QUICK START GUIDE
HEAVY-DUTY MOUNTABLE DICERS
MODELS
SAFETY INSTRUCTIONS
CAUTION: Be careful when handling, operating, and cleaning
the machine, as the blades are very sharp. Always keep
your hands away from the blades.
1. Release the push block by removing the thumb screws.
2. Release the blade and holder assembly by removing the
3. Carefully remove the blade and holder assembly, as well as
the push block.
4. Wash the push block, blade, and holder assembly.
The blade and holder assembly can be further
disassembled for more thorough cleaning by:
• Removing the thumb screws and blade holder plate.
• Lightly tapping the blades and spacers to remove them
from the holder.
To reassemble the blade and holder assembly:
• Put the blade holder on a at surface with the spacer
pockets facing up.
• Insert blade spacers with their slots facing the inner
opening of the blade holder.
• Insert blades with cutting edge facing down and slots
facing up.
• Insert blades with cutting edge and slots facing down.
• Put the blade holder plate into place and secure it with
the thumbscrews.
3. When nished, be sure to clean the machine using the
instructions to the right.
181DM12 - 1/2" | 181DM14 - 1/4" | 181DM38 - 3/8"
PREPARATION
These dicers can be mounted to a countertop, workstation,
or wall.
1. Wall-Mount Instructions:
• Place the unit where you'd like it to be mounted.
• Find the closest stud and move the machine so that the
mounting holes on one side of the unit are over the stud.
It's important that the unit be mounted to a stud to
prevent it from falling during use.
• Mark the 4 hole locations and remove the machine.
• Drill 5/32" holes through these marks and then, with
washers under their heads, drive the mounting screws
through the holes in the unit and into the holes in
the wall.
2. Countertop/Workstation Instructions:
• Choose a sturdy countertop or workstation for mounting.
• Place the unit where you'd like it to be mounted.
• Mark the 4 hole locations and remove the machine.
• Drill 5/32" holes through these marks and then, with
washers under their heads, drive the mounting screws
through the holes in the unit and into the holes in
the surface.
NOTE: To cut 1/4" and 1/2", use the 1/4" push block.
To cut 3/8", use the 3/8" push block.
OPERATION
1. Put an onion on the blade and holder assembly.
2. After making sure your hands and fingers are clear of
the cutting area, pull the handle in one quick motion.
• This may occassionally need to be repeated for onions
that are exceptionally large.
• Do not try to cut onions that are bigger than the opening
in the blade holder.
CLEANING & MAINTENANCE
NOTE: DO NOT use cooking oil.
Please read and comply with the instructions listed on this
document. To get the best service life and performance from your
machine, clean it thoroughly before and after use by following the
instructions listed below. Minimize the use of alkaline cleaners as
they may dull the nish and cause pitting.
REPLACEMENT PARTS
10/2023
ITEM NUMBER DESCRIPTION
#181PBLD14 1/4" Blades (22)
#181PBLD38 3/8" Blades (16)
#181PBLD12 1/2" Blades (10)
#181PPB38 3/8" Pusher Block
#181PPB1412 1/4", 1/2" Pusher Block
#181BRKDD Dicer Wall Bracket
#181BUMPER Bumper
#181SSWNUT Wingnut
#181TSCREW Thumb Screw
#181FT1 Feet (4)

Produkt Specifikationer

Mærke: GARDE
Kategori: Skæremaskine
Model: 181PPB1412
