CDA - 4/6
375 MHz COMPUTER
DISTRIBUTION AMPLIFIERS
OPERATION MANUAL
REGULATORY COMPLIANCE
FSR'S ELECTRONIC PRODUCTS have been tested for compliance with: FCC Class A and CE
The Power Adapter has been tested for compliance with: UL, CSA and CE.
WARRANTY POLICY
This product is warranted against failures due to defective parts or faulty workmanship for a period of
one year after delivery to the original owner. During this period, FSR will make any necessary repairs
or replace the unit without charge for parts or labor. Shipping charges to the factory or repair station
must be prepaid by the owner, return-shipping charges, via UPS / FedEx ground, will be paid by FSR.
This warranty applies only to the original owner and is not transferable. In addition, it does not apply
to repairs done by other than the FSR factory or Authorized Repair Stations.
This warranty shall be cancelable by FSR at its sole discretion if the unit has been
subjected to physical abuse or has been modifi ed in any way without written authorization from FSR.
FSR’s liability under this warranty is limited to repair or replacement of the defective unit.
FSR will not be responsible for incidental or consequential damages resulting from the use or misuse
of its products. Some states do not allow the exclusion of incidental or consequential damages, so the
above limitations may not apply to you. This warranty gives you specifi c legal rights, and you may
also have other rights which vary from state to state.
Warranty claims should be accompanied by a copy of the original purchase invoice
showing the purchase date (if a Warranty Registration Card was mailed in at the time of purchase, this
is not necessary). Before returning any equipment for repair, please read the important information
on service below.
SERVICE
Before returning any equipment for repair, please be sure that it is adequately packed and cushioned
against damage in shipment, and that it is insured. We suggest that you save the original packaging
and use it to ship the product for servicing. Also, please enclose a note giving your name, address,
phone number and a description of the problem.
NOTE: all equipment being returned for repair must have a Return Authorization (RMA) Num-
ber. To get a RMA Number, please call the
FSR Service Department (973-785-4347).
Please display your RMA Number prominently on the front of all packages.
Contact Information:
FSR Inc.
244 Bergen Boulevard,
Woodland Park, NJ 07424
Tel: (973) 785-4347 · Fax: (973) 785-4207
E-Mail: sales@fsrinc.com · Web: http://www.fsrinc.com
LIT1029B
43870
PROPRIETARY INFORMATION
All information in this manual is proprietary to and the property
of FSR inc. This publication is protected by the Federal Copyright
Law, with all rights reserved. No part of this document may be
reproduced, transcribed, or transmitted, in any form or by any
means, without prior explicit written permission from FSR Inc.
Operators Safety Summary
The general safety information in this summary is for operating
personnel.
Read Instructions Read and understand all safty and operating
instructions before using this equipment. Keep the instructions
handy.
Do Not Remove Covers or Panels There are no user-serviceable
parts within the unit. Removal of the top cover will expose
dangerous voltages. To avoid personal injury, do not remove the
top cover. Do not operate the unit without the cover installed.
Power Source This product is intended to operate from the
specifi ed wall plug-in transformer. Do not use any orther power
source.
Grounding the Product This product is grounded through the
grounding conductor of the power cord. To avoid electrical shock,
plug the power cord into a properly wired receptacle before
connecting to the product input or output terminals.
Use the Proper Power Cord Use only the power cord and
connector specifi ed for your product. Use only a power cord that is
in good condition. Refer cord and connector changes to qualifi ed
service personnel.
Do Not Operate in Explosive Atmospheres To avoid explosion,
do not operate this product in an explosive atmosphere.
Sync
Input level: TTL 2.0V minimum
Output level: 5.0 Vp-p into Hi-Z, 2.4 Vp-p into 75 ohm
Delay Time: 8nS
Rise & Fall Time: 2.5nS
Input Impedance: 475 ohms
Output impedance: 75 ohms
Polarity: Positive or negative
Horizontal frequency: 15 kHz - 200 kHz
Vertical frequency: 50 Hz - 150 Hz
General
Power Supply: 12VDC 0.5A Wall plug-in power supply with locking
connector
Enclosure: Metal 8.5" W x 4.75" D x 1.62" H (1/2 rack unit).
Rack mounting kit is supplied.
Weight: 1.6 lbs.
Response curves of a 150 foot length of West Penn 8255 coaxdriven with a 0.7V
P-P signal. Notice that by itself, the cable’s -3dBbandwidth is only 17 MHz, but
when usedwith the CDA-4/6, the bandwidth is restored to 162 MHz at the end of
the cable.
