FULGOR FULGOR MILANO MILANO
Product specications are subject to change. Always refer to the latest installation guide on the website. Product specications are subject to change. Always refer to the latest installation guide on the website.
30" OVERLAY WARMING DRAWER 30" OVERLAY WARMING DRAWER
† To achieve full ADA compliance, please consult the current ADA requirements for product installation instructions.
Overlay panel installation
Pull-to open and Push-to-close
Heavy Duty full extension rails
True convection heating system
All stainless steel structure
Warming Temperature range: min. 90 °F up to 195 °F;
Handle and overlay panel not included
Slow cooking min. 90 °F up to 195 °F
Close/Open Mechanism Pull-to-open and Push-to-close
Drawer Material Stainless Steel
Compatible Ovens F7MSP30S1-F7MDP30S1 - F7MSCO30S1- F7MSPD30S1 - F4MSP30S1
Temperature (max), °F (°C) 195 (90)
Thermostat, °F (°C) 90 - 195 (30 - 90)
Interior Lights 2 x 20 W Halogen
Volume (each), cu. ft. (L) 1.9 (53.3)
Useable Width, in. (mm) 24-3/8 (620)
Useable Height, in. (mm) 7-7/8 (200)
Useable Depth, in. (mm) 16-7/8 (430)
Product Width, in. (mm) 29-5/8 (754)
Product Height, in. (mm) 10-3/8 (264)
Product Depth, in. (mm) 22-7/8 (581)
Cutout Width, in. (mm) 28-3/8 (722)
Cutout Height (min), in. (mm) 9 1/4 (235)
Cutout Depth (min), in. (mm) 24 (610)
Net Weight, lbs. (kg) 67.2 (30.5)
Max power absorbed (W) 1100 W
Power Cable Lenght, in. (mm) 86 5/8 (2200)
Use & Care Manual / Installation Manual English / French / Spanish
Limited Warranty Parts and Labor (2-year)
The 600 series 30” pull-to-open panel warming drawer (requires handle), equipped with a soft-closing
mechanism, offers unmatched versatility for modern kitchens. Featuring a unique true convection design,
this practical appliance goes beyond just warming—it also excels at slow cooking, proong, dehydrating,
and defrosting, all within a compact, fully enclosed space. The convection fan ensures even heat
distribution, keeping your side dishes, pies, and bread at the perfect temperature from top to bottom.
Whether you’re prepping or serving, this warming drawer is the ultimate kitchen companion.
Americans with Disabilities Act †
