QUICK START GUIDE

COUNTERTOP FRY CUTTERS

MODELS

PRE-DRILLED LEGS

181FC14 - 1/4" Fry

181FC38 - 3/8" Fry

181FC12 - 1/2" Fry

181FCWDG6 - 6 Wedge

181FCWDG8 - 8 Wedge

SUCTION CUP FEET

181FC14SC - 1/4" Fry

181FC38SC - 3/8" Fry

181FC12SC - 1/2" Fry

181FCWDG6SC - 6 Wedge

181FCWDG8SC - 8 Wedge

SAFETY INSTRUCTIONS

CAUTION

Be careful when handling and operating the machine, as

the blades are very sharp. Always keep your hands away

from the blades.

WALL MOUNT INSTRUCTIONS

NOTE: It’s important that the unit be mounted to

a stud to prevent it from falling during use!

1. Position the unit where you’d like it to be mounted.

2. Find the closest stud and move the machine so that

the mounting holes on one side of the unit are over

the stud.

3. Mark the 4 hole locations and remove the machine.

4. Drill 5/32" holes through these marks.

5. Re-position the unit on the wall aligned with the holes

and secure using washers and mounting screws.

COUNTER MOUNT INSTRUCTIONS

1. Choose a spot on a sturdy countertop where you'd like

to mount the unit. Ensure the mounting screws will not

penetrate anything under the counter.

2. Mark the 4 hole locations and remove the machine.

3. Drill 5/32" holes through these marks.

4. Re-position the unit to align with the holes and secure

using washers and mounting screws.

OPERATION

1. Put a potato on the blade and holder assembly.

2. After making sure your hands and ngers are clear of

the cutting area, pull the handle in one quick motion.

a. This may occasionally need to be repeated for

potatoes that are exceptionally large.

b. DO NOT try to cut potatoes that are bigger than

the opening in the blade holder.

3. When nished, be sure to clean the machine using the

instructions below.

NOTE: To cut 1/4" and 1/2", use the 1/4" push block.

To cut 3/8", use the 3/8" push block.

CLEANING

NOTE: Avoid using alkaline cleaners as they may dull the

nish and cause pitting.

1. Release the push block by removing the thumb screws.

2. Release the blade & holder assembly by removing the

wing nuts.

3. Carefully remove the blade & holder assembly, as well

as the push block.

4. Wash the push block and blade and holder assembly.

5. The blade & holder assembly can be further

disassembled for more thorough cleaning by:

a. Removing the thumb screws and blade holder plate.

b. Lightly tapping the blades and spacers to remove

them from the holder.

6. To reassemble the blade and holder assembly:

a. Put the blade holder on a at surface with the

spacer pockets facing up.

b. Insert blade spacers with their slots facing the

inner opening of the blade holder.

c. Insert blades with cutting edge facing down

and slots facing up.

d. Insert blades with cutting edge and slots facing

down.

e. Put the blade holder plate into place and secure

it with the thumbscrews.

7. Simply reverse the disassembly instructions to

reassemble the fry cutter.

8. When needed, lubricate the guide rods with mineral oil,

food grade grease or parafn.

NOTE: DO NOT use cooking oil.

08/2023

QUICK START GUIDE

COUNTERTOP FRY CUTTERS

REPLACEMENT PARTS

BLADE ASSEMBLIES

#181PBA14 #181PBA38 #181FCWDG6BLD #181FCWDG8BLD#181PBA12

1/4" 3/8" 1/2" 6-Section Wedge 8-Section Wedge

BLADES

#181PBLD14 #181PBLD38 #181PBLD12

1/4" (22 Blades) 3/8" (16 Blades) 1/2" (10 Blades)

PUSHER BLOCKS

#181PPB38 #181PPB1412 #181FCWDG6PB #181FCWDG8PB

3/8" 1/4" 1/2" 6-Section Wedge 8-Section Wedge

ADDITIONAL PARTS

#181BRKTFF #181BUMPER #181SSWNUT #181TSCREW #181FT1

Wall Bracket Bumper Wingnut Thumb Screw Feet (4)

08/2023
