CB22+ Installation Instructions

LIT188543466

Structural Channel

Route conduit (supplied by customer)

to knockouts as required

Structural Member

supplied by customer

All mounting hardware

ONLY

AC Access Plate

AC POWER INPUT WIRING MUST

BE PERFORMED BY A QUALIFIED

ELECTRICIAN

4x #8-32 x 1/4" Long

Pan Head Screw

Turn latch to open door

Shelf

Drop Ceiling Material

(supplied by customer)

18-3/4" x 22-1/2"

4x Capture Tab

Cables support the Ceiling Box, and are NOT

door up towards ceiling and (b) push towards shelf -

INTENDED FOR USE WITH COMMON "T" GRID

tabs over ceiling panel to hold in place.

Model Number CB-MNT1

completely remove door. Installation of 18-3/4" x 22-1/2"

Door Removal:

building codes. Install safety cable as required by local building

DROP CEILING AND IS NOT COMPATIBLE

gross weight. Use appropriate mounting methods based on local

after AC wiring is complete.

NOTE:

WITH ALL DROP CEILINGS.

(Alternate Method 2)

required by building codes.

safety cables.

codes. Route conduits to box as required.

drop ceiling material into door can be done as required,

while door is off or during re-assembly. Bend capture

Install CB-22+ to a structural ceiling able to support 5x the noted

Mounting:

reverse procedure to install. Disconnect safety cable to

Quick 3/32" Cable Installation KIt (sold seperately)

NOTE: Ceiling Box suspension method

(Shown) Threaded steel rod (1/4"-20 minimum) is

required for applications where the pole is

supporting more than 50lbs. and is recommended

for all ceiling box installations to minimize fixture

movement.

(Alternate Method 1)

12 ga. steel wire may be used (supplied by

customer) at 70,000 psi tensile strength or better as

Turn latch to open door (unlock if needed). (a) Push

To install AC main power into unit, remove AC access

plate by removing 4x #8-32 screws, as shown. Wiring

must be performed by a qualified electrician only.

Wiring must be done in accordance with all NEC and

other applicable codes. Re-install AC access plate

AC Wiring:

make electrical connections as required.

supports.

Clip Removal (cable not shown - reverse steps to install)

Shelf Removal (reverse steps to install)

Mounting Brackets as shown. Install rack unit and

reinstall shelf into Ceiling Box. Make electrical

4b.

Remove shelf to mount electronics. Use existing

connections as required.

holes/slot pattern adding additional holes if required

to adequately secure equipment. Reinstall shelf and

MAXIMUM DISTRIBUTED LOAD - 40LBS

To install 2RU rack-sized equipment, install 2RU

4a.

To access shelf and equipment, retract

hinges located under the shelf on the side

you wish to rotate down. Support the shelf

until the cables engage it.

To fully remove the shelf, remove the two

#6-32 screws on the sides that retain the

cable clip. Slide the clips out of the shelf.

The shelf should hang on the two remaining

spring hinges. Carefully retract the final two

spring hinges while fully supporting shelf as it

rotates out of the Ceiling Box.

For shelf installation, the arrows on the shelf

must point away from the receptacles at

the back of the box and towards the door

latch at the front. Fully retract 2 hinges on

the rear of the shelf and lift shelf into Ceiling

Box. Align both pins with the Ceiling Box

embosses located on either side of chassis.

Insert point side of the cable clips into the

side of the shelf, rotate until the end of the

clip passes through the shelf, then slide clip

back. Install the two #6-32 screws through

the shelf side into the clips. Fully retract the

remaining 2 hinges on the front of the shelf

and rotate shelf into Ceiling Box engaging

the hinge pins in the front embosses.

The shelf may be flipped over and mounted

to the top of the Ceiling Box using the same

spring hinge operation. In this position the

cables will not function as rotational

Shelf Options and Operation:

Direction Arrow

Alternate 2RU Mounting Location

4x #10-32 x 3/8" Long

Pan Head Screw

Shelf Front

Preinstalled 2RU

Bracket Location

Shelf disconnected

from Ceiling Box

Shelf disconnected

from Cable

as Shelf arrows

Shelf

point in same direction

2x Screw to

remove/attach

Arrow shaped Clip to
