Installation
Instructions
KIT CONTENTS
4 Support Pads
4 Mounting Screws
Drawer Divider
1
SBSD137, SBSD227
TOOLS YOU WILL NEED
Phillips Head
Screwdriver
9/16” Open End Wrench
or Adjustable Wrench
8 mm Socket Wrench
1 REMOVE THE LEVELING LEGS
A Carefully lay the washer or dryer on its side to
access the leveling legs on the bottom of the
appliance.
IMPORTANT: Do not lay the washer or dryer on
its back! Do not remove the shipping bolts on the
back side of the washer. The bolts must remain in
place until the washer is returned to an upright
position.
B Use an open-end wrench to remove the
washer or dryer leveling legs.
INSTALLATION PREPARATION
Remove the packaging.
The Drawer divider is taped at the top of the
shipping carton. Remove the divider and set aside
for final installation.
Flatten the product carton to use as a pad
to lay the washer or dryer down on its side.
Continue using the carton to protect the finished floor
in front of the installation location.
Back out and remove
all 4 leveling legs
Instructions en français : . . . . . . . . . . . . . . . . 4
Instrucciones en español: . . . . . . . . . . . . . . . 8
For Washer Models: GBVH5140, GBVH6260, GCVH6260, GCVH6600, GCVH6800, GFAN1000,
GFAN1100,
GFWH1200, GFWH1300, GFWH1400, GFWH1405, GFWH2400,
GFWH2405, GFWN1000, GFWN1100, GFWN1200, GFWN1300, GFWS1500,
GFWS1505, GFWS3500, GFWS3505,
GHDVH626, GHDVH670,
GMAN1200,
WBVH5100,
WBVH6240,
WCVH5300,
WCVH6260, WCVH6600,
WCVH6800,
WHDVH626 & WHDVH660
For Dryer Models: DBVH510, DBVH512, DCVH515, DCVH660, DHDVH52, DHDVH66,
GFDM245, GFDN100, GFDN110, GFDN120, GFDN130, GFDN240, GFDN245,
GFDS140, GFDS145, GFDS150, GFDS155, GFDS350, GFDS355, GFMN100,
GFMN110, GFMN240, GFMS350, GFMS355, GMMN120,
PBVH415, PCVH565,
PCVH680,
PDVH515, PHDVH52 & PHDVH57
BEFORE YOU BEGIN
Read these instructions completely
and carefully.
• IMPORTANT ³6DYHWKHVHLQVWUXFWLRQV
for local inspector’s use.
• IMPORTANT ³2EVHUYHDOOJRYHUQLQJ
codes and ordinances.
• Note to Consumer – Keep these instructions with
your Owner’s Manual
for future reference.
• Completion time – 1 to 2 hours
• Proper installation is the responsibility
of the installer.
• Product failure due to improper installation is not
covered under the Warranty.
CAUTION ³'XHWRWKHVL]HDQGZHLJKW
of these products, and to reduce the risk of
personal injury or damage to the product,
TWO PEOPLE ARE REQUIRED
FOR PROPER INSTALLATION.
• See washer and dryer installation instructions
for additional installation requirements and
guidelines.
49-90321-2 175D1807P589 11-13 GE
2
Installation Instructions
3
INSTALL THE PEDESTAL
TO THE WASHER OR DRYER
A Place the pedestal against the bottom
of the unit. Check to be sure the drawer front
is at the front of the unit.
B Align the holes in the pedestal with
the holes in the bottom of the unit.
Use a Phillips screwdriver to install
the 4 screws through the pedestal
DQGLQWRWKHXQLW³GRQRWWLJKWHQ
C Slide the pedestal toward the unit,
until it is aligned front to back. Use an
8 mm socket wrench to securely tighten the
screws.
2
PREPARE THE PEDESTAL
A Pull the
drawer out
as far as it
will go.
B Remove screws
from drawer
slides. Slide
drawer out of
the base and set
aside.
C Do not remove
the foam blocks
on the top of the
pedestal.
FOR DRYERS ONLY:
D Locate the 4 support pads from the parts
package. Each pad has 2 protrusions that fit
into the holes on top of the pedestal. Press the
rubber pads into each set of corner holes on
the top of the pedestal as shown.
NOTE: The support pads should be installed on
the dryer only. DO NOT INSTALL THESE PADS ON
THE WASHER PEDESTAL.
