Side 1/12
OUTDOOR UNIT
INSTALLATION MANUAL
For authorized service personnel only.
PART No. 9374872206-02
AIR CONDITIONER
En-2
1. SAFETY PRECAUTIONS
Be sure to read this Manual thoroughly before installation.
The warnings and precautions indicated in this Manual contain important information
pertaining to your safety. Be sure to observe them.
Hand this Manual, together with the Operating Manual, to the customer. Request the
customer to keep them on hand for future use, such as for relocating or repairing the unit.
After installation, explain correct operation to the customer, using the operating manual.
WARNING This mark indicates procedures which, if improperly performed,
might lead to the death or serious injury of the user.
CAUTION
This mark indicates procedures which, if improperly performed,
might possibly result in personal harm to the user, or damage to
property.
WARNING
Never touch electrical components immediately after the power supply has been turned
off. Electrical shock may occur. After turning off the power, always wait 5 minutes or
more before touching electrical components.
Request your dealer or a professional installer to install the indoor unit in accordance
with this Installation Manual. An improperly installed unit can cause serious accidents
VXFKDVZDWHUOHDNDJHHOHFWULFVKRFNRU¿UH,IWKHLQGRRUXQLWLVLQVWDOOHGLQGLVUHJDUG
of the instructions in the Installation Manual, it will void the manufacturer’s warranty.
Do not turn ON the power until all work has been completed. Turning ON the power
EHIRUHWKHZRUNLVFRPSOHWHGFDQFDXVHVHULRXVDFFLGHQWVVXFKDVHOHFWULFVKRFNRU¿UH
If refrigerant leaks while work is being carried out, ventilate the area. If the refrigerant
FRPHVLQFRQWDFWZLWKDÀDPHLWSURGXFHVDWR[LFJDV
Installation work must be performed in accordance with national wiring standards by
authorized personnel only.
'XULQJLQVWDOODWLRQPDNHVXUHWKDWWKHUHIULJHUDQWSLSHLVDWWDFKHG¿UPO\EHIRUH\RXUXQ
the compressor.
Do not operate the compressor under the condition of refrigerant piping not attached
properly with 2-way or 3-way valve open. This may cause abnormal pressure in the
refrigeration cycle that leads to breakage and even injury.
When installing and relocating the air conditioner, do not mix gases other than the
VSHFL¿HGUHIULJHUDQW5$WRHQWHUWKHUHIULJHUDQWF\FOH
If air or other gas enters the refrigerant cycle, the pressure inside the cycle will rise to
an abnormally high value and cause breakage, injury, etc.
Do not remove the connection pipe while the compressor is in operation with 2-way or
3-way valve open.
This may cause abnormal pressure in the refrigeration cycle that leads to breakage and
even injury.
For the air conditioner to operate satisfactorily, install it as outlined in this installation
manual.
Connect the indoor unit and outdoor unit with the air conditioner piping and cable
available standards parts.
This installation manual describes the correct connections using the installation set
available from our standard parts.
Also, do not use an extension cable.
WARNING
Do not purge the air with refrigerants but use a vacuum pump to vacuum the
installation.
There is not extra refrigerant in the outdoor unit for air purging.
8VHDYDFXXPSXPSIRU5$H[FOXVLYHO\
Using the same vacuum pump for different refrigerants may damage the vacuum pump
or the unit.
8VHDFOHDQJDXJHPDQLIROGDQGFKDUJLQJKRVHIRU5$H[FOXVLYHO\
During the pump-down operation, make sure that the compressor is turned off before
you remove the refrigerant piping.
Do not remove the connection pipe while the compressor is in operation with 2-way or
3-way valve open.
This may cause abnormal pressure in the refrigeration cycle that leads to breakage and
even injury.
CAUTION
Read carefully all security information before use or install the air conditioner.
Do not attempt to install the air conditioner or a part of the air conditioner by yourself.
7KLVXQLWPXVWEHLQVWDOOHGE\TXDOL¿HGSHUVRQQHOZLWKDFDSDFLW\FHUWL¿FDWHIRUKDQGOLQJ
UHIULJHUDQWÀXLGV5HIHUWRUHJXODWLRQDQGODZVLQXVHRQLQVWDOODWLRQSODFH
The installation must be carried out in compliance with regulations in force in the place
of installation and the installation instructions of the manufacturer.
This unit is part of a set constituting an air conditioner. It must not be installed alone or
with non-authorized by the manufacturer.
Always use a separate power supply line protected by a circuit breaker operating on all
wires with a distance between contact of 3 mm for this unit.
7KHXQLWPXVWEHFRUUHFWO\HDUWKHGJURXQGHGDQGWKHVXSSO\OLQHPXVWEHHTXLSSHG
with a differential breaker in order to protect the persons.
The units are not explosion proof and therefore should not be installed in explosive
atmosphere.
This unit contains no user-serviceable parts. Always consult authorized service
personnel to repairs.
When moving, consult authorized service personnel for disconnection and installation
of the unit.
Children should be monitored to ensure they do not play with the device.
7KLVDSSOLDQFHLVQRWLQWHQGHGIRUXVHE\SHUVRQVLQFOXGLQJFKLOGUHQZLWKUHGXFHG
physical, sensory or mental capabilities, or lack of experience and knowledge, unless
they have been given supervision or instruction concerning use of the appliance by a
person responsible for their safety. Children should be supervised to ensure that they
do not play with the appliance.
'RQRWWRXFKWKHDOXPLQXP¿QVRIKHDWH[FKDQJHUEXLOWLQWKHLQGRRURURXWGRRUXQLWWR
avoid personal injury when you install or maintain the unit.
Do not place any other electrical products or household belongings under indoor unit
or outdoor unit.
Dripping condensation from the unit might get them wet, and may cause damage or
malfunction of your property.
2. ABOUT THE PRODUCT
2. 1. Precautions for using R410A refrigerant
WARNING
The basic installation work procedures are the same as conventional refrigerant models.
However, pay careful attention to the following points:
 6LQFHWKHZRUNLQJSUHVVXUHLVWLPHVKLJKHUWKDQWKDWRIFRQYHQWLRQDOUHIULJHUDQW
5PRGHOVVRPHRIWKHSLSLQJDQGLQVWDOODWLRQDQGVHUYLFHWRROVDUHVSHFLDO6HH
WKHWDEOHEHORZ
(VSHFLDOO\ZKHQUHSODFLQJDFRQYHQWLRQDOUHIULJHUDQW5PRGHOZLWKDQHZ
UHIULJHUDQW5$PRGHODOZD\VUHSODFHWKHFRQYHQWLRQDOSLSLQJDQGÀDUHQXWVZLWK
WKH5$SLSLQJDQGÀDUHQXWV
 0RGHOVWKDWXVHUHIULJHUDQW5$KDYHDGLIIHUHQWFKDUJLQJSRUWWKUHDGGLDPHWHU
WRSUHYHQWHUURQHRXVFKDUJLQJZLWKFRQYHQWLRQDOUHIULJHUDQW5DQGIRUVDIHW\
7KHUHIRUHFKHFNEHIRUHKDQG>7KHFKDUJLQJSRUWWKUHDGGLDPHWHUIRU5$LV
81)WKUHDGVSHULQFK@
 %HFDUHIXOWKDWIRUHLJQPDWWHURLOZDWHUHWFGRHVQRWHQWHUWKHSLSLQJWKDQZLWK
refrigerant models. Also, when storing the piping, securely seal the openings by
pinching, taping, etc.
 When charging the refrigerant, take into account the slight change in the composition
of the gas and liquid phases. And always charge from the liquid phase where
refrigerant composition is stable.
Contents
 6$)(7<35(&$87,216 ……………………………………………………………… 2
2. ABOUT THE PRODUCT
 3UHFDXWLRQVIRUXVLQJ5$UHIULJHUDQW ………………………………………… 2
 6SHFLDOWRROVIRU5$ …………………………………………………………… 3
2. 3. Accessories ………………………………………………………………………… 3
 6\VWHPFRQ¿JXUDWLRQ ……………………………………………………………… 3
2. 5. Operating range …………………………………………………………………… 4
3. INSTALLATION WORK
 6HOHFWLQJDQLQVWDOODWLRQORFDWLRQ ………………………………………………… 4
3. 2. Drain installation …………………………………………………………………… 5
3. 3. Installation dimensions …………………………………………………………… 5
3. 4. Transportation of the unit ………………………………………………………… 6
3. 5. Installation of the unit ……………………………………………………………… 6
4. PIPE INSTALLATION I
 )ODUHFRQQHFWLRQSLSHFRQQHFWLRQ ……………………………………………… 7
5. ELECTRICAL WIRING
 7KHSUHFDXWLRQVRIHOHFWULFDOZLULQJ ……………………………………………… 8
5. 2. Electrical requirement ……………………………………………………………… 8
5. 3. Unit wiring …………………………………………………………………………… 8
5. 4. Connection diagrams ……………………………………………………………… 8
5. 5. Outdoor unit ………………………………………………………………………… 9
6. PIPE INSTALLATION II
 9DFXXP ……………………………………………………………………………… 9
6. 2. Additional charging ……………………………………………………………… 
7. POWER ………………………………………………………………………………… 
8. TEST RUN
 0DNHD7(67581LQDFFRUGDQFHZLWKWKHLQVWDOODWLRQ0DQXDO
for the indoor unit ………………………………………………………………… 
8. 2. Outdoor unit LEDS ……………………………………………………………… 
9. PUMP DOWN……………………………………………………………………………
