreads, plastic
sheets or stretch wrap may become airtight
chambers,andcanquicklycausesuffocation.
Proper Disposal of your
Refrigerator or Freezer
Risk of child entrapment
Child entrapment and suffocation are not
problems of the past. Junked or abandoned
refrigerators or freezers are still dangerous –
even if they will sit for “just a few days”. If you
are getting rid of your old refrigerator or freezer,
please follow the instructions below to help
prevent accidents.

4
FEATURES AT A GLANCE
Ice Maker
Ice Bucket
Freezer Shelf
Auxiliary Freezer
Control
Refrigerator
Control
(Some Models)
Deli Drawer
Cover
Deli Drawer
(Some Models)
Half Shelf
Crisper Cover
Crisper Drawers
Ice Tray
Fixed Door Bin
Door Rack
Dairy Door
Fixed
Door Bin
Door Rack
Toe Grille
Full Width Deli
(Some Models)
Deli Drawer
Cover
Upper Door
Rack
Features may vary according to model
IMPORTANT
Cleaning your Refrigerator
Remove tape and glue residue from surfaces before turning on the refrigerator. Rub a small
amountofliquiddishsoapovertheadhesivewithyourngers.Rinsewithwarmwaterand
dry with a soft cloth.
Donotusesharpinstruments,rubbingalcohol,ammableuids,orabrasivecleanersto
remove tape or glue. These products can damage the surface of your refrigerator.
After you remove all of the package materials, clean the inside of your refrigerator before
using it. See the “Care & Cleaning” section in this manual.
See important information about cleaning glass shelves and covers in the “Optional Features”
section of this manual.
IMPORTANT
Moving your Refrigerator
Your refrigerator is heavy. When moving the refrigerator for cleaning or service, be sure
tocovertheoorwithcardboardorhardboardtoavoidoordamage.Alwayspullthe
refrigerator straight out when moving it. Do not wiggle or “walk” the refrigerator when trying
tomoveitasoordamagecouldoccur.

5
INSTALLATION
NOTE
If your refrigerator is placed with the door
hinge side against a wall, you may have to
allow additional space for the handle so the
door can be opened wider.
CAUTION
Do not install the refrigerator where the
surrounding air temperature may fall to 39°F
(4°C) or below. The refrigerator compartment
contents may freeze. Do not install the
refrigerator where the surrounding air
temperature may reach 110°F (43°C) or above.
The refrigerator and freezer compartments may
rise to above normal operating temperatures.
Do not block the toe grille on the lower front of
yourrefrigerator.Sufcientaircirculationisessential
for the proper operation of your refrigerator.
This Use & Care Guide provides general operating
instructions for your model. Use the refrigerator only
as instructed in this Use & Care Guide. Before starting
therefrigerator,followtheseimportantrststeps.
Location
• Choose a place that is near a grounded
electrical outlet. Do Not use an extension
cord or an adapter plug.
• If possible, place the refrigerator out of
direct sunlight and away from the range,
dishwasher or other heat sources.
• Therefrigeratormustbeinstalledonaoor
that is level and strong enough to support
a fully loaded refrigerator.
• Consider water supply availability for models
equippedwithanautomaticicemaker.If
you do not hook up water to the refrigerator,
remember to turn the ice maker off.
Installation
Installation clearances
• Allow the following clearances for ease
of installation, proper air circulation, and
plumbing and electrical connections:
Sides&Top ⅜inch
Back 1 inch
or
2. Attach toe grille to cabinet.
Guidelines for nal positioning of your
refrigerator:
• All four corners of the cabinet must rest
rmlyontheoor.
• The cabinet should be level at the front and rear.
• The sides should tilt ¼-inch (6 mm) from
front-to-back (to ensure that doors close
and seal properly).
• Doors should align with each other and be level.
To install the toe grille:
1. The toe grille is packaged with the covers
installed. Remove the cover on the side
corresponding with the door hinge bracket.
NOTE
For additional instructions on garage
installation, refer to “Controls” section.
some models
NOTE
In case of future door reversals, save the
toe grille cover not being used.

6
WARNING
The anti-tip device must be
installed according to the
instructions in your Use &
Care Manual. Failure to do
so will result in injury.
WARNING
When reversing the door swing:
You MUST move the anti-tip bracket to align
with the hinges of the door. Failure to do so
will result in injury.
NOTE
Raise the front of the refrigerator enough so
the doors close freely when opened halfway.
The refrigerator should slope ¼ inch to
½ inch from front-to-back. Then level the
refrigerator from side-to-side.
To level the cabinet using the front
rollers:
1 Remove the toe grille.
2 Useaat-bladescrewdriveror⅜inch
socket wrench to raise or lower the front
rollers (Figure 2). Do not raise the cabinet
more than 9/16 inch.
Figure 4 (some models)
Lower
Anti-tip
Bracket
Raise
9/16"
(14 mm)
Max
Figure 3
9/16"
(14 mm)
Max
Raise
Figure 2
OR
3 Use adjustable wrench to adjust leveling
screws. Lower the leveling screws on each
sideclockwiseuntiltheycontacttheoor
(Figure 3). Do not raise the cabinet more
than 9/16 inch.
4 Somemodelsareequippedwithananti-
tip bracket (Figure 4). Lower it clockwise
untilitcontactstheoor.
INSTALLATION

7
NOTE
The direction in which your refrigerator doors open (door swing) can be reversed, from left
to right or right to left, by moving the door hinges from one side to the other. Reversing the
doorswingshouldbeperformedbyaqualiedperson.
DOOR REMOVAL/REVERSAL INSTRUCTIONS
Door removal and reversal
instructions:
1. Remove toe grille.
2. Remove top hinge cover. Trace around the
hinge with a soft lead pencil. This makes
reinstallation easier. Remove top hinge and
lift door off center hinge pin. Set door aside.
3. Unscrew center hinge pin using adjustable
wrench and save for reassembly. Ensure
plastic washer stays on hinge pin.
IMPORTANT
Before you begin, turn the refrigerator temperature control to “0” (Mechanical controls) or
“OFF” (Electronic controls) and remove the electrical power cord from the wall outlet. Remove
any food from door shelves.
or
or
Tools Necessary:
PhillipsTM
Head
Socket
Wrench Set Adjustable
Wrench
3/8" (10mm)
Fixed
Wrench
Top Hinge
Cover Front
Screw
Top Hinge
Cover Rear
Screw
Bottom
Hinge
Screw
Top
Hinge
Screw
Top
Hinge
Cover
Top Hinge

9
IMPORTANT
Should open seal condition exist, try working
the gasket by hand to make sure it is seated
into the channel.
If the condition still exist, try heating the gasket
with a hair dryer with the door closed. Be
careful not to damage the interior door panel or
the gasket by applying too much heat.
If the open seal condition still exist, it may be
necessarytoipthegasket.Inthiscase,remove
the gasket from the door by pulling it out. Rotate
the gasket half a turn (180 degrees). Reinstall
thegasketbyinsertingthecornersrstthen
work towards the middle assuring that the dart
is fully seated in the channel.
NOTE
In case of future door reversals, save the toe
grille cover not being used.
20. After the screws have been tightened,
replace the top hinge cover.
21. Remove the toe grille cover corresponding
with the door hinge bracket from the toe
grille and attach the opposite toe grille
cover that was saved earlier over the
opening on the side corresponding with
the toe grille support (see Figures A & B).
DOOR REMOVAL/REVERSAL INSTRUCTIONS
A
Toe Grille Cover
Toe
Grille
Support
Anti-tip
Bracket
B
Toe Grille
Cover
Toe Grille
Support
Anti-tip
Bracket
22. Reinstall toe grille with appropriate cover
(some models).
23. Plug in electrical power cord and turn
refrigerator temperature control to center
position. Adjust setting as necessary.
Look for open areas between the
gasket and the cabinet flange.
Gasket should seal against the
cabinet all the way around including top
and bottom
19. Tighten the top hinge screws and check door
gasket for open seal condition (see graphic).

10
IMPORTANT
To ensure proper installation of handles,
please review these instructions and
illustrations thoroughly prior to installing the
handles.
Additionally, before installing the door
handles, make sure the door swing is
correct. Your model will have either a
right hand or left hand door swing. Follow
instructions in the Use & Care Guide to
reverse the doors, if necessary.
HANDLE INSTALLATION
To attach metal refrigerator handle:
1. Place rounded part of handle onto
shoulder screw on face of door and align
the two holes in top of handle with the
two holes in top of door. Do not tighten
the set screw yet.
2. Install the two screws into the top of the
handle.
3. Tighten the set screw on the rounded part
ofthehandleuntilthehandleisushwith
the door, then tighten another ½ turn.
CAUTION
Wear gloves and use extreme CAUTION
when installing these handles. The rounded
end of the handles may be sharp.
To attach metal freezer handle:
1. Place rounded part of handle onto
shoulder screw on face of door and align
the two holes in bottom of handle with
the two holes in bottom of door. Do not
tighten the set screw yet.
2. Install the two screws into the bottom of
the handle.
Stainless Steel Models
Screw
Handle
Button
Plug
Set
Screw
Shoulder
Screw
Shoulder
Screw
Nameplate
Handle
Set
Screw
Screw
Screw
Handle
Shoulder
Screw
Set
Screw
3. Tighten the set screw on the rounded part
ofthehandleuntilthehandleisushwith
the door, then tighten another ½ turn.
Shoulder
Screw
Set
Screw
Handle
Screw
Produkt Specifikationer
Mærke: | Frigidaire |
Kategori: | Køleskab |
Model: | FFTR1619RS |
Har du brug for hjælp?
Hvis du har brug for hjælp til Frigidaire FFTR1619RS stil et spørgsmål nedenfor, og andre brugere vil svare dig
Køleskab Frigidaire Manualer
17 Juni 2025
17 Juni 2025
16 Juni 2025
16 Juni 2025
16 Juni 2025
16 Juni 2025
16 Juni 2025
16 Juni 2025
16 Juni 2025
16 Juni 2025
Køleskab Manualer
- Gram
- Hitachi
- Wolkenstein
- Mora
- Waeco
- Waltham
- Café
- Napoleon
- Berg
- Eurotech
- Lamona
- Traulsen
- Baumatic
- AEG
- Yolco
Nyeste Køleskab Manualer
20 Juli 2025
20 Juli 2025
20 Juli 2025
20 Juli 2025
20 Juli 2025
20 Juli 2025
19 Juli 2025
19 Juli 2025
19 Juli 2025
19 Juli 2025
