Instructions
MINIPORT CN-15MP
and CN-20MP
CONTRACTOR SERIES SmartSequencer™
C US
15 AMP
MINIPORT
120 VAC, 50/60 Hz
MAX LOAD 15A
POWER
EXTREME VOLTAGE
CLASS 2 WIRING
FORCE
OFF
P
P
S
S
SECONDARY
LINK
SMARTSEQUENCING
OUT
IN
+12V
STAT
REM
GND
DLY OUT
REMOTE
PORT
PRIMARY
LINK
BYPASS
120 VAC
/60/HZ
A MAX.
15 AMPS
PUSH TO RESET
C US
CN-15MP
120 VAC
/60/HZ
A MAX.
120 VAC
/60/HZ
A MAX.
C US
20 AMP
MINIPORT
120 VAC, 50/60 Hz
MAX LOAD 20A
POWER
EXTREME VOLTAGE
CLASS 2 WIRING
FORCE
OFF
P
P
S
S
SECONDARY
LINK
SMARTSEQUENCING
OUT
IN
+12V
STAT
REM
GND
DLY OUT
REMOTE
PORT
PRIMARY
LINK
BYPASS
C US
CN-20MP
CN-15MP
Contractor Grade Power Management with
SmartSequencing™ Technology
Features:
SmartSequencing™ technology allows large complex A/V systems to
be safely power cycled on and off sequentially, with the press of a button.
Extreme Voltage Shutdown (EVS) with safeguards against operation
during under and over voltage conditions.
Security features include cover shield to prevent tampering with switch
settings.
Forced Off immediate shutdown: for safety and fire ordinance compliance.
Multi-Color LED Indicators for status functions.
2 Power Outlets on 1 bank providing 1800 Watts of AC power (CN-15MP)
and 2400 Watts of AC power (CN-20MP).
CN-15MP – 10 ft. Power Cord 14AWG
CN-20MP - 10 ft. Power Cord 12AWG
15 Year Limited Product Warranty
CN-20MP
CN-15-20MP-DIN-00020-A
1
C US
15 AMP
MINIPORT
120 VAC, 50/60 Hz
MAX LOAD 15A
POWER
EXTREME VOLTAGE
CLASS 2 WIRING
FORCE
OFF
P
P
S
S
SECONDARY
LINK
SMARTSEQUENCING
OUT
IN
+12V
STAT
REM
GND
DLY OUT
REMOTE
PORT
PRIMARY
LINK
BYPASS
120 VAC
/60/HZ
A MAX.
15 AMPS
PUSH TO RESET
C US
CN-15MP
120 VAC
/60/HZ
A MAX.
120 VAC
/60/HZ
A MAX.
C US
20 AMP
MINIPORT
120 VAC, 50/60 Hz
MAX LOAD 20A
POWER
EXTREME VOLTAGE
CLASS 2 WIRING
FORCE
OFF
P
P
S
S
SECONDARY
LINK
SMARTSEQUENCING
OUT
IN
+12V
STAT
REM
GND
DLY OUT
REMOTE
PORT
PRIMARY
LINK
BYPASS
C US
CN-20MP
Introduction
Congratulations and thank you for choosing the Furman CN-15MP or CN-
20MP Miniport. We assure you that your Miniport will provide many years
of trouble free operation. The Miniport Power Sequencer is equipped with
Furman’s exclusive SmartSequencing™ technology. SmartSequenc-
ing™ defines a whole new level of power management and control while
streamlining installations from start to finish.
Why choose Furman?
At Furman Sound, we have spent the last 30 years quietly obsessing
about professional audio and how to best separate your equipment from
the noise and damage often associated with AC power. Over the years we
have developed a multitude of technologies that have spared countless
devices from damage and earned the trust and respect of the Profession-
al A/V industry. The Contractor series represents the culmination of our
engineering expertise and leverages more than 30 years of experience.
Why choose AC power sequencing?
Many pro audio/video installations need audio power amplifiers to activate
last. Our solution is the AC power sequencer. The power sequencer pro-
vides AC power to outlet groups one at a time, thus allowing equipment to
be powered up and down in an orderly fashion by first providing power to
signal processing equipment and then providing power to the amplifiers.
When shutting down the A/V system, a sequencer will turn off the system
in the reverse order, hence the amps will be turned off first, and then the
signal processing equipment will be turned off last.
This is necessary because, as most sound reinforcement professionals
know, the majority of equipment damage occurs when devices are either
being powered up or powered down. Power sequencing allows equip-
ment to power up in sequence which prevents the dreaded speaker “pop”
associated with on off switching of signal processing equipment while
the audio power amplifiers are energized. If the signal processing “pop”
is amplified sufficiently, the result can damage amplifiers and speaker
components. Because it prevents this unwanted, and often costly, circum-
stance, AC power sequencing is extremely valuable.
Furman Contractor Series equipment allows sound reinforcement equip-
ment to be remotely powered up or powered down over a large distance,
not just in the immediate vicinity of the operator. A remotely mounted
switch or control pad can be used to sequence equipment on or off. In
addition, Furman Contractor Series remote functions can be initiated
across a room, on-site, or off-site with our BlueBOLT technology.
The Miniport SmartSequencer fulfills many power sequencing require-
ments that have very difficult to achieve in the past. Furman SmartSe-
quencing™ delivers an end-to-end solution right out of the box! Please
review this manual to discover how the Miniport with SmartSequencing™
can deliver professional results for you.
Before You Begin Inspect Upon Receipt
The box should contain the following items:
1) Miniport CN-15MP or CN-20MP
2) Quick Start Guide
3) Phoenix –Type Connectors
CN-15MP
CN-15MP
CN-15MP Quick Start Guide
CN-20MP Quick Start Guide
CN-20MP
3 Phoenix Type Connectors
FORCE
OFF
1. FOUR PIN CONNECTOR
2. TWO PIN CONNECTOR
3. FIVE PIN CONNECTOR
3 Phoenix Type Connectors
FORCE
OFF
1. FOUR PIN CONNECTOR
2. TWO PIN CONNECTOR
3. FIVE PIN CONNECTOR
CN-20MP
