Data Sheet FUJITSU Storage CELVIN NAS Q905 Storage ®

Page 1 / 7 www.fujitsu.com/fts/accessories

Data Sheet

FUJITSU Storage CELVIN NAS Q905 ®

Storage

Powerful 6-Drive NAS

The FUJITSU CELVIN® NAS Q905 is the ideal product for le sharing, end to end backup

options and SAN (Storage Area Network) integration for SMB customers - enabling

centralized data management at a reasonable price. It is perfect for storing massive

amounts of unstructured data or the management of virtual machines with scalability up to

36 TB and additional virtual disk expansion.

Business Server Feature

6 hot swappable drives



Integrated backup server with diverse replication modes



iSCSI storage for cluster virtualization

VMWare®/Citrix®/HyperV™ Capable

Enabling private cloud

Reliability

Service-friendly cabinet

3-years spare part supply

Country-specic warranty

Top-up services are available

Data Sheet FUJITSU Storage CELVIN NAS Q905 Storage ®

Page 2 / 7 www.fujitsu.com/fts/accessories

CELVIN® NAS Q905

Technical specications

Linux embedded system (2.6 kernel)

Firmware based on 4.1.3 or higher

Processor: Intel® Celeron® J1900 up to 2,41GHz

Memory: 2 GB DDR3L RAM, one free slot, max up to 8GB

512 MB Flash on DOM

FAN:2x quiet cooling fan (9 cm)

Intel® Ethernet Controller I210-AT

Formfactor: Tower

Hard disk capacity Up to 6 x 2.5-inch or 3.5-inch SATA I/II/SATA 6Gb/s HDD or SSD up to 36TB raw capacity, consult HDD compatibility list

NAS HDD: ready for 24x7 use; Business Critical HDD: tailored for 24x7 reliability

LED USB

Status

HDD 1 -6

LAN

Power

System controls Power button, One-touch copy button, Alarm Buzzer (System Warning), Reset Button, Display mode button

Color Black housing, copper colored trays

Interfaces

USB 3.0 total Rear side: x2, front: x1

HDMI Rear side: p2-x1

LAN / Ethernet Rear side: p2-x4 Gigabit RJ-45 Ethernet port (always on)

Software specication

Networking TCP/IP (IPv4 /IPv6 dual stack), multi IP setting,LACP,

Port trunking /NIC teaming:

Balance-rr (Round-Robin), Active Backup, Balance XOR, Broadcast, IEEE 802.3ad,

Balance-tlb (Adaptive, Transmit Load Balancing), Balance-alb (Adaptive Load Balancing)

DHCP client, DHCP server including PXE boot

CIFS/SMB(1.0,2.0,2.1,3.0 selectable), SAMBA 4, AFP/Netatalk3.3, NFS v3, HTTP, HTTPS, FTP,SFTP(admin),

DDNS, NTP, Telnet, SSH, iSCSI, SNMP,WebDAV,SMSC

4 Gigabit w/ Jumbo Frame, Bonjour

iSCSI target (with multi-LUNs per target), Up to 256 LUNs/targets combined

iSCSI LUN online expansion

LUN mapping / LUN masking

Online LUN capacity expansion

SCSI Primary Commands -3 (SPC-3) support / persistent reservation

MC/S (multiple TCP connections / session) support to reach iSCSI target

MPIO (multipath input output) for load balancing and failover

iSCSI LUN Backup, One-time-Snapshot and Restore

iSCSI initiator for virtual disks (max 8 disks); stack chaining master

Virtual disk support for EXT3/ EXT4/ NTFS/ FAT32/ HFS+

iSCSI Connection and Management by Fujitsu Finder (Windows)

Support for VMware VSphere (ESXi 5.x) via NFS and iSCSI

(VMware VAAI for iSCSI and VAAI for NAS)

Windows Server 2008 support (Hyper-V & failover clustering)

Windows Server 2012 R2 Hyper-V;

ODX support

Citrix XenServer (6.2)

VLAN 802.1Q

USB WiFi-Adapter support IEEE 802.11b/g/n/ac

WEP, WPA-personal (AES/TKIP), WPA2-personal (AES)

Connection to wireless network or Ad Hoc network

Produkt Specifikationer

Mærke:	Fujitsu
Kategori:	Server
Model:	CELVIN NAS Q905
Type:	NAS
Tænd-/slukkontakt:	Ja
Vekselstrømsindgangsspænding:	100-240 V
Vekselstrømsindgangsfrekvens:	50 - 60 Hz
Bredde:	257 mm
Dybde:	235 mm
Højde:	175 mm
Vægt:	5300 g
Produktfarve:	Sort
Wi-Fi:	Ingen
Relativ luftfugtighed ved drift (H-H):	5 - 95 %
Antal HDMI-porte:	1
Ethernet LAN-porte (RJ-45):	4
Antal USB 2.0-porte:	2
Antal USB 3.2 Gen 1 (3.1 Gen 1) type-A-porte:	3
Ethernet LAN:	Ja
Processorkerner:	4
Strømforbrug (typisk):	250 W
Driftstemperatur (T-T):	0 - 40 °C
Intern hukommelse:	2 GB
Operativsystem installeret:	Linux
Certificering:	CE, FCC Class B
Balance system:	Ja
Webbaseret administration:	Ja
Knap til nulstilling:	Ja
Intel® Wireless Display (Intel® WiDi):	Ingen
Processorfrekvens:	2 GHz
Processorserie:	Intel® Celeron®
Processor boost frekvens:	2.42 GHz
Processortråde:	4
Processor-cache:	2 MB
Processor cache type:	L2
Intern hukommelsestype:	DDR3L
On-board grafikkort, model:	Intel® HD Graphics
Intel® Hyper Threading Teknologi (Intel® HT Technology):	Ingen
Intel® Turbo Boost Teknologi:	Ingen
Processorproducent:	Intel
Processormodel:	J1900
Flashhukommelse:	512 MB
Enhanced Intel SpeedStep Teknologi:	Ja
Udfør deaktivering af bit:	Ja
CPU-konfiguration (maks.):	1
Indlejret tilgængelige muligheder:	Ja
Intel® 64:	Ja
Intel® Virtualization Technology for Directed I/O (VT-d):	Ingen
Intel® Virtualization Technology (VT-x):	Ja
Lydalarm:	Ja
Antal blæsere:	2 blæser(e)
Størrelse på lagerdisk:	- "
Understøttet datalagringsdrev typer:	HDD
Antal understøttede lagerdiske:	6
Datalagringsdriver installeret:	Ja
Kabinettype:	Tower
Intel® Stabil Billede Platformsprogram (SIPP):	Ingen
Intel® Identity Protection Technology version:	0.00
Intel® Stable Billede Platform Program (SIPP) version:	0.00
Konfliktfri processor:	Ja
Ventilator diameter:	90 mm
Processor sokkel:	BGA 1170
Processor litografi:	22 nm
Stepping:	B3
Thermal Design Power (TDP):	10 W
Maksimalt antal PCI Express-kanaler:	4
PCI Express slots version:	2.0
PCI Express-konfigurationer:	1x4
Fejlkorrigerende kode understøttet af processor:	Ingen
Tjunction:	105 °C
Processor front side bus:	- Mhz
Systembus-hastighed:	- GT/s
Processor driftstilstande:	32-bit,64-bit
Processor kodenavn:	Bay Trail
Intel® InTru™ 3D Teknologi:	Ingen
Intel® Insider™:	Ingen
Intel® Anti-Theft Teknologi (Intel® AT):	Ingen
Intel® Identity Protection Teknologi (Intel® IPT):	Ingen
Intel® Quick Sync Video Teknologi:	Ja
Intel® AES Nye Instruktioner (Intel® AES-NI):	Ingen
Intel® FDI Teknologi:	Ingen
Intel® Rapid Storage Teknologi:	Ingen
Processor-pakke størrelse:	25 X 27 mm
Processor kode:	SR1SC
Grafisk og IMC litografi:	22 nm
Processor ARK ID:	78867
Indbygget grafikadapter basefrekvens:	688 Mhz
Indbygget grafikadapter dynamisk frekvens (maks.):	854 Mhz
Understøtter RAID:	Ja
Installeret lagerdisktype:	HDD
Antal installerede lagerdiske:	6
Total installeret opbevaringskapacitet:	12 TB
Maksimalt understøttet lagerkapacitet:	24 TB
Kapacitet af datalagringsdrev:	2000 GB
RAID-niveauer:	0,1,5+HS,5,6,6+S,10+S,10,JBOD
Hot-swap drevbåse:	Ja
Backup funktion:	Ja
Maksimal intern hukommelse understøttet af processor:	8 GB
Hukommelsestyper understøttet af processor:	DDR3L-SDRAM
Antal understøttede skærme (indbygget grafik):	2
Intel® Small Business Advantage (SBA) version:	0.00
Fysisk adresse udvidelse (PAE):	36 Bit
Hukommelseskanaler understøttet af processor:	Dobbelt
iSCSI-understøttelse:	Ja
Indbygget FTP-server:	Ja
