8” SUPER SLIM ACTIVE SUBWOOFER
SPECIFICATIONS
CP-AS1080
Peak Power (Watts) 300
Rated Power (Watts) 100
Frequency Response 20Hz - 120Hz
Dimensions (mm) 330(l) x 245(w) x 78(h)
13 x 9-5/8 x 3”
CP-AS1080
www.fusionelectronics.com
INSTALLATION GUIDELINES
1. Ensure the +12V lead is disconnected from the battery before you connect any new equipment.
2. Ensure the mounting location will not interfere with the gas tank, brake lines or electrical wiring.
3. Ensure the Super Slim Active Subwoofer is securely fastened to the vehicle to prevent damage in the event of an accident.
4. Ensure all wiring is protected to avoid pinching or crushing which could result in damage to the audio system.
5. Ensure the mounting location has sufficient air flow around the amplifier.
6. Ensure you use the recommended gauge wire/cable for all amplifier connections.
WIRING
Ensure the audio system is turned off before making any connections
to the amplifier, speakers or source unit.
Failure to do so could result in permanent damage to the audio
system. When wiring the FUSION Super Slim Active Subwoofer
ensure that the cable is protected from sharp objects and always
use rubber grommets when wiring through metal panels.
Ensure all terminals and connections are protected from the vehicle
chassis, and from each other, as failure to do so could result in
permanent damage to the audio system.
FUSION Electronics recommends 8 gauge wire (power & ground).
GROUND
When grounding/earthing your Super Slim Active Subwoofer
ensure that the location is a good source of ground (preferably the
floor pan). Make sure the metal is clean of paint etc as a poor earth
could damage your audio system.
Note: This is the first connection to be made!!
REMOTE TURN ON
This connection turns the amplifier on and should be connected to
the remote turn on wire from the Head Unit. If one is not available
a switched 12V source must be used. Either a power antenna wire
or ACC +12V.
POWER
Connect the power lead directly to the +12V battery terminal with
an inline fuse or circuit breaker as close to the battery as possible.
LOW LEVEL INPUTS
Choose the correct length RCA interconnects and run them to the
RCA outputs of the source/head unit, avoiding running beside other
looms and or power cable.
Note: For correct performance both input RCA connectors must
be used.
HIGH LEVEL INPUTS (SPEAKER LEVEL)
If your head unit does not have RCA outputs, you can use the
speaker outputs for the audio source for the CP-AS1080. Use the
supplied cable and wire harness and connect the speaker outputs
from the source to the high level Input. Be sure to observe polarity
to avoid audio phase problems.
Note: When using the high level connection, the Level MUST be set
to minimum or the Subwoofer will be permanently damaged and
could void your warranty.
LOW LEVEL OUTPUTS
Use the RCA output connectors to make one CP-AS1080 linkable
to multiple CP-AS1080 Super Slim Active Subwoofers. This output
is a pass-thru connection derived from the RCA input connector so
the signal level and frequency response is the same as the original
input signal.
PUBLISHED BY FUSION ELECTRONICS LIMITED: © Copyright 2011 by FUSION Electronics Limited. All rights reserved. Specifications and design are subject to change without notice. v3.0
YOU CAN HELP PROTECT THE ENVIRONMENT! Please remember to respect the local regulations: Hand in the non-working electrical equipment to an appropriate waste disposal center.
RECORD YOUR PURCHASE DETAILS HERE:
SERIAL NUMBER
DATE OF PURCHASE
AFFIX RECEIPT HERE
WARNING: Audio Systems can produce sound levels over 135dB. Continuous exposure to sound pressure levels over 100dB may cause permanent
hearing loss! Please watch for emergency vehicles as warning signals may not be heard. USE COMMON SENSE!
TROUBLE SHOOTING
Problem Possible Reason Solution
Not switching on.. • No +12V to power wire • Check fuses and connections to battery
Power LED not ‘on’. • No power to remote wire • Check remote on connections to head unit
• Fuse broken • Replace fuse with correct type and amperage
Not working, but status • Fuse blown • Replace fuse with correct type and amperage
LED is ‘on’ • Amplifier too hot • Move amplifier to vented area
• Turn head unit down
No Sound • RCA Signal • Check RCA connection to head unit
• Gain control not set up • Ensure you have set up the amplifier gain level control
• Head Unit • Check head unit volume level
• Connections • Check all power, remote on and ground connections
For further product and installation information, please visit www.fusionelectronics.com
Pour plus d’informations sur les produits et l’installation, rendez-vous sur www.fusionelectronics.com
Para obtener más información acerca de los productos y de su instalación, visite el sitio web www.fusionelectronics.com
Bezoek www.fusionelectronics.com voor meer product- en installatie-informatie.
Weitere Produkt- und Installationsinformationen finden Sie unter www.fusionelectronics.com
Per ulteriori informazioni sui prodotti e la loro installazione, potete visitare www.fusionelectronics.com
Для получения дополнительной информации о продуктах и установке зайдите, пожалуйста, на: www.fusionelectronics.com
LEVEL CONTROL
This control is used to match the input level of the amplifier to
the output level of your head unit. We recommend the following
method.
1. Turn the amplifier level to zero
2. Turn the volume of the head unit to ¾ & the bass & treble to zero
3. Adjust the level control until the desired maximum volume is
achieved without distortion
4. Failure to follow these steps may cause permanent damage to
the audio system
LOW PASS FILTER
Ensure the crossover frequency is set at 120Hz or below. This
feature is designed to filter out all mid to high frequencies that only
full range speakers should produce
BASS BOOST
Set the bass boost level to increase the bass at 45Hz. Selectable
from 0dB - 12dB gains
REMOTE CONTROL LEVEL INPUT
Attach the remote level control (via the included cable) to control
the volume level of the subwoofer independently at the front of the
vehicle.
PHASE SHIFT (0-180 DEG)
Use this switch to help compensate for time alignment problems
in the system. Such problems usually result from having the
subwoofer at a different distance from the listener than the other
speakers in the system.
