Hybrid Element installation manual
1. Removing dummy cover
• Pushandholdtheunlocking
button.
• Movethedummycoververtically
untilitisevenwiththemarked
lineandtakeitoff.
2. Preparation and
installation of the CATV
receiver (optional)
• RemovetheCATVdrawerfromthe
baseplate.
• Removethedustcapfromthe
CATVdrawer.
• PlacetheCATVreceiverinsidethe
CATVdrawer.Pushgentlyuntil
youhearanaudible‘click’.

• Removethedustcapfromthe
CATVreceiver.(a)
• SlidetheCATVdrawerbackinthe
FTUandpushdownwardsuntil
youhearanaudible‘click’.(b)
3. Installation of the Hybrid
Element
• Removetheprotectioncapfrom
theElementfiberconnector.
• CarefullypositiontheHybrid
ElementontopoftheFiber
TerminationUnit.Thebottomof
theElementshouldmatchthe
markedlineontheFTU.
• InstalltheHybridElementby
gentlypushingthefrontpart,
whileslidingitdownuntilthe
FTUiscoveredandyouhearan
audible‘click’.
• TheHybridElementisnow
correctlyinstalled.
Hybrid Element connector
numbering
The number of Ethernet ports
available is dependent upon the
specific Hybrid Element model. What
your Hybrid Element looks like may
differ slightly from the image.
4. Powering of the Hybrid
Element
• Connectthe12Vplugofthe
suppliedadaptertotheHybrid
Elementandconnecttheadapter
toapowersocket.
www.genexis.eu Rev.2
Click!
Click!
Hybrid Live! slot
(LAN3)
Ethernet port 1
(LAN1)
Ethernet port 2
(LAN2)
a. b.
