Side 1/20
EnglishDeutschFrançaisEspañolItalianoEλληvIkάPortuguêsРусскийTürkçe
INSTALLATION MANUAL
INSTALLATIONSANLEITUNG
MANUEL D'INSTALLATION
MANUAL DE INSTALACIÓN
MANUALE D'INSTALLAZIONE
ΕΓΧΕΙΡΙΔΙΟ ΕΓΚΑΤΑΣΤΑΣΗΣ
MANUAL DE INSTALAÇÃO
РУКОВОДСТВО ПО УСТАНОВКЕ
KURULUM KILAVUZU
OUTDOOR UNIT
AUSSENGERÄT
UNITÉ EXTÉRIEURE
UNIDAD EXTERIOR
UNITÀ ESTERNA
ΕΞΩΤΕΡΙΚΉ ΜΟΝΆΔΑ
UNIDADE EXTERIOR
ВНЕШНИЙ МОДУЛЬ
DIŞ ÜNİTE
For authorized service personnel only.
Nur für autorisiertes Fachpersonal.
Pour le personnel de service agrée uniquement.
Únicamente para personal de servicio autorizado.
A uso esclusivo del personale tecnico autorizzato.
Μόνο για εξουσιοδοτημένο τεχνικό προσωπικό.
Somente para o pessoal do serviço técnico autorizado.
Только для .авторизованного обслуживающего персонала
Yalnızca yetkili servis personeli için.
PART No. 9380545293-02
AJ*072LELAH
AJ*090LELAH
AJ*108LELAH
AJ*126LELAH
AJ*144LELAH
AJ*162LELAH
[Original instructions]
En-1
1. SAFETY PRECAUTIONS
• Be sure to read this Installation manual thoroughly before installation.
• The warnings and precautions indicated in this Installation manual contain important
information pertaining to your safety. Be sure to observe them.
• After installing the unit, perform a test run to make sure the unit operates normally. Then,
explain to the customer how to operate and maintain the unit.
• Please pass this Installation manual together with the Operating manual to the customer.
Please ask the customer to keep the Operating manual and Installation manual at hand
for future reference during the moving or repair of the main unit.
WARNING This mark indicates procedures which, if improperly per-
formed, might lead to the death or serious injury of the user.
Consult the retail store or professional technicians to install the main unit according to
the Installation manual.
Improper installation will cause serious accidents such as refrigerant leakage, water
leakage, electric shock, and fire.
Manufacturer's guarantee will be invalid when instructions in the Installation manual are
ignored during installation.
For installation purposes, be sure to use the parts supplied by the manufacturer or other
prescribed parts.
Using non-specified parts will cause serious accidents such as falling unit, refrigerant
leakage, water leakage, electric shock, and fire.
To install a unit that uses the R410A refrigerant, use dedicated tools and piping materi-
als that have been manufactured specifically for R410A use.
Because the pressure of the R410A refrigerant is approximately 1.6 times higher than
the R22, failure to use dedicated piping material or improper installation can cause
rupture or injury.
It will also cause serious accidents such as refrigerant leakage, water leakage, electric
shock, and fire.
Do not use this equipment with air or any other unspecified refrigerant in the refrigerant
lines.
Excess pressure can cause a rupture.
Be sure to install the unit as prescribed, so that it can withstand earthquakes and
typhoons or other strong winds.
Improper installation can cause the unit to topple or fall, or other accidents.
Ensure that the outdoor unit is securely installed at a place that can withstand the
weight of the unit.
Improper installation will cause injuries caused by falling unit.
If there is a refrigerant leakage, make sure that it does not exceed the concentration
limit.
If a refrigerant leakage exceeds the concentration limit, it can lead to accidents such as
oxygen starvation.
If a refrigerant leakage occurs during operation, immediately vacate the premises and
thoroughly ventilate the area.
If the refrigerant is exposed to fire, it will create a hazardous gas.
Electrical work must be performed in accordance with this Installation manual by a
person certified under the national or regional regulations. Be sure to use a dedicated
circuit for the unit.
An insufficient power supply circuit or improperly performed electrical work can cause
serious accidents such as electric shock or fire.
For wiring, use the prescribed type of cables, connect them securely, making sure that
there are no external forces of the cables applied to the terminal connections.
Improperly connected or secured cables can cause serious accidents such as overheat-
ing the terminals, electric shock, or fire.
Securely install the electrical box cover on the unit.
An improperly installed electrical box cover can cause serious accidents such as electric
shock or fire through exposure to dust or water.
Do not turn ON the power until all work has been completed.
Turning ON the power before the work is completed can cause serious accidents such
as electric shock or fire.
After the installation, make sure there is no refrigerant leakage.
If the refrigerant leaks into the room and becomes exposed to a source of fire such as a
fan heater, stove, or burner, it will create a hazardous gas.
Use a wall hole pipe. Otherwise, it may cause a short circuit.
Do not place the outdoor unit near the handrail of the balcony.
Children may climb onto the outdoor unit, lean over the handrail and fall over.
Use only a specified power cable. Poor connection, poor insulation, and exceeding the
allowable current will lead to electric shock and fire.
Attach the connecting cables securely to the terminal. Or secure it firmly with a “wiring
suppressor”.
Loose connection will lead to malfunction, electric shock, and fire.
Be sure to install an earth leakage breaker that can shut down all power supplies within
the system at the same time.
If you do not install a breaker, it may cause electric shock and fire.
During installation, make sure that the refrigerant pipe is attached firmly before you run
the compressor.
Do not operate the compressor under the condition of refrigerant piping not attached
properly with 2-way or 3-way valve open. This may cause abnormal pressure in the
refrigeration cycle that leads to rupture and even injury.
During the pump-down operation, make sure that the compressor is turned off be-
fore you remove the refrigerant piping. Do not remove the connection pipe while the
compressor is in operation with 2-way or 3-way valve open. This may cause abnormal
pressure in the refrigeration cycle that leads to breakage and even injury.
INSTALLATION MANUAL
VRF system outdoor unit
PART No. 9380545293-02
Contents
1. SAFETY PRECAUTIONS …………………………………………………………………1
2. ABOUT THIS PRODUCT ………………………………………………………………… 2
2.1. Precautions for using R410A refrigerant …………………………………………2
2.2. Special tools for R410A ……………………………………………………………2
2.3. Accessories …………………………………………………………………………2
2.4. Combinations ……………………………………………………………………… 3
2.5. Optional parts ……………………………………………………………………… 3
3. INSTALLATION WORK …………………………………………………………………… 3
3.1. Selecting an installation location ………………………………………………… 3
3.2. Drain processing …………………………………………………………………… 3
3.3. Installation dimensions …………………………………………………………… 3
3.4. Transporting the unit ………………………………………………………………4
3.5. Installing the unit …………………………………………………………………… 5
4. SYSTEM CONFIGURATION ………………………………………………………………5
4.1. System confi guration ……………………………………………………………… 5
4.2. Pipe selection ……………………………………………………………………… 5
4.3. Protection of pipes ………………………………………………………………… 6
5. PIPE INSTALLATION ………………………………………………………………………6
5.1. Brazing ………………………………………………………………………………6
5.2. Indoor unit pipe connections ……………………………………………………… 6
5.3. Opening the knockout hole ……………………………………………………… 7
5.4. Pipe connection …………………………………………………………………… 7
6. ELECTRICAL WIRING ……………………………………………………………………8
6.1. The precautions of electrical wiring ………………………………………………8
6.2. Knockout hole ……………………………………………………………………… 8
6.3. Selecting power supply cable and breaker ………………………………………8
6.4. Transmission line ……………………………………………………………………9
6.5. Wiring method ………………………………………………………………………9
6.6. External input and external output …………………………………………… 11
7. FIELD SETTING ………………………………………………………………………… 12
7.1. Field setting switches …………………………………………………………… 12
7.2. DIP switch setting ……………………………………………………………… 12
7.3. Rotary switch setting …………………………………………………………… 12
7.4. Push button setting ……………………………………………………………… 12
7.5. Address setting for signal amplifi ers …………………………………………… 14
7.6. Indoor unit address setting ……………………………………………………… 14
7.7. Resistance measurement of transmission cable
(Measure with breaker OFF) …………………………………………………… 14
8. PIPE INSTALLATION II ………………………………………………………………… 15
8.1. Sealing test ……………………………………………………………………… 15
8.2. Vacuum process ………………………………………………………………… 15
8.3. Additional charging ……………………………………………………………… 15
8.4. Installing insulation ……………………………………………………………… 16
8.5. Filling with putty ………………………………………………………………… 16
9. TEST RUN ……………………………………………………………………………… 16
9.1. Indoor unit connection check …………………………………………………… 16
9.2. Pre-check for test run …………………………………………………………… 17
9.3. Test run method ………………………………………………………………… 17
9.4. Checklist ………………………………………………………………………… 17
10. LED STATUS …………………………………………………………………………… 18
10.1. Normal operation codes ………………………………………………………… 18
10.2. Error codes ……………………………………………………………………… 18
11. INFORMATION ………………………………………………………………………… 18
