Side 1/2
QUICK START GUIDE
COUNTERTOP FRY CUTTERS
MODELS
PRE-DRILLED LEGS
181FC14 - 1/4" Fry
181FC38 - 3/8" Fry
181FC12 - 1/2" Fry
181FCWDG6 - 6 Wedge
181FCWDG8 - 8 Wedge
SUCTION CUP FEET
181FC14SC - 1/4" Fry
181FC12SC - 1/2" Fry
181FCWDG6SC - 6 Wedge
181FCWDG8SC - 8 Wedge
SAFETY INSTRUCTIONS
CAUTION
Be careful when handling and operating the machine, as
the blades are very sharp. Always keep your hands away
from the blades.
WALL MOUNT INSTRUCTIONS
NOTE: It’s important that the unit be mounted to
a stud to prevent it from falling during use!
1. Position the unit where you’d like it to be mounted.
2. Find the closest stud and move the machine so that
the mounting holes on one side of the unit are over
the stud.
3. Mark the 4 hole locations and remove the machine.
4. Drill 5/32" holes through these marks.
5. Re-position the unit on the wall aligned with the holes
and secure using washers and mounting screws.
COUNTER MOUNT INSTRUCTIONS
1. Choose a spot on a sturdy countertop where you'd like
to mount the unit. Ensure the mounting screws will not
penetrate anything under the counter.
2. Mark the 4 hole locations and remove the machine.
3. Drill 5/32" holes through these marks.
4. Re-position the unit to align with the holes and secure
using washers and mounting screws.
OPERATION
1. Put a potato on the blade and holder assembly.
2. After making sure your hands and ngers are clear of
the cutting area, pull the handle in one quick motion.
a. This may occasionally need to be repeated for
potatoes that are exceptionally large.
b. DO NOT try to cut potatoes that are bigger than
the opening in the blade holder.
3. When nished, be sure to clean the machine using the
instructions below.
NOTE: To cut 1/4" and 1/2", use the 1/4" push block.
To cut 3/8", use the 3/8" push block.
CLEANING
NOTE: Avoid using alkaline cleaners as they may dull the
nish and cause pitting.
1. Release the push block by removing the thumb screws.
2. Release the blade & holder assembly by removing the
wing nuts.
3. Carefully remove the blade & holder assembly, as well
as the push block.
4. Wash the push block and blade and holder assembly.
5. The blade & holder assembly can be further
disassembled for more thorough cleaning by:
a. Removing the thumb screws and blade holder plate.
b. Lightly tapping the blades and spacers to remove
them from the holder.
6. To reassemble the blade and holder assembly:
a. Put the blade holder on a at surface with the
spacer pockets facing up.
b. Insert blade spacers with their slots facing the
inner opening of the blade holder.
c. Insert blades with cutting edge facing down
and slots facing up.
d. Insert blades with cutting edge and slots facing
down.
e. Put the blade holder plate into place and secure
it with the thumbscrews.
7. Simply reverse the disassembly instructions to
reassemble the fry cutter.
8. When needed, lubricate the guide rods with mineral oil,
food grade grease or parafn.
NOTE: DO NOT use cooking oil.
08/2023
QUICK START GUIDE
COUNTERTOP FRY CUTTERS
REPLACEMENT PARTS
BLADE ASSEMBLIES
#181PBA14 #181PBA38 #181FCWDG6BLD #181FCWDG8BLD#181PBA12
1/4" 3/8" 1/2" 6-Section Wedge 8-Section Wedge
BLADES
#181PBLD14 #181PBLD38 #181PBLD12
1/4" (22 Blades) 3/8" (16 Blades) 1/2" (10 Blades)
PUSHER BLOCKS
#181PPB38 #181PPB1412 #181FCWDG6PB #181FCWDG8PB
3/8" 1/4" 1/2" 6-Section Wedge 8-Section Wedge
ADDITIONAL PARTS
#181BRKTFF #181BUMPER #181SSWNUT #181TSCREW #181FT1
Wall Bracket Bumper Wingnut Thumb Screw Feet (4)
08/2023
